Appendix B Custom Cabling and Optional Connectors
6023E/6024E/6025E User Manual B-2 ni.com
♦ 6025E
AMP 100-position IDC male connector
AMP backshell, 0.50 max O.D. cable
AMP backshell, 0.55 max O.D. cable
Mating connectors and a backshell kit for making custom 68-pin cables are
available from National Instruments.
Optional Connectors
The following table shows the optional connector and cable assembly
combinations you can use for each device.
Device Connector Cable Assembly
PCI-6023E/6024E 68-Pin E Series SH6868, R6868
50-Pin E Series SH6850, R6850
DAQCard-6024E 68-Pin E Series SHC68-68-EP, RC68-68
50-Pin E Series 68M-50F adapter plus
SHC68-68-EP or RC68-68 cable
6025E MIO-16 68-Pin, 68-Pin Extended
Digital Input
SH1006868
50-Pin E Series, 50-Pin Extended
Digital Input
RI005050
