Chapter 4 Signal Connections
© National Instruments Corporation 4-3 6023E/6024E/6025E User Manual
Figure 4-2. I/O Connector Pin Assignment for the 6025E
50 100
49 99
48 98
47 97
46 96
45 95
44 94
43 93
42 92
41 91
40 90
39 89
38 88
37 87
36 86
35 85
34 84
33 83
32 82
31 81
30 80
29 79
28 78
27 77
26 76
25 75
24 74
23 73
22 72
21 71
20 70
19 69
18 68
17 67
16 66
15 65
14 64
13 63
12 62
11 61
10 60
959
858
757
656
555
454
353
252
151
FREQ_OUT GND
GPCTR0_OUT +5 V
PFI9/GPCTR0_GATE GND
PFI8/GPCTR0_SOURCE PA0
PFI7/STARTSCAN GND
PFI6/WFTRIG PA1
PFI5/UPDATE* GND
GPCTR1_OUT PA2
PFI4/GPCTR1_GATE GND
PFI3/GPCTR1_SOURCE PA3
PFI2/CONVERT* GND
PFI1/TRIG2 PA4
PFI0/TRIG1 GND
EXTSTROBE* PA5
SCANCLK GND
+5 V PA6
+5 V GND
DGND PA7
DIO7 GND
DIO3 PB0
DIO6 GND
DIO2 PB1
DIO5 GND
DIO1 PB2
DIO4 GND
DIO0 PB3
DGND GND
AOGND PB4
RESERVED GND
DAC1OUT PB5
DAC0OUT GND
AISENSE PB6
ACH15 GND
ACH7 PB7
ACH14 GND
ACH6 PC0
ACH13 GND
ACH5 PC1
ACH12 GND
ACH4 PC2
ACH11 GND
ACH3 PC3
ACH10 GND
ACH2 PC4
ACH9 GND
ACH1 PC5
ACH8 GND
ACH0 PC6
AIGND GND
AIGND PC7
