User`s manual

114
SPECIFICATIONS
Item
Transport Stream MPEG-2 ISO/IEC 13818 / Transport stream Specificartion
Profile Level MPEG-2 MP@ML
Input Rate Max. 90 Mbit/
Video Resolution 720×576(PAL)/720×480(NTSC)
Audio Decoding MPEG/Musicam LayerⅠ&Ⅱ
Audio Mode Single channel/Dual channel Joint Stereo/Stereo
Teletext VBI & OSD(Optional)
Sampling Rate 32,44.1 and 48KHz
Specification
VI. MPEG Transport Stream & A/V Decoding
Item
Main Processor ARM946 RISC Processor
Flash Memory 2 Mbyte
Program DRAM 32 Mbyte
Channel Capacity Digital Channel : 5000
Specification
VII. System Resources
Item
Input Voltage AC 90 to 250V, 50~60Hz
Power Consumption Max. 50W
Poteciton Separate Internal Fuse
Type SMPS
Specification
VIII. Power Supply
Item
Size (W×H×D) 290×50×220(mm)
Net Weight 2.0Kg
Specification
IX. Physical Specification
Item
RF-Connector 75 ohm IEC 169-2, Male/Female
Frequency 470MHz to 860MHz
Output Channel CH 21-69 for the Demodulator
TV Standard PAL G/I/K Selectable by Menu Setting
Audio OUtput Mono with Volume Control
Preset Channel Ch 38(or TBD), Software changeable by Menu Screen
Specification
V. RF-Modulator
