NI PXI/PCI-5124 Specifications 14 ni.com
Sample Clock
Jitter, Typical
≤1 ps rms (100 Hz to 100 kHz)
≤2ps rms (100 Hz to 1MHz)
Includes the
effects of
the converter
aperture
uncertainty and
the clock
circuitry jitter
Excludes trigger
jitter
Timebase
Frequency
200 MHz —
Timebase
Accuracy
Not Phase-Locked to
Reference Clock
Phase-Locked to
Reference Clock
—
±25 ppm Equal to the Reference
Clock accuracy
Sample Clock
Delay Range
±1 Sample Clock period —
Sample Clock
Delay/Adjustment
Resolution
≤5ps —
Specification Value Comments
