NI PXI/PCI-5124 Specifications 24 ni.com
Software
Specification Val ue Comments
Driver
Software
NI-SCOPE 2.7 or later
NI-SCOPE is an IVI-compliant driver that allows you to
configure, control, and calibrate the NI 5124. NI-SCOPE
provides application programming interfaces for many
development environments.
—
Application
Software
NI-SCOPE provides programming interfaces,
documentation, and examples for the following
application development environments:
•LabVIEW
• LabWindows
™
/CVI
™
• Measurement Studio
• Microsoft Visual C/C++
• Microsoft Visual Basic
—
Interactive
Soft Front
Panel and
Configuration
The Scope Soft Front Panel supports interactive control of
the NI 5124. The Scope Soft Front Panel is included on the
NI-SCOPE CD.
National Instruments Measurement & Automation Explorer
(MAX) also provides interactive configuration and test tools
for the NI 5124. MAX is included on the NI-SCOPE CD.
—
