© National Instruments Corporation A-1 SCXI-1121 User Manual
A
Specifications
This appendix lists the specifications for the SCXI-1121. These are
typical at 25 °C unless otherwise stated. The operating temperature range
is 0 to 50 °C.
Analog Input
Gain (jumper-selectable)........................ 1, 2, 5, 10, 20, 50, 100, 200, 500,
1,000, 2,000
Output range........................................... ±5 V
Number of channels ............................... 4
Gain accuracy
1
...................................... 0.15% of full scale
Offset voltage
Input................................................ ±6 µV
Output ............................................. ±3 mV
Stability versus ambient temperature
Input offset drift.............................. ±0.2 µV/°C
Output offset drift ........................... ±200 µV/°C
Gain drift......................................... 20 ppm/°C
Input bias current .................................. ±80 pA
Input resistance
Normal ............................................ 1 GΩ
Power off.........................................50 kΩ
Overload.......................................... 50 kΩ
Output resistance
Multiplexed-Output mode............... 100 Ω
Parallel-Output mode...................... 330 Ω
1
Includes the combined effects of gain, offset, and hysteresis and nonlinearity
