© National Instruments Corporation 23 NI PXI/PCI-5124 Specifications
Calibration
Power
Specification Val ue Comments
Self-Calibration Self-calibration is done on software command.
The calibration corrects for gain, offset, frequency
response, triggering, and timing adjustment errors
for all input ranges.
—
External Calibration
(Factory Calibration)
The external calibration calibrates the VCXO and the
voltage reference. Appropriate constants are stored
in nonvolatile memory.
—
Interval for External
Calibration
2 years —
Warm-Up Time 15 minutes —
Specification Typical Value Comments
NI PXI-5124 NI PCI-5124 —
+3.3 VDC 1.3 A 1.3 A
+5 VDC 1.7 A 2.7 A
+12 VDC 130 mA 130 mA
–12 VDC 270 mA 0A
Total Power 17.6 W 19.4 W
