Brochure

GRILL SPECIFICATIONS BIPRO600RBI BIPRO500RB BIPT750RBI BIP500 BIPF600 BIPF450 BIU405RB BIM730RBI BIM605RBI BIM485RB
LIFT EASE
™
roll top lid S S S S S S - S S S
ACCU PROBE
™
temperature gauge S S S S S S S S S S
Total cooking surface (sq. in.)* 922 760 1160 760 1100 890 570 1025 850 675
Electronic ignition S S° S - S S S - - -
JETFIRE
™
ignition - S - S - - - S S S
Infrared ceramic bottom burners 1 - 2 - 2 1 - 1 1 -
Stainless steel bottom burners 4 4 3 4 2 2 3 4 3 3
Infrared rear rotisserie burner S S S - S S S S S S
Stainless steel WAVE
™
cooking grids - - - - - - - S S S
Stainless steel 9.5 mm WAVE
™
cooking grids S S S - S S - - - -
Porcelain cast iron WAVE
™
reversible channel cooking grids - - - S - - S - - -
i-GLOW
™
backlit control knobs - S - - - - - S S S
EASY SET
™
control knobs S S S S S S S S S S
Removable drip pan S S S S S S S S S S
Warming rack S S S S S S S S S S
President’s Limited Lifetime Warranty S S S S S S - S S S
DIMENSIONS (opening size) BIPRO600RBI BIPRO500RB BIPT750RBI BIP500 BIPF600 BIPF450 BIU405RB BIM730RBI BIM605RBI BIM485RB
Length (in) 37 3/4” 30 3/4” 49 3/4” 30 3/4” 55 3/4” 46 3/4” 27 1/2” 43 1/4” 36 1/2” 29 3/4”
Depth (in) 20 5/8” 20 5/8” 20 5/8” 20 5/8” 20 5/8” 20 5/8” 16 3/4” 21 3/8” 21 3/8” 21 3/8”
Height (in) 8 7/8” 8 7/8” 9 5/8” 8 7/8” 8 7/8” 8 7/8” 12” 7 1/2” 7 1/2” 7 1/2”
DOORS & ACCESSORIES Part Number Width Height Depth
Flat Stainless Steel Door N370-0361-1 17” 23 1/4” -
Flushed Mount Stainless Steel Double Door N370-0502 28 1/4” 20 1/4” -
Flushed Mount Stainless Steel Double Door N370-0503 37 3/4” 20 1/4” -
Stainless Steel Single Drawer N370-0359 17 1/4” 6 3/4” 23”
Stainless Steel Triple Drawer N370-0360 17 1/4” 22 3/4” 23”
Infrared SIZZLE ZONE
™
Burner with Roll Top BISZ300 20 1/8” 9 5/8” 20 5/8”
Infrared SIZZLE ZONE
™
with Flat Top BISZ300FT 20 1/8” 9 5/8” 20 5/8”
Double Side Burner BISB245 20 1/8” 8 7/8” 20 5/8”
Side Burner N370-0504/05 18” 15” 4 1/2”
Zero Clearance (2) 37” BIZC600 44 1/8” 22 15/16” 11 1/8”
OASIS
™
MODULAR COMPONENTS Part Number Width Height Depth
Under Grill Cabinet - 300 series IM-UGC300 24” 35” 24”
Under Grill Cabinet - 500 series IM-UGC500 34 3/4” 35” 24”
Under Grill Cabinet - 600 series IM-UGC600 42” 35” 24”
Under Grill Cabinet - 750 series IM-UGC750 53 3/4” 35” 24”
Under Grill Cabinet - 485 series IM-UGC485 34 3/4” 35” 24”
Under Grill Cabinet - 605 series IM-UGC605 40 1/2” 35” 24”
Under Grill Cabinet - 730 series IM-UGC730 47 1/4” 35” 24”
Propane Tank Cabinet - universal door IM-UTC 24” 35” 24”
Universal Door Cabinet IM-UDC 24” 35” 24”
Fridge Cabinet IM-FDC 24” 35” 24”
Three Drawer Cabinet IM-3DC 24” 35” 24”
Two Drawer Cabinet IM-2DC 24” 35” 24”
Waste Drawer with Paper Towel Holder IM-WDC 24” 35” 24”
Cabinet End Panel IM-CEP 2” 31” 24”
Cabinet Transitions - 45 degrees IM-45T 18 3/8” 35” -
Wall Spacer IM-WSF 1 1/2” 35” 4”
Ice Bucket Holder IM-IBA 19 1/8” 1 3/16” 16”
S = Standard O = Optional ° Rear burner * All lid openings require a minimum of 5” clearance behind the unit. Refer to owners manual for individual models. - Dimensions subject to change. Refer to manual for accurate dimensions
