- NI PXI/PCI-5124 Specifications
- Contents
- Vertical
- Analog Input (Channel 0 and Channel 1)
- Figure 1. NI 5124 Frequency Response (Typical)
- Figure 2. NI 5124 Dynamic Performance, 50 W , 1 Vpk-pk Range, 262,144 Point FFT (Typical)
- Figure 3. Representation of NI 5124 Spectral Noise Density on 0.2 V Range, Noise Filter Enabled, 1 MW Input Impedance
- Figure 4. Representation of NI 5124 Spectral Noise Density on 0.2 V Range, Full Bandwidth, 50 W Input Impedance
- Analog Input (Channel 0 and Channel 1)
- Horizontal
- Trigger
- PFI 0 and PFI 1 (Programmable Function Interface, AUX Front Panel Connector)
- TClk Specifications
- Waveform Specifications
- Calibration
- Power
- Software
- Environment
- Safety, Electromagnetic Compatibility, and CE Compliance
- Physical
- Where to Go for Support
© National Instruments Corporation 19 NI PXI/PCI-5124 Specifications
TRIG (External Trigger, Front Panel Connector)
Trigger
Filters
Low-Frequency
(LF) Reject
High-Frequency
(HF) Reject
—
50 kHz 50 kHz
Digital Trigger (Digital Trigger Type)
Sources NI PXI-5124 NI PCI-5124 —
PXI_Trig<0..6>
(backplane connector)
PFI<0..1>
(front panel SMB connector)
PXI Star Trigger
(backplane connector)
RTSI<0..6>
PFI<0..1>
(front panel SMB connector)
Video Trigger (Video Trigger Type)
Sources CH 0 (front panel BNC connector)
CH 1 (front panel BNC connector)
TRIG (front panel BNC connector)
—
Types Specific Line
Any Line
Specific Field
—
Standard Negative sync of NTSC, PAL, or SECAM signal —
Specification Value Comments
Connector BNC —
Impedance 1MΩ in parallel with 22 pF —
Coupling AC, DC —
AC-Coupling Cutoff
(–3 dB)
12 Hz —
Input Voltage Range ±5 V —
Maximum Input Overload |Peaks| ≤42 V —
Specification Val ue Comments
