© National Instruments Corporation A-1 PXI-8461 or PXI-8460 and NI-CAN for Windows NT
A
Uninstalling the Hardware
and Software
This appendix describes how to uninstall the PXI-8461 or PXI-8460
hardware and the NI-CAN software from Windows NT.
Uninstalling the Hardware from Windows NT
Because Windows NT 3.51 and 4.0 do not maintain hardware information
for the board, you just need to physically remove your PXI hardware from
your computer. To do so, shut down Windows NT, power off your PXI or
CompactPCI chassis, remove any cables attached to your board, and
physically remove the board.
Uninstalling the NI-CAN Software from Windows NT
Note
The following instructions apply to Windows NT 4.0 only. If you are using Windows
NT 3.51, refer to the
readme.txt file in your NI-CAN directory for information on how
to uninstall the NI-CAN software.
Before uninstalling the NI-CAN software, you should remove the PXI
boards from your computer, as explained in the previous section.
