Installation Guide

Hayden Collection
Technical Specification Guide
Please call [phone] or visit mylenstairs.com for additional product
information, assistance or questions.
Page 1
Collection Overview
Powder coated white, gray or black steel column sleeves, offered with either laminate wood treads and platform or
color matched 3/8” steel treads and platform. The Hayden collection is offered with horizontal stainless steel line rail
infill and color matched aluminum handrails and is suitable for loft installations. Either tread option is available with
Anti-slip Traction Tread Covers. Adjustable rise from 8 ½” to 9 ½” between treads via 1/8” spacers.
Mylen Stairs stands behind our product with a five-year Warranty on everything we sell and a lifetime
warranty on metal fabrication (see below for details). You can trust us if you have a problem, we will fix it for
you, that’s the bottom line. If you have any questions please e-mail us at [e-mail] or call us at
[phone]. More detailed warranty information is available on our Warranty Disclaimer document or on
our www.mylenstairs.com web site.
Color and Finish Options
The Hayden Collection is offered with the following color and finish options to suit your design tastes and specific
installation application. The Hayden Collection is recommended for interior installations only.
Column Sleeves
Powder Coated White, Gray or Black Steel
Ballusters Only
(Laminate Treads Option)
Powder Coated White, Gray or Black Steel
Treads and Ballusters
(Steel Treads Option)
Powder Coated White, Gray or Black Steel
Tread Type
Smooth Steel or Smooth Laminate Wood
Handrail
Powder Coated White, Gray or Black Aluminum
Optional Traction Tread Covers
Black
Diameter Measurements
The recommended opening should be at
least 4" wider than the staircase’s diameter
Please refer to the following chart for more
diameter measurement information.
Stair Diameter
Floor Opening
42” (3’6”)
46”
60” (5’0”)
64”
