Appendix A Specifications for PCMCIA Bus
6023E/6024E/6025E User Manual A-12 ni.com
Accuracy Information
Transfer Characteristics
Relative accuracy....................................±0.5 LSB typ dithered,
±1.5 LSB max undithered
DNL ........................................................±0.75 LSB typ,
–0.9to+1.5LSBmax
No missing codes....................................12 bits, guaranteed
Offset error
Pregain error after calibration..........±12 µVmax
Pregain error before calibration.......±28 mV max
Postgain error after calibration ........±0.5 mV max
Postgain error before calibration .....±100 mV max
Gain error (relative to calibration reference)
After calibration (gain = 1)..............±0.02% of reading max
Before calibration ............................±2.75% of reading max
Gain ≠ 1 with gain error
adjusted to 0 at gain = 1...................±0.05% of reading max
Nominal Range (V)
Absolute Accuracy Relative Accuracy
% of Reading
Offset
(mV)
Noise + Quantization
(mV)
Tem p
Drift
(%/ °
°°
°C)
Absolute
Accuracy
at Full
Scale
(mV)
Resolution (mV)
Positive
FS
Negative
FS
24 Hours 1Year Single Pt. Averaged Single Pt. Averaged
10 –10 0.0872 0.0914 8.83 3.91 1.042 0.0010 19.012 5.89 1.37
5 –5 0.0272 0.0314 4.42 1.95 0.521 0.0005 6.517 2.95 0.686
0.5 –0.5 0.0872 0.0914 0.462 0.452 0.052 0.0010 0.972 0.516 0.069
0.05 –0.05 0.0872 0.0914 0.066 0.063 0.007 0.0010 0.119 0.073 0.009
Note: Accuracies are valid for measurements following an internal E Series calibration. Averaged numbers assume dithering and averaging of
100 single-channel readings. Measurement accuracies are listed for operational temperatures within ±1 °C of internal calibration temperature
and ±10 °C of external or factory calibration temperature.
