Chapter 3 Advanced Programming with NI-IMAQdx
NI-IMAQdx User Manual 3-4 ni.com
The following range is applicable for any given attribute.
Broadcasting
Many machine vision applications involve a single host computer
acquiring data from a single industrial camera. Other machine vision
applications acquire data from multiple industrial cameras concurrently.
With the broadcasting feature, a machine vision application can run on
multiple host computers while acquiring data from a single camera, as
shown in Figure 3-1.
Table 3-4. Attribute Types and Compatible Range
Attribute Type Compatible Range
U32 Minimum, Maximum, Increment
I64 Minimum, Maximum, Increment
F64 Minimum, Maximum, Increment
String N/A
Enum Attribute Values
Bool N/A
Command N/A
