Installation Guide

8
W415-0713 / A / 11.09.10
Installation and repairs must be performed by a qualifi ed installer, service agency or the supplier.
4.0 REPLACEMENTS
COMPONENTS
REF NO. PART NO. DESCRIPTION
1 W280-0071 NIGHT LIGHT LENS FRAME
2 W290-0080 NIGHT LIGHT GASKET
3 W300-0067 CERAMIC ORANGE NIGHT LIGHT LENS
4 W100-0107 RIGHT SIDE LOG BURNER
4 W100-0108 LEFT SIDE LOG BURNER
5* W175-0227 CONNECTOR, 3/8” STAINLESS STEEL FLEX
6* W175-0289 CONNECTOR, 3/8” STAINLESS STEEL FLEX (24”)
7 W010-1829 3-WAY NATURAL GAS PILOT ASSEMBLY
7 W010-1830 3-WAY PROPANE GAS PILOT ASSEMBLY
8 W456-0033 #33 ORIFICE NATURAL
8 W456-0053 #53 ORIFICE PROPANE
9 W455-0070 NATURAL GAS PILOT INJECTOR
9 W455-0065 PROPANE GAS PILOT INJECTOR
10 GL-666 LOG SET
11 W135-0366 LOG, RIGHT MIDDLE #2
12 W135-0367 LOG, LEFT MIDDLE #1
13 W135-0368 LOG, RIGHT FRONT #3
14 W135-0369 LOG, LEFT FRONT #5
15 W135-0370 LOG, MIDDLE FRONT #4
16 W135-0371 LOG, RIGHT CROSSOVER
17 W135-0372 LOG, LEFT CROSSOVER
18 W135-0373 LOG, BOTTOM FRONT CROSSOVER
19 W135-0374 LOG, BOTTOM LEFT FRONT
20 W475-0574 HEARTH RIGHT FIBRE PANEL
21 W475-0613 HEARTH LEFT FIBRE PANEL
22* W361-0016 GLOWING EMBERS
23* W550-0001 CHARCOAL EMBERS
24* W550-0002 CHARCOAL LUMPS
25* W361-0014 VERMICULITE
26 W750-0200 FLAME SENSOR
27 W750-0201 ELECTRODE
28 W010-1946 ASSEMBLY, LOG GRATE
Contact your dealer or the factory for questions concerning prices and policies on replacement parts. Normally
all parts can be ordered through your Authorized dealer / distributor.
FOR WARRANTY REPLACEMENT PARTS, A PHOTOCOPY OF THE ORIGINAL INVOICE WILL BE
REQUIRED TO HONOUR THE CLAIM.
When ordering replacement parts always give the following information:
• Model & Serial Number of appliance
• Installation date of appliance
• Part number
• Description of part
• Finish
* IDENTIFIES ITEMS WHICH ARE NOT ILLUSTRATED. FOR
FURTHER INFORMATION, CONTACT YOUR AUTHORIZED DEALER.
41.1
FAILURE TO POSITION THE PARTS
IN ACCORDANCE WITH THIS
MANUAL OR FAILURE TO USE ONLY
PARTS SPECIFICALLY APPROVED
WITH THIS APPLIANCE MAY
RESULT IN PROPERTY DAMAGE OR
PERSONAL INJURY.
!
WARNING
