- Getting Started with Your PXI-8461 or PXI-8460 and the NI-CAN™ Software for Windows NT
- Support
- Important Information
- Compliance
- Contents
- About This Manual
- Chapter 1 Introduction
- Chapter 2 Installation and Configuration
- Chapter 3 Verify the Installation
- Chapter 4 Begin to Use the NI-CAN Software
- Appendix A Uninstalling the Hardware and Software
- Appendix B Cabling Requirements for PXI-8461 High-Speed CAN
- Appendix C Cabling Requirements for PXI-8460 Low-Speed CAN
- Appendix D Troubleshooting and Common Questions
- Appendix E Specifications
- Appendix F Technical Support Resources
- Glossary
- Figures
- Figure 2-1. Add/Remove Programs Properties Dialog Box
- Figure 2-2. Installing the PXI Hardware
- Figure 2-3. PXI-8461 That Is Working Properly
- Figure 2-4. NI-CAN Hardware Settings Dialog Box
- Figure 3-1. NI CAN Diagnostic Utility after Testing
- Figure A-1. Add/Remove Programs Properties Dialog Box
- Figure B-1. Pinout for 9-Pin D-Sub Connector
- Figure B-2. Pinout for 5-Pin Combicon-Style Pluggable Screw Terminal
- Figure B-3. PXI-8461 Part Locator Diagram
- Figure B-4. Power Source Jumpers
- Figure B-5. Termination Resistor Placement
- Figure B-6. Cabling Example
- Figure C-1. Pinout for 9-Pin D-Sub Connector
- Figure C-2. PXI-8460 Parts Locator Diagram
- Figure C-3. Power Source Jumpers
- Figure C-4. Termination Resistor Placement for Low-Speed CAN
- Figure C-5. Location of Termination Resistors on a PXI-8460
- Figure C-6. Preparing Lead Wires of Replacement Resistors
- Figure C-7. Cabling Example
- Tables
- Table B-1. Power Requirements for the CAN Physical Layer for Bus-Powered Versions
- Table B-2. ISO 11898 Specifications for Characteristics of a CAN_H and CAN_L Pair of Wires
- Table B-3. DeviceNet Cable Length Specifications
- Table C-1. Power Requirements for the Low-Speed CAN Physical Layer for Bus-Powered Versions
- Table C-2. ISO 11519-2 Specifications for Characteristics of a CAN_H and CAN_L Pair of Wires
© National Instruments Corporation E-1 PXI-8461 or PXI-8460 and NI-CAN for Windows NT
E
Specifications
This appendix describes the physical characteristics of the hardware and
the recommended operating conditions.
PXI-8461 One Port and Two Port
Dimensions............................................. PXI 3U Module
100 by 160 mm
(3.94 by 6.30 in.)
Power requirement ................................. +5 VDC 500 mA typical
I/O connector.......................................... 9-pin D-Sub for each port
(standard)
or
5-pin Combicon-style pluggable
DeviceNet screw terminal
Operating environment
Component temperature.................. 0 to 55 °C
Relative humidity............................ 10% to 90%, noncondensing
Storage environment
Temperature.................................... –20 to 70 °C
Relative humidity............................ 10% to 90%, noncondensing
PXI-8460 One Port and Two Port
Dimensions............................................. PXI 3U Module
100 by 160 mm
(3.94 by 6.30 in.)
Power requirement ................................. +5 VDC 500 mA typical
I/O connector.......................................... 9-pin D-Sub for each port
