SDW-225SS WELDER/GENERATOR — OPERATION & PARTS MANUAL — REV. #2 (10/07/05) — PAGE 123
KUBOTA Z482-EB ENGINE — WATER FLANGE & THERMOSTAT ASSY.
WATER FLANGE & THERMOSTAT ASSY.
NO PART NO PART NAME QTY. REMARKS
010 1687572700 COMP. FLANGE, WATER 1
020 1624173370 PIPE, WATER RETURN .................... 1 ........... NCLUDES ITEMS W/
*
030
*
1584172922 GASKET, WATER FLANGE 1 I
040 0102350616 BOLT 2
050 0102360650 BOLT 4
060 1685173350 PIPE, WATER RETURN 1
070 1624173360 BAND, PIPE 2
080 1553173010 ASSY. THERMOSTAT 1
090 1584173260 COVER, THERMOSTAT 1
100 1685173270 GASKET, THERMOSTAT 1
110 0102350622 BOLT 2
120 1554383040 SWITCH, THERMOMETER 1
