- NI PXI/PCI-5124 Specifications
- Contents
- Vertical
- Analog Input (Channel 0 and Channel 1)
- Figure 1. NI 5124 Frequency Response (Typical)
- Figure 2. NI 5124 Dynamic Performance, 50 W , 1 Vpk-pk Range, 262,144 Point FFT (Typical)
- Figure 3. Representation of NI 5124 Spectral Noise Density on 0.2 V Range, Noise Filter Enabled, 1 MW Input Impedance
- Figure 4. Representation of NI 5124 Spectral Noise Density on 0.2 V Range, Full Bandwidth, 50 W Input Impedance
- Analog Input (Channel 0 and Channel 1)
- Horizontal
- Trigger
- PFI 0 and PFI 1 (Programmable Function Interface, AUX Front Panel Connector)
- TClk Specifications
- Waveform Specifications
- Calibration
- Power
- Software
- Environment
- Safety, Electromagnetic Compatibility, and CE Compliance
- Physical
- Where to Go for Support
NI PXI/PCI-5124 Specifications 2 ni.com
PFI 0 and PFI 1 (Programmable Function Interface,
AUX Front Panel Connector) ...............................................................20
TClk Specifications .................................................................................21
Waveform Specifications ........................................................................22
Calibration ...............................................................................................23
Power .......................................................................................................23
Software...................................................................................................24
Environment ............................................................................................25
NI PXI-5124 .....................................................................................25
NI PCI-5124 .....................................................................................26
Safety, Electromagnetic Compatibility, and CE Compliance .................27
Safety................................................................................................27
Electromagnetic Compatibility.........................................................27
CE Compliance.................................................................................27
Environmental Management ............................................................28
Physical....................................................................................................28
Front Panel Connectors ....................................................................28
Dimensions and Weight ...................................................................29
Where to Go for Support .........................................................................31
Vertical
Analog Input (Channel 0 and Channel 1)
Specification Val ue Comments
Number of
Channels
Two (simultaneously sampled) —
Connector BNC —
Impedance and Coupling
Input Impedance 50 Ω ±2.0% 1MΩ ±0.75% in parallel
with a typical capacitance
of 29 pF
Software
selectable
Input Coupling AC, DC, GND AC coupling
available on
1MΩ only
