PARTS AND OPERATION MANUAL OPERATION AND PARTS MANUAL WHISPERWATTTM SERIES MODEL DCA-600SSV 60 Hz GENERATOR PARTS LIST NO. C4874303204 Revision #0 (07/13/07) THIS MANUAL MUST ACCOMPANY THE EQUIPMENT AT ALL TIMES.
PROPOSITION 65 WARNING Diesel engine exhaust and some of PAGE 2 — DCA-600SSV — OPERATION AND PARTS MANUAL — REV.
REPORTING SAFETY DEFECTS If you believe that your vehicle has a defect that could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Multiquip at 1-800-421-1244. If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.
TABLE OF CONTENTS MQ Power DCA-600SSV 60 Hz AC Generator California Proposition 65 Warning ..................................... 2 Reporting Safet Defects ................................................... 3 Table of Contents .............................................................. 4 Parts Ordering Procedures ............................................... 5 Specifications ................................................................... 6 Dimensions (Top, Side, Front) .............................
www.mqpower.com PARTS ORDERING PROCEDURES Ordering parts has never been easier! Choose from three easy options: Effective: Order via Internet (Dealers Only): If you have an MQ Account, to obtain a Username and Password, E-mail us at: parts@multiquip.com. Order parts on-line using Multiquip’s SmartEquip website! ■ View Parts Diagrams ■ Order Parts To obtain an MQ Account, contact your Use the internet and qualify for a 5% Discount on Standard orders for all orders which include Goto www.multiquip.
DCA-600SSV — SPECIFICATIONS Table 1. Generator Specifications Model DCA-600SSV Type Revolving field, self ventilated, open protected type synchronous generator Armature Connection Star with Neutral Phase 3 Standby Output 660 KVA (528 KW) Prime Output 600 KVA (480 KW) Voltage — 1Ø 120, 127, 139, 240, 254, and 277V Voltage — 3Ø 208, 220, 240, 416, 440, and 480V Frequency 6 0 Hz Speed 1800 r pm Power Factor 0.8 Aux. AC Power Single Phase, 60 Hz Aux. Voltage/Output 120 VAC/ 4.8 Kw (2.
DCA-600SSV — DIMENSIONS (TOP, SIDE AND FRONT) C E D B TOP VIEW A G F H Figure 1. Dimensions 600 SIDE VIEW I REAR VIEW (CONTROL PANEL VIEW) J TABLE 3. DIMENSIONS Reference Letter Dimension in. (mm.) Reference Letter Dimension in. (mm.) A 26.97 in. (685 mm.) G 17.32 in. (440 mm.) B 27.36 in. (695 mm.) H 39.37 in. (1,000 mm.) C 39.37 in. (1,000 mm.) I 185.04 in. (4,700 mm.) D 17.32 in. (440 mm.) J 78.9 in. (2,005 mm.) E 38.98 in. (990 mm.) K 65 in. (1,651 mm.) F 38.98 in.
DCA-600SSV — SAFETY MESSAGE ALERT SYMBOLS FOR YOUR SAFETY AND THE SAFETY OF OTHERS! Safety precautions should be followed at all times when operating this equipment. Failure to read and understand the Safety Messages and Operating Instructions could result in injury to yourself and others. NOTE This Owner's Manual has been developed to provide complete instructions for the safe and efficient operation of the MQPower M o d e l DCA-6 00SSV WHISPERWATT™ GENERATOR.
DCA-600SSV — SAFETY MESSAGE ALERT SYMBOLS WARNING - ROTATING PARTS NEVER operate equipment with covers, or guards removed. Keep fingers, hands, hair and clothing away from all moving parts to prevent injury. CAUTION - ACCIDENTAL STARTING ALWAYS place the Engine ON/OFF switch in the OFF position and remove the ignition key when the pump is not in use. CAUTION - OVER-SPEED CONDITIONS NEVER tamper with the factory settings of the engine governor or settings.
DCA-600SSV — RULES FOR SAFE OPERATION DANGER - READ THIS MANUAL! Failure to follow instructions in this manual may lead to serious injury or even DEATH! This equipment is to be operated by trained and qualified personnel only! This equipment is for industrial use only. The following safety guidelines should always be used when operating the DCA-600SSV Whisperwatt™ Generator. General Safety: ■ DO NOT operate or service this equipment before reading this entire manual.
DCA-600SSV — RULES FOR SAFE OPERATION Generator Grounding To guard against electrical shock and possible damage to the equipment, it is important to provide a good EARTH ground. Article 250 (Grounding) of the National Electrical Code (NEC) provides guide lines for proper grounding and specifies that the cable ground shall be connected to the grounding system of the building as close to the point of cable entry as practical.
DCA-600SSV— RULES FOR SAFE OPERATION Maintenance Safety Battery Safety ■ The electrical voltage required to operate the generator can cause severe injury or even death through physical contact with live circuits. Turn all circuit breakers OFF before performing maintenance on the generator. Use the following guidelines when handling the battery: ■ NEVER lubricate components or attempt service on a running machine.
DCA-600SSV — RULES FOR SAFE OPERATION ■ The maximum speed for highway towing is 55 MPH unless posted otherwise. Recommended off-road towing To reduce the possibility of an accident while transporting is not to exceed 15 MPH or less depending on type of the generator on public roads, always make sure the trailer terrain. that supports the generator and the towing vehicle are in good operating condition and both units are mechanically ■ Place chock blocks underneath wheel to prevent rolling, sound.
DCA-600SSV — GENERATOR DECALS Machine Safety Decals The DCA-600SSV generator is equipped with a number of safety decals. These decals are provided for operator safety and maintenance information. The illustrations below and on the preceding pages shows the decals as they appear on the machine. Should any of these decals become unreadable, replacements can be obtained from your dealer. Figure 2. Generator Decals PAGE 14 — DCA-600SSV — OPERATION AND PARTS MANUAL — REV.
DCA-600SSV — GENERATOR DECALS Figure 2. Generator Decals DCA-600SSV — OPERATION AND PARTS MANUAL — REV.
DCA-600SSV — GENERATOR DECALS Figure 2. Generator Decals PAGE 16 — DCA-600SSV — OPERATION AND PARTS MANUAL — REV.
DCA-600SSV — GENERATOR DECALS Figure 3. Generator Decals DCA-600SSV — OPERATION AND PARTS MANUAL — REV.
DCA-600SSV — INSTALLATION DCA-600SSV — INSTALLATION Figure 4. Typical Generator Grounding Application PAGE 18 — DCA-600SSV — OPERATION AND PARTS MANUAL — REV.
DCA-600SSV — INSTALLATION Outdoor Installation Generator Grounding Install the generator in a area that is free of debris , bystanders, and overhead obstructions. Make sure the generator is on secure level ground so that it cannot slide or shift around. Also install the generator in a manner so that the exhaust will not be discharged in the direction of nearby homes. To guard against electrical shock and possible damage to the equipment, it is important to provide a good EARTH ground.
DCA-600SSV — GENERAL INFORMATION DCA-600SSVWhisperwatt™ Series Familiarization Generator The MQ Power Model DCA-600SSV is a 528 kW generator (Figure 5) that is designed as a high quality portable (requires a trailer for transport) power source for telecom sites, lighting facilities, power tools, submersible pumps and other industrial and construction machinery.
DCA-600SSV — MAJOR COMPONENTS DCA-600SSV — MAJOR COMPONENTS Table 4. Generator Major Components ITEM NO. DESCRIPTION 1 Enclosure Assembly 2 Air Cleaner Assembly 3 Muffler Assembly 4 Fuel Tank Assembly 5 Engine and Radiator Assembly 6 Battery Assembly 7 Generator Assembly 8 Output Terminal Assembly 9 Generator Control Panel Assembly 10 Engine Operating Panel Assembly Figure 5. Major Components DCA-600SSV — OPERATION AND PARTS MANUAL — REV.
DCA-600SSV — GENERATOR CONTROL PANEL 2 1 3 4 5 10 11 12 13 14 AUTO MANUAL OFF/RESET A HZ V LOW OIL PRESSURE HIGH COOLANT TEMPERATURE OVERCRANK OVERSPEED ENGINE RUNNING MOOOOO-20001Q 7 6 8 9 Figure 6. Generator Control Panel The definitions below describe the controls and functions of the DCA-600SSV " Control Panel " (Figure 6). 1. Pilot Lamp – Indicates that the generator is working properly. 2. Panel Light – Normally used in dark areas or at night time.
DCA-600SSV — GENERATOR CONTROL PANEL 10. Circuit Breaker OFF Lamp – When the circuit breaker ON switch is placed in the OFF position this lamp will be turned OFF. If the generator is to be connected to a building’s AC power source via an automatic transfer switch (isolation), place the switch in the AUTO position. In this position, should an outage occur, the automatic transfer switch (ATS) will start the generator automatically via the generator’s auto-start contacts connected to the ATS’s start contacts.
DCA-600SSV — ENGINE OPERATING PANEL 1 5 6 7 3 BATTERY SWITCH WATER TEMP. OIL PRESS. FUEL LEVEL CHARGE AIR FILTER 4 PRE-HEAT LAMP EMERGENCY ENGINE SPEED STOP HIGH ON OFF TACHOMETER LOW PRE-HEAT BUTTON 11 2 8 9 Figure 7. Engine Operating Panels PAGE 24 — DCA-600SSV — OPERATION AND PARTS MANUAL — REV.
DCA-600SSV — ENGINE OPERATING PANEL The definitions below describe the controls and functions of the DCA-600SSV " Engine Operating Panels " (Figure 7). 3. Pre-Heat Lamp – Indicates that the glow plugs of the diesel engine are hot and the engine is ready to be started. 1. 4. Emergency Stop Button – Push this button inward to stop the engine in the event of an emergency. DO NOT use this button as a normal means of stopping the engine. 5.
DCA-600SSV — OUTPUT TERMINAL FAMILIARIZATION Output Terminal Familiarization The “Output Terminal Panel ” (Figure 8) is provided with the following: Three 240/139V output receptacles, 50 amp Output Terminal Panel Shown below (Figure 8) is the Output Terminal Panel , lift up on the cover to gain access to receptacles and terminal lugs. Three AUX.
DCA-600SSV — OUTPUT TERMINAL PANEL FAMILIARIZATION 120 VAC GFCI Receptacles There are two 120 VAC, 20 amp GFCI (Duplex Nema 5-20R) recepacles provided on the output terminal panel. These receptacles can be accessed in any voltage change-over board position. Each receptacle is protected by a 20 amp circuit breaker. These breakers are located directly above the GFCI receptacles. Remember the load output (current) of both GFCI receptacles is dependent on the load requirements of the UVWO terminals.
DCA-600SSV — OUTPUT TERMINAL PANEL FAMILIARIZATION Connecting Loads Loads can be connected to the generator by the UVWO terminal lugs or the convenience receptacles. (See Figure 12). Make sure to read the operation manual before attempting to connect a load to the generator. To protect the UVWO output terminals from overload, a 3pole, 1,600 amp, main circuit breaker is provided. Make sure to switch ALL circuit breakers to the "OFF" position prior to starting the engine.
DCA-600SSV— LOAD APPLICATION Single Phase Load Always be sure to check the nameplate on the generator and equipment to insure the wattage, amperage and frequency requirements are satisfactorily supplied by the generator for operating the equipment. Generally, the wattage listed on the nameplate of the equipment is its rated output. Equipment may require 130— 150% more wattage than the rating on the nameplate, as the wattage is influenced by the efficiency, power factor and starting system of the equipment.
DCA-600SSV — GENERATOR OUTPUTS Generator Output Voltages A wide range of voltages are available to supply voltage for many different applications. Voltages are selected by applying jumpers (6) to the voltage change-over board (Figure 15). To obtain some of the voltages as listed in Table 7 (see below) will require a fine adjustment using the voltage regulator (VR) control knob located on the control panel.
DCA-600SSV — GENERATOR OUTPUTS/GAUGE READING How to Read the AC Ammeter and AC Voltage Gauges. The AC ammeter and AC voltmeter gauges are controlled by the Ac ammeter and AC voltmeter change-over switches. Both of these switches are located on the generator control panel and DO NOT effect the generator output. They are provided to help observe how much power is being supplied, produced at the UVWO terminals lugs.
DCA-600SSV — OUTPUT TERMINAL PANEL CONNECTIONS UVWO Terminal Output Voltages Various output voltages can be obtained using the UVWO output terminal lugs. The voltages at the terminals are dependent on the placement of the jumpers plates (6) on the Voltage Change-Over Board and the adjustment of the Figure 22. Voltage Regulator Knob Voltage Regulator Control Knob. 1Ø-240V UVWO Terminal Output Voltages Remember the voltage change-over board determines the 1.
DCA-600SSV — OUTPUT TERMINAL PANEL CONNECTIONS 3Ø-480V UVWO Terminal Output Voltages 1Ø-480V UVWO Terminal Output Voltages 1. Jumper the voltage change-over board for 480V operation 1. Make sure the voltage change-over board is jumpered as shown in Figure 25. This configuration uses 6 jumper for 480V operation as shown in Figure 25. plates in 3 different positions. Remember there are 2 2. Connect the load wires to the UVWO terminals as shown jumper plates at every position.
DCA-600SSV — SETUP Fuel Check Circuit Breakers To protect the generator from an overload, a 3-pole, 1600 amp, main circuit breaker is provided to protect the UVWO output terminals from overload. In addition two single-pole, 20 amp GFCI circuit breakers are provided to protect the GFCI receptacles from overload. Three 50 amp load circuit breakers have also been provided to protect the auxiliary receptacles from overload.
DCA-600SSV — SETUP CAUTION - TRAILER FUEL TANK ALWAYS! fill trailer tank first with #2 diesel fuel, before filling secondary internal tank. INTERNAL SECONDARY TANK DIESEL FUEL INTERNAL FUEL TANK SIGHT GAUGE Full 3/4 1/2 1/4 Empty Figure 31. Skid Type Fuel Tank System Refueling Procedure: WARNING - RESPIRATORY HAZARDS ALWAYS! FILL THE TRAILER FUEL TANK FIRST, BEFORE FILLING INTERNAL FUEL TANK DIESEL FUEL Diesel fuel and its vapors are dangerous to your health and the surrounding environment.
DCA-600SSV — SETUP 3. NEVER overfill trailer fuel tank – It is important to read the trailer fuel gauge when filling trailer fuel tank. DO NOT wait for fuel to rise in filler neck. See Figure 34. 5. Figure 34. Full Trailer Tank Figure 36. Full Fuel System 6. CAUTION - REFUELING THE GENERATOR Figure 36 below reflects a full fuel system. Fuel from the engine return line will drain into the secondary internal fuel tank.
DCA-600SSV— SETUP Coolant (Ethylane Glycol [Green] / Water — 50/50 mix) Use only drinkable tap water. If hard water or water with many impurities is used, the inside of the engine and radiator may become coated with deposits and cooling efficiency will be reduced. An anticorrosion additive added to the water will help prevent deposits and corrosion in the cooling system. See the engine manual for further details.
DCA-600SSV— SETUP Battery This unit is of negative ground DO NOT connect in reverse. Always maintain battery fluid level between the specified marks. Battery life will be shortened, if the fluid level are not properly maintained. Add only distilled water when replenishment is necessary. When connecting battery do the following: DO NOT over fill. Check to see whether the battery cables are loose. Poor contact may result in poor starting or malfunctions. Always keep the terminals firmly tightened.
DCA-600SSV — GEN. START-UP PROCEDURE (MANUAL) BEFORE STARTING 3. Place the G.F.C.I. and aux. circuit breakers (Figure 42) in the “OFF” position prior to starting the engine. CAUTION - LETHAL EXHAUST HAZARD The engine's exhaust contains harmful emissions. ALWAYS have adequate ventilation when operating. Direct exhaust away from nearby personnel. If applicable perform the following: ■ Apply commercial power to the internal battery charger receptacle (to ensure good starting) via commercial power.
DCA-600SSV— GENERATOR START-UP PROCEDURE (MANUAL) 7. Set the battery ON/OFF switch (Figure 45) to the “ON” position. 12. Verify that the "Engine Running" status LED on the MPEC unit (Figure 50) is "ON" (lit) after the engine has been started. Figure 45. Battery ON/OFF Switch 8. Press and hold the engine preheat button (Figure 46) until the preheat lamp is lit (ON). Pre-Heat Lamp Pre-Heat Button Figure 50. Engine Running LED (ON) 13.
DCA-600SSV— GENERATOR START-UP PROCEDURE (MANUAL) 16. The ammeter (Figure 54) will indicate zero amps with no load applied. When a load is applied, the ammeter will indicate the amount of current that the load is drawing from the generator. 20. Press the main circuit breaker “ON” switch (Figure 58). Figure 58. Main Circuit Breaker ON Switch Figure 54. Ammeter (No Load) 17. The engine oil pressure gauge (Figure 55) will indicate the oil pressure (kg/ cm2) of the engine.
DCA-600SSV — GENERATOR START-UP PROCEDURE (AUTO MODE) 23. Observe the generator's ammeter (Figure 61) and verify it reads the anticipated amount of current with respect to the load. The ammeter will only display a current reading if a load is in use. When starting generator in AUTO mode use the "Manual Start-up" procedure except where noted (see below). 1. Perform steps 1 through 4 in the Before Starting section (page 38) as outlined in the Manual Starting Procedure. 2.
DCA-600SSV — GENERATOR SHUT-DOWN PROCEDURE WARNING - SHUTTING DOWN THE GENERATOR NEVER stop the engine suddenly except in an emergency. Emergency Shutdown Procedure 1. PUSH inward the emergency stop button located on the engine operating panel (Figure 67) to turn off the generator in the event of an emergency. Normal Shutdown Procedure To shutdown the generator use the following procedure: 1. Place both the GFCI and AUX circuit breakers as shown in Figure 42 to the OFF position. 2.
DCA-600SSV — MAINTENANCE 10 Hrs DAILY TABLE 14.
DCA-600SSV — MAINTENANCE Service Daily Fuel Tank Inspection If the engine is operating in very dusty or dry grass In addition to cleaning the fuel tank, the following components conditions, a clogged air cleaner will result. This can lead to should be inspected for wear: a loss of power, excessive carbon buildup in the combustion ■ Rubber Suspension – look for signs of wear or chamber and high fuel consumption. Change air cleaner deformity due to contact with oil.
DCA-600SSV — MAINTENANCE Air Removal WARNING - BURN HAZARDS If air enters the fuel injection system of a diesel engine, starting becomes impossible. After running out of fuel, or Allow engine to cool when flushing out after disassembling the fuel system, bleed the system radiator. Flushing the radiator while hot according to the following procedure. See the VOLVO Engine could cause serious burns from water or Manual for details. steam.
DCA-600SSV — MAINTENANCE Jacket Water Heater and Internal Battery Charger 120 VAC Input Receptacles (OPTIONAL) This generator can be optionally equipped with two 120 VAC, 20 amp input receptacles located on the output terminal panel. The purpose of these receptacles is to provide power via commercial power to the jacket water heater and internal battery charger. These receptacles will ONLY function when commercial power has been supplied to them (Figure 71).
DCA-600SSV —TRAILER BRAKES MAINTENANCE Electric Brakes Electrically actuated brakes (Figure 72) are similar to hydraulic brakes. The basic difference is that hydraulic brakes are actuated by an electromagnet. Listed below are some of the advantages that electric brakes have over hydraulic brakes: Brake system can be manually adjusted to provide the corrected braking capability for varying road and load conditions.
DCA-600SSV —TRAILER MAINTENANCE Tires/Wheels/Lug Nuts Tires and wheels are a very important and critical components of the trailer. When specifying or replacing the trailer wheels it is important the wheels, tires, and axle are properly matched. CAUTION - EYESIGHT HAZARD ALWAYS wear safety glasses when removing or installing force fitted parts. Failure to comply may result in serious injury. CAUTION - REPAIRING TRAILER WHEELS DO NOT attempt to repair or modify a wheel.
DCA-600SSV —TRAILER MAINTENANCE Lug Nut Torque Requirements It is extremely important to apply and maintain proper wheel mounting torque on the trailer. Be sure to use only the fasteners matched to the cone angle of the wheel. Proper procedure for attachment of the wheels is as follows: 1. Start all wheel lug nuts by hand. 2. Torque all lug nuts in sequence. See Figure 71. DO NOT torque the wheel lug nuts all the way down. Tighten each lug nut in 3 separate passes as defined by Table 17. 3.
DCA-600SSV — TRAILER-WIRING DIAGRAM Figure 72. Trailer Wiring Diagram (5-Pin) DCA-600SSV — OPERATION AND PARTS MANUAL — REV.
DCA-600SSV — TRAILER-WIRING DIAGRAM Figure 73. Trailer Wiring Diagram (7-Pin) PAGE 52 — DCA-600SSV — OPERATION AND PARTS MANUAL — REV.
DCA-600SSV —GENERATOR WIRING DIAGRAM DCA-600SSV — ENGINE WIRING DIA Figure 74. Generator Wiring Diagram DCA-600SSV — OPERATION AND PARTS MANUAL — REV.
DCA-600SSV — GENERATOR WIRING DIAGRAM (MAIN BREAKER) Figure 75. Main Circuit Breaker Wiring Diagram PAGE 54 — DCA-600SSV — OPERATION AND PARTS MANUAL — REV.
DCA-600SSV — ENGINE WIRING DIAGRAM Figure 76. Engine Wiring Diagram DCA-600SSV — OPERATION AND PARTS MANUAL — REV.
DCA-600SSV — TROUBLESHOOTING (ENGINE) Practically all breakdowns can be prevented by proper handling and maintenance inspections, but in the event of a breakdown, use Table 18 (Engine Troubleshooting) as a basic guideline for troubleshooting the engine. If the problem cannot be remedied, consult our company's business office or service plant. TABLE 18. ENGINE TROUBLESHOOTING SYMPTOM Engine does not start. POSSIBLE PROBLEM SOLUTION No fuel? Replenish fuel. Air in the fuel system? Bleed system.
DCA-600SSV — TROUBLESHOOTING (ENGINE) TABLE 18. ENGINE TROUBLESHOOTING (CONTINUED) SYMPTOM Engine revolution is not smooth. Either white or blue exhaust gas is observed. Either black or dark gray exhaust gas is observed. Deficient output. POSSIBLE PROBLEM SOLUTION Fuel filter clogged or dirty? Clean or change. Air cleaner clogged? Clean or change. Fuel leak due to loose injection pipe retaining nut? Tighten nut. Injection pump malfunctioning? Repair or replace.
DCA-600SSV — TROUBLESHOOTING (GENERATOR) Practically all breakdowns can be prevented by proper handling and maintenance inspections, but in the event of a breakdown, use Table 19 shown below for diagnosis of the Generator. If the problem cannot be remedied, consult our company's business office or service plant. TABLE 19. GENERATOR TROUBLESHOOTING SYMPTOM POSSIBLE PROBLEM SOLUTION AC Voltmeter defective? Check output voltage using a voltmeter. Is wiring connection loose? Check wiring and repair.
DCA-600SSV — TROUBLESHOOTING (ENGINE CONTROLLER) Practically all breakdowns can be prevented by proper handling and maintenance inspections, but in the event of a breakdown, use Table 20 (Engine Controller Troubleshooting) as a basic guideline for troubleshooting the Microprocessor Engine Controller unit (MPEC). If the problem cannot be remedied, consult our company's business office or service plant. TABLE 20. ENGINE CONTROLLER TROUBLESHOOTING (MPEC) Sympton Low oil pressure light is on.
DCA-600SSV— TROUBLESHOOTING (DIAGNOSTIC LAMP) The engine controller of this generator diagnoses problems that arise from the engine control system and the engine itself. The malfunction can be determined by examining the flashing pattern of the diagnostic lamp (Figure 79) located in the control box. Example Error Code 2. Figure 81 displays the error code for high temp intake. Figure 81.
NOTE PAGE DCA-600SSV — OPERATION AND PARTS MANUAL — REV.
DCA-600SSV— EXPLANATION OF CODE IN REMARKS COLUMN The following section explains the different symbols and remarks used in the Parts section of this manual. Use the help numbers found on the back page of the manual if there are any questions. The contents and part numbers listed in the parts section are subject to change without notice. Multiquip does not guarantee the availibility of the parts listed. PART NO. PART NAME QTY. 12345 BOLT ....................... 1 .... WASHER, 1/4 IN. ...........
DCA-600SSV — SUGGESTED SPARE PARTS DCA-600SSV w/SA6D170AE-1 VOLVO ENGINE 1 to 3 Units Qty. P/N Description 20 ............ 6125817032 ..................... AIR FILTER, INNER & OUTER 30 ............ 6003117111 ..................... FUEL FILTER 30 ............ 6002111231 ..................... OIL FILTER 2 .............. 6004111030 ..................... CARTRIDGE, CORROSION RESISTOR 1 .............. 0601810575 ..................... PILOT LAMP, ENGINE TROUBLE 1 .............. 0601810576 .....................
DCA-600SSV — GENERATOR ASSY. GENERATOR ASSY. PAGE 64 — DCA-600SSV — OPERATION AND PARTS MANUAL — REV.
DCA-600SSV — GENERATOR ASSY. GENERATOR ASSY.
DCA-600SSV — GENERATOR ASSY. (CONT.) GENERATOR ASSY. PAGE 66 — DCA-600SSV — OPERATION AND PARTS MANUAL — REV.
DCA-600SSV — GENERATOR ASSY. (CONT.) GENERATOR ASSY. NO 9 10 11 11A 11B 12 13 14 15 16 17 18 19 20 20A 21 22 23 24 24A 25 26 PART NO 7431310003 8461312004 0016308095 0040008000 0041208000 0010110016 0803000104 8461335003 8461334003 0017106012 0017106050 8461333003 0017106012 0343206170 0043606000 8461332003 0017106050 0605000012 0030020000 0040020000 C3164701404 0070506208 PART NAME COVER, BEARING GASKET, BEARING HEX. HEAD BOLT SPRING WASHER PLAIN WASHER HEX.
DCA-600SSV — CONTROL BOX ASSY. CONTROL BOX ASSY. PAGE 68 — DCA-600SSV — OPERATION AND PARTS MANUAL — REV.
DCA-600SSV — CONTROL BOX ASSY. CONTROL BOX ASSY.
DCA-600SSV — CONTROL BOX ASSY. (CONT.) CONTROL BOX ASSY. PAGE 70 — DCA-600SSV — OPERATION AND PARTS MANUAL — REV.
DCA-600SSV — CONTROL BOX ASSY. (CONT.) CONTROL BOX ASSY.
DCA-600SSV — CONTROL BOX ASSY. (CONT.) CONTROL BOX ASSY. PAGE 72 — DCA-600SSV — OPERATION AND PARTS MANUAL — REV.
DCA-600SSV — CONTROL BOX ASSY. (CONT.) CONTROL BOX ASSY. NO 74 75 76 77 78 79 80 81 82 83 84 85 PART NO 0605010502 8481814503 0017108020 C4214300904 0601850349 C4214301004 0017108020 C4214400404 8481825304 0017108020 0017110030 0017108020 PART NAME SNAP PIN COVER, CONTROL BOX HEX. HEAD BOLT SIDE PANEL, CONTROL BOX EMBEDDED PULLS SIDE PANEL, CONTROL BOX HEX. HEAD BOLT PANEL, CONTROL BOX PANEL, CONTROL BOX HEX. HEAD BOLT HEX. HEAD BOLT HEX. HEAD BOLT QTY.
DCA-600SSV — ENGINE AND RADIATOR ASSY. ENGINE AND RADIATOR ASSY. PAGE 74 — DCA-600SSV — OPERATION AND PARTS MANUAL — REV.
DCA-600SSV — ENGINE AND RADIATOR ASSY. ENGINE AND RADIATOR ASSY.
DCA-600SSV — ENGINE AND RADIATOR ASSY. (CONT.) ENGINE AND RADIATOR ASSY. PAGE 76 — DCA-600SSV — OPERATION AND PARTS MANUAL — REV.
DCA-600SSV — ENGINE AND RADIATOR ASSY. (CONT.) ENGINE AND RADIATOR ASSY. NO 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 PART NO 0150000018 0019206025 0130404000 0130204000 0602022291 C4322600004 C4322600104 0605515073 C4324100303 0019208025 0603325011 0602022293 0268800680 0268801560 0605515138 0191302200 0605515109 C4358300704 C4358300604 0012310030 0207010000 PART NAME O RING HEX. HEAD BOLT T-JOINT STREET ELBOW HOSE JOINT DRAIN HOSE DRAIN HOSE HOSE BAND BREATHER TANK HEX.
DCA-600SSV — ENGINE OPERATING PANEL ASSY. ENGINE OPERATING PANEL ASSY. PAGE 78 — DCA-600SSV — OPERATION AND PARTS MANUAL — REV.
DCA-600SSV — ENGINE OPERATING PANEL ASSY. ENGINE OPERATING PANEL ASSY.
DCA-600SSV — OUTPUT TERMINAL ASSY. OUTPUT TERMINAL ASSY. PAGE 80 — DCA-600SSV — OPERATION AND PARTS MANUAL — REV.
DCA-600SSV — OUTPUT TERMINAL ASSY. OUTPUT TERMINAL ASSY.
DCA-600SSV — OUTPUT TERMINAL ASSY. (CONT.) OUTPUT TERMINAL ASSY. PAGE 82 — DCA-600SSV — OPERATION AND PARTS MANUAL — REV.
DCA-600SSV — OUTPUT TERMINAL ASSY. (CONT.) OUTPUT TERMINAL ASSY. NO 32 32-1 33 34 35 36 3-A 36B 37 38 39 40 41 PART NO C3261600704 0221200150 0017106030 0601812598 0601812565 0027104015 0030004000 0041204000 C4237101203 06061851780 C4237102804 C4237400804 0017106016 PART NAME BRACKET, CIRCUIT BREAKER RUBBER CUSHION HEX. HEAD BOLT RECEPTACLE RECEPTACLE MACHINE SCREW HEX. NUT PLAIN WASHER COVER GROMMET COVER BRACKET HEX. HEAD BOLT QTY.
DCA-600SSV — BATTERY ASSY. BATTERY ASSY. PAGE 84 — DCA-600SSV — OPERATION AND PARTS MANUAL — REV.
DCA-600SSV — BATTERY ASSY. BATTERY ASSY. NO 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 PART NO 0168719052 C9109100704 0805007804 0805006504 0037808000 0040008000 0041208000 C5347600504 C4347601704 7432280504 C4347601904 C4347601804 0347010030 0208110000 0845040114 0845041004 PART NAME BATTERY BATTERY SHEET BATTERY BAND BATTERY BOLT WING NUT SPRING WASHER PLAIN WASHER BATTERY CABLE BATTERY CABLE BATTERY CABLE BATTERY CABLE EARTH CABLE HEX. HEAD BOLT HEX. NUT TERMINAL CAP (+) TERMINAL CAP (-) QTY.
DCA-600SSV — MUFFLER ASSY. MUFFLER ASSY. PAGE 86 — DCA-600SSV — OPERATION AND PARTS MANUAL — REV.
DCA-600SSV — MUFFLER ASSY. MUFFLER ASSY. NO 1 2 3 4 5 6 7 8 9 10 11 11A 11B 12 13 14 15 16 17 17A 17B 17C 18 19 20 21 22 23 PART NO C4331100802 0019210020 C4334200904 C4334200904 0019210030 0019208020 C4334000903 C4334001003 0602325009 C4334200504 0010116050 0040016000 0041216000 C4484100004 0012310025 0012310030 C4334103603 C3334200704 0010112050 0030012000 0040012000 0041212000 C4331301204 0019208025 C4331400204 0019210020 0603320132 0207310000 PART NAME MUFFLER HEX. HEAD BOLT PACKING PACKING HEX.
DCA-600SSV — FUEL TANK ASSY. FUEL TANK ASSY. PAGE 88 — DCA-600SSV — OPERATION AND PARTS MANUAL — REV.
DCA-600SSV — FUEL TANK ASSY. FUEL TANK ASSY.
DCA-600SSV — ENCLOSURE #1 ASSY. ENCLOSURE #1 ASSY. PAGE 90 — DCA-600SSV — OPERATION AND PARTS MANUAL — REV.
DCA-600SSV — ENCLOSURE #1 ASSY. ENCLOSURE #1 ASSY.
DCA-600SSV — ENCLOSURE #1 ASSY. (CONT.) ENCLOSURE #1 ASSY. PAGE 92 — DCA-600SSV — OPERATION AND PARTS MANUAL — REV.
DCA-600SSV — ENCLOSURE #1 ASSY. (CONT.) ENCLOSURE #1 ASSY. NO 35 35A 35B 35C 36 37 37A 38 39 40 41 42 43 44 45 46 47 PART NO 0010120065 0030020000 0040020000 0041220000 C4434200103 0017108020 0207008000 C2367700404 0019208020 C4464102903 C4464103003 C4464103103 0207108000 8452023004 0019208020 0019208020 C4464502404 PART NAME HEX. HEAD BOLT HEX. NUT SPRING WASHER PLAIN WASHER COVER HEX. HEAD BOLT HEX. NUT COVER HEX. HEAD BOLT ROOF PANEL ROOF PANEL ROOF PANEL HEX. NUT COVER HEX. HEAD BOLT HEX.
DCA-600SSV — ENCLOSURE #2 ASSY. ENCLOSURE #2 ASSY. PAGE 94 — DCA-600SSV — OPERATION AND PARTS MANUAL — REV.
DCA-600SSV — ENCLOSURE #2 ASSY. ENCLOSURE #2 ASSY.
DCA-600SSV — ENCLOSURE #2 ASSY. (CONT.) ENCLOSURE #2 ASSY. PAGE 96 — DCA-600SSV — OPERATION AND PARTS MANUAL — REV.
DCA-600SSV — ENCLOSURE #2 ASSY. (CONT.) ENCLOSURE #2 ASSY. NO 42 42A 43 43A 44 45 45A 46 47 47A 48 48A 49 50 51 51-1 52 53 54 55 56 PART NO C4464202403 C4494501604 C4464202503 C4494501604 C4464501804 C4464502304 C4494501604 0207008000 C4464502204 C4494501704 C4464502104 C4494501704 0017108020 0019208020 C4374200503 0310000520 0017108020 C3374200104 0017108020 0019210025 C4464502504 PART NAME ROOF PANEL ACOUSTIC SHEET ROOF PANEL ACOUSTIC SHEET GUTTER PANEL ACOUSTIC SHEET HEX.
DCA-600SSV — ENCLOSURE #3 ASSY. ENCLOSURE #3 ASSY. PAGE 98 — DCA-600SSV — OPERATION AND PARTS MANUAL — REV.
DCA-600SSV — ENCLOSURE #3 ASSY. ENCLOSURE #3 ASSY.
DCA-600SSV — RUBBER SEAL ASSY. RUBBER SEAL ASSY. PAGE 100 — DCA-600SSV — OPERATION AND PARTS MANUAL — REV.
DCA-600SSV — RUBBER SEAL ASSY. RUBBER SEAL ASSY. NO 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 PART NO 0229201650 0228901440 0228901670 0228901020 0228901610 0228900960 0228801610 0228800860 0228801380 0229201490 0229200780 0229200595 0228100500 0228100270 0228100580 0228100140 PART NAME RUBBER SEAL RUBBER SEAL RUBBER SEAL RUBBER SEAL RUBBER SEAL RUBBER SEAL RUBBER SEAL RUBBER SEAL RUBBER SEAL RUBBER SEAL RUBBER SEAL RUBBER SEAL RUBBER SEAL RUBBER SEAL RUBBER SEAL RUBBER SEAL QTY.
DCA-600SSV — NAMEPLATE AND DECALS NAME PLATE AND DECALS PAGE 102 — DCA-600SSV — OPERATION AND PARTS MANUAL — REV.
DCA-600SSV — NAMEPLATE AND DECALS NAME PLATE AND DECALS NO 1-1 1-2 2-1 2-2 2-3 2-4 2-5 2-6 2-7 2-8 2-9 2-10 2-11 2-12 2-13 2-14 2-15 2-16 2-17 3-1 3-2 3-3 3-4 3-5 3-6 4-1 4-2 4-3 4-4 4-5 5-1 5-2 5-3 5-4 5-5 5-6 5-7 5-8 5-9 6-1 6-2 6-3 PART NO C3551002303 C9522100003 0800520100 0800520904 0800520814 0800564004 0800565004 0840624504 0840624604 0840624704 0840624804 B9531100604 C3551001004 C3551003204 C4561101903 C9502400004 C9521007004 C9521203003 Z0110001504 6360610304 6360620204 B9504000404 B9504100104 C65
DCA-600SSV — NAMEPLATE AND DECALS (CONT.) NAME PLATE AND DECALS PAGE 104 — DCA-600SSV — OPERATION AND PARTS MANUAL — REV.
DCA-600SSV — NAMEPLATE AND DECALS (CONT.) NAME PLATE AND DECALS NO 7-1 7-2 8-1 8-2 8-3 8-4 9-1 9-2 9-3 9-4 9-5 9-6 9-7 9-8 9-8A 9-9 9-10 9-11 9-12 9-13 9-14 9-15 9-16 9-17 PART NO B9504200004 B9511100204 1320620904 6360620004 0840607104 B9504500004 0800615102 1320610603 1320621504 0840625902 B9504000304 B9521100404 B9531100604 0600500090 0021106016 C4561101603 C4561102503 C4561102303 C4561102204 C4561102604 C4561102104 C4561102403 C4561102003 C4561102704 PART NAME QTY.
