OPERATION AND PARTS MANUAL SERIES MODEL MVC-88GH/GHW ONE-WAY PLATE COMPACTOR (HONDA GX160K1QMX2 GASOLINE ENGINE) Revision #5 (01/11/11) To find the latest revision of this publication, visit our website at: www.multiquip.com THIS MANUAL MUST ACCOMPANY THE EQUIPMENT AT ALL TIMES.
PROPOSITION 65 WARNING l PAGE 2 — MVC88GH/GHW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV.
NOTES MVC88GH/GHW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV.
TABLE OF CONTENTS Multiquip —MVC88GH/GHW Plate Compactor Proposition 65 Warning ............................................. 2 Table Of Contents ..................................................... 4 Parts Ordering Procedures ....................................... 5 Safety Information ................................................ 6-10 Specifications (Compactor/Engine) ........................ 11 General Information ................................................ 12 Components (Plate Compactor) ......
www.multiquip.com PARTS ORDERING PROCEDURES Ordering parts has never been easier! Choose from three easy options: Order via Internet (Dealers Only): Best Deal! Effective: January 1st, 2006 If you have an MQ Account, to obtain a Username and Password, E-mail us at: parts@multiquip. com. Order parts on-line using Multiquip’s SmartEquip website! ■ View Parts Diagrams ■ Order Parts ■ Print Specification Information To obtain an MQ Account, contact your District Sales Manager for more information.
SAFETY INFORMATION Do not operate or service the equipment before reading the entire manual. Safety precautions should be followed at all times when operating this equipment. Failure to read and understand the safety messages and operating instructions could result in injury to yourself and others. Potential hazards associated with the operation of this equipment will be referenced with hazard symbols which may appear throughout this manual in conjunction with safety messages.
SAFETY INFORMATION GENERAL SAFETY CAUTION NEVER operate this equipment without proper protective clothing, shatterproof glasses, respiratory protection, hearing protection, steel-toed boots and other protective devices required by the job or city and state regulations. NEVER operate this equipment when not feeling well due to fatigue, illness or when under medication. NEVER operate this equipment under the influence of drugs or alcohol.
SAFETY INFORMATION COMPACTOR SAFETY DANGER NEVER operate the equipment in an explosive atmosphere or near combustible materials. An explosion or fire could result causing severe bodily harm or even death. WARNING NEVER disconnect any emergency or safety devices. These devices are intended for operator safety. Disconnection of these devices can cause severe injury, bodily harm or even death. Disconnection of any of these devices will void all warranties.
SAFETY INFORMATION FUEL SAFETY BATTERY SAFETY (ELECTRIC START ONLY) DANGER DANGER DO NOT add fuel to equipment if it is placed inside truck bed with plastic liner. Possibility exists of explosion or fire due to static electricity. FUEL DO NOT drop the battery. There is a possibility that the battery will explode. DO NOT expose the battery to open flames, sparks, cigarettes, etc. The battery contains combustible gases and liquids.
SAFETY INFORMATION TRANSPORTING SAFETY CAUTION NEVER allow any person or animal to stand underneath the equipment while lifting. NOTICE Before lifting, make sure that the equipment parts (hook and vibration insulator) are not damaged and screws are not loose or missing. Always make sure crane or lifitng device has been properly secured to the lifting bail (hook) of the equipment. ALWAYS shutdown engine before transporting. NEVER lift the equipment while the engine is running.
SPECIFICATIONS TABLE 1. Specifications (Compactor) Models MVC-88GH/MVC-88GHW Centrifugal Force 3,450 lbs. (1,564.9 kg) Number of Vibrations 5,800 vibrations/min Traveling Speed 72 ft./min (22 meters/min) Plate Size (LxW) 19.7 x 20.7 in. .500 x .525 mm Operating Weight (GW) Operating Weight (GHW) 183 lbs. (83.0 kg.) 212 lbs. ( 96.2 kg.) Fuel Tank Capacity 3.8 qt. (3.6 liters) Water Tank Capacity GHW Model Only 13.7 qt. (13.0 liters) Max. Area Of Compaction 7092 sq. ft./hr. Table 2.
GENERAL INFORMATION Definition of Plate Compactor Frequency/Speed The Mikasa MVC-88GH/GHW is a walk behind, plate compactor designed for the compaction of sand, mixed soils and asphalt. This plate compactor is a powerful compacting tool capable of applying a tremendous force in consecutive high frequency vibrations to a soil surface. Its applications include compacting for road, embankments and reservoirs as well as backfilling for gas pipelines, water pipelines and cable installation work.
COMPONENTS Figure 1. Plate Compactor Controls Figures 1 shows the location of the basic controls and components of the MVC-88 Plate Compactor. The function of each control is described below: 6. Belt Cover – Remove this cover to gain acess to the Vbelts. NEVER run the compactor without the V-belt cover. If the V-belt cover is not installed, the possibility exist that your hand may get caught between the V-belt and clutch, thus causing serious injury and bodily harm. 1.
BASIC ENGINE Figure 2. Engine Controls & Components INITIAL SERVICING 5. The engine (Figure 2) must be checked for proper lubrication and filled with fuel prior to operation. Refer to the manufacturers Engine manual for instructions & details of operation and servicing. Fuel Valve Lever – OPEN to let fuel flow, CLOSE to stop the flow of fuel. 6. Choke Lever – Used in the starting of a cold engine, or in cold weather conditions. The choke enriches the fuel mixture. 1. 7.
INSPECTION 3. Insert and remove the dipstick without screwing it into the filler neck. Check the oil level shown on the dipstick. CAUTION NEVER operate the unit in a confined area or enclosed area structure that does not provide ample free flow of air. 4. If the oil level is low (Figure 4), fill to the edge of the oil filler hole with the recommended oil type (Table 3). Maximum oil capacity is 0.63 quarts (0.60 liters) CAUTION ALWAYS wear approved eye and hearing protection before operating the unit.
INSPECTION 2. The V-belt tension is proper if the V-belt bends 10 to 15 mm (Figure 7) when depressed with finger at midway between the clutch and vibration pulley shafts. V-Belt Check CAUTION NEVER attempt to check the V-belt with the engine running. Severe injury can occur of your hand (Figure 5) gets caught between the V-belt and the clutch. Always use safety gloves. CLUTCH PULLEY Figure 7. V-Belt Tension VIBRATOR PULLEY Figure 5. V-Belt Hazard 1.
OPERATION NOTICE CAUTION DO NOT attempt to operate the compactor until the Safety, General Information and Inspection sections of this manual have been read and thoroughly understood. The CLOSED position of the choke lever enriches the fuel mixture for starting a COLD engine. The OPEN position provides the correct fuel mixture for normal operation after starting, and for restarting a warm engine. 1. Place the fuel valve lever (Figure 9) in the "ON" position. 4.
OPERATION 6. If the engine has started, slowly return the choke lever (Figure 11) to the CLOSED position. If the engine has not started repeat steps 1 through 5. 7. Before the compactor is put into operation run the engine for 3-5 minutes. Stopping the Engine CAUTION NEVER stop the engine suddenly while working at high speeds. 8. Check for abnormal engine noises or fuel leaks.
MAINTENANCE CAUTION CAUTION These inspection intervals are for operation under normal conditions. Adjust your inspection intervals based on the number hours plate compactor is in use, and particular working conditions. Inspection and other services should always be carried out on hard and level ground with the engine shutdown. Inspection and Maintenance Service Tables. 1.
MAINTENANCE ENGINE OIL TABLE 5. MACHINE INSPECTION Item 1. Drain the engine oil when the oil is warm as shown in Figure 14. Hours of Operation (Starting check) Every 8 hours (every day) Loosened or lost screws Every 8 hours (every day) Damage of any part Every 8 hours (every day) Function of controlling system part Every 8 hours (every day) Vibrator oil check Every 100 hours Vibrator oil replacement Every 200 hours V-belt (clutch) check Every 200 hour 2.
MAINTENANCE Checking and Replacing the V-Belt and Clutch 1. After 200 hours of operation, remove the upper belt cover to check the V-belt tension. Tension is proper if the belt bends about 10 mm when depressed strongly with finger between shafts. Loose or worn V-belts reduces power transmission efficiency, causing weak compaction and reduces the life of the belt itself.
LONG -TERM STORAGE Plate Compactor Storage For storage of the plate compactor for over 30 days, the following is required: ■ Drain the fuel tank completelyor add STA-BIL to the fuel. ■ Run the engine until the fuel is completely consumed. ■ Completely drain the oil from the engine crankcase and follow procedures described in the HONDA engine Owner's Manual for engine storage. ■ Completely drain the compactor's hydraulic oil from the vibrating case.
TROUBLESHOOTING Practically all breakdowns can be prevented by proper handling and maintenance inspections, but in the event of a breakdown, please take a remedial action following the diagnosis based on the Engine , and Compactor Troubleshooting (Tables 7, and 8) information shown below and on the proceeding pages. If the problem cannot be remedied, please leave the unit just as it is and consult or company's service department. TABLE 7.
TROUBLESHOOTING TABLE 7. ENGINE TROUBLESHOOTING (CONTINUED) SYMPTOM "Weak in power" compression is proper and does not misfire. POSSIBLE CAUSE SOLUTION Air cleaner not clean? Clean or replace air cleaner Improper level in carburetor? Check float adjustment, re-build carbureator. Defective Spark plug? Clean or replace spark plug. Defective Spark plug? "Weak in power" compression is proper but misfires. Engine overheats. Rotational speed fluctuates. Recoil star ter malfunction.
NOTENOTES PAGE MVC88GH/GHW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV.
EXPLANATION OF CODE IN REMARKS COLUMN The following section explains the different symbols and remarks used in the Parts section of this manual. Use the help numbers found on the back page of the manual if there are any questions. NOTICE The contents and part numbers listed in the parts section are subject to change without notice. Multiquip does not guarantee the availability of the parts listed. SAMPLE PARTS LIST NO. 1 2% 2% 3 4 PART NO. PART NAME QTY. REMARKS 12345 BOLT......................1 .....
SUGGESTED SPARE PARTS MVC-88GH/GW 1 TO 5 UNITS WITH HONDA GX160K1QMX2 ENGINE 1 to 5 Units Qty. P/N Description 3 ......... o70100332 ....... V-BELT 1 ......... 060403060 ....... OIL SEAL, VIBRATING 2 ......... 050101000 ....... O-RING 5 ......... 9807956841 ..... SPARK PLUG 1 ......... 28462ZH8003 .. ROPE, RECOIL STARTER 1 ......... 36100ZE1015 .. SWITCH ASSY, ENGINE STOP 5 ......... 17210ZE1822 .. ELEMENT, A/C 1 ......... 17620ZH7023 .. CAP, FUEL TANK 1 ......... 17672ZE2W01 . FUEL FILTER, FUEL TANK 4 ...
NAME PLATE AND DECALS l PAGE 28 — MVC88GH/GHW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV.
NAME PLATE AND DECALS NO 1 2 3 4 5 6 7 8 9 10 11 PART NO 920206290 920203290 920208450 920203060 920208350 920201580 920106460 920201950 920101410 920203330 PART NAME QTY. REMARKS DECAL, READ OWNERS MANUAL ....... 1 ........ NPA-629 DECAL, CAUTION ................................. 1 ........ NPA-329 DECAL, LIFTING ................................... 1 ........ NPA-845 DECAL, CAUTION (START ENG/VIBR) . 1 ........ NPA-306 DECAL, V- BELT RPF-3330 ................... 1 ........ NPA-835 DECAL, MQ LOGO ........
BODY ASSY. l PAGE 30 — MVC88GH/GHW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV.
BODY ASSY.
VIBRATOR ASSY. l PAGE 32 — MVC88GH/GHW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV.
VIBRATOR ASSY.
SPRINKLER ASSY. l PAGE 34 — MVC88GH/GHW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV.
SPRINKLER ASSY. NO 111 111A * 112 * 113 * 114 * 115 * 116 * 117 * 118 * 119 * 120 * 121 # * 122 # * 123 # * 124 # * 125 # * PART NO 4169100109 416910010 033910050 953406390 954403241 416338930 416338940 416452750 001740825 416453780 416452790 954300340 001241030 033910010 022910180 416453800 PART NAME QTY. REMARKS WATER TANK ASSY. .................... 1 ............... INCLUDES ITEMS W/ * WATER TANK (W/CAP ONLY) ...... 1 ............... REPLACES 416116010 INCLUDES ITEMS W/# WASHER 14.5X30X1.
TRANSPORT WHEEL ASSY. l PAGE 36 — MVC88GH/GHW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV.
TRANSPORT WHEEL ASSY. NO 1 2 3 4 5 6 PART NO 416116160 959404310 031120320 025203030 416454150 025403025 PART NAME WHEEL SHAFT WHEEL 150X42 WASHER, FLAT M20 SPLIT COTTER PIN 3X30 ROLLER SPRING PIN 3X25 QTY. 1 2 2 2 2 3 REMARKS MVC88GH/GHW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV.
CYLINDER HEAD ASSY. l PAGE 38 — MVC88GH/GHW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV.
CYLINDER HEAD ASSY. NO. 1 2 * 3 * 4 # * 5 6 6 7 8 9 10 11 12 14 15 15 PART NO. 12210ZH8020 12204ZE1306 12205ZE1315 12216ZE5300 12251ZF1800 12310ZE1010 12310ZE1020 12391ZE1000 15721ZH8000 90013883000 90043ZE1020 90047ZE1000 9430110160 957230806000 9807955846 9807956846 PART NAME QTY. REMARKS CYLINDER HEAD......................................... 1 ...... INCLUDES ITEMS W/ * GUIDE, VALVE (OS) (OPTIONAL) 1 GUIDE, EX. VALVE (OS) (OPTIONAL) ........ 1 ......
CYLINDER BARREL ASSY. l PAGE 40 — MVC88GH/GHW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV.
CYLINDER BARREL ASSY. NO. 2 3 3 4 5# 6# 8 10 11 12 13 14 * 15 * 16 17 18 19 20 PART NO. 12000ZH8811 15510ZE1023 15510ZE1033 16510ZE1000 16511ZE1000 16512ZE1000 16531ZE1000 90131ZE1000 90451ZE1000 90601ZE1000 90602ZE1000 91001ZF1003 91202883005 91353671003 9405010000 9410106800 9425108000 957010601200 PART NAME QTY. REMARKS CYLINDER ASSY. (OIL ALERT) ................... 1 ...... INCLUDES ITEMS W/ * SWITCH ASSY., OIL LEVEL ........................ 1 ...... USE UP TO ENGINE S/N 4367320 SWITCH ASSY.
CRANKCASE COVER ASSY. l PAGE 42 — MVC88GH/GHW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV.
CRANKCASE COVER ASSY. NO. 1 3 4 5 9# 10+ 11 * 12 13 14 * PART NO. 11300ZE1641 11381ZH8801 15600ZE1003 15600ZG4003 15625ZE1003 15625ZE1003 91202883005 9430108140 957010803200 961006205000 PART NAME QTY. REMARKS COVER ASSY., CRANKCASE (U-TYPE) ..... 1 ...... INCLUDES ITEMS W/ * GASKET, CASE COVER 1 CAP ASSY., OIL FILLER ............................. 1 ...... INCLUDES ITEMS W/# CAP ASSY., OIL FILLER ............................. 1 ......
CRANKSHAFT ASSY. l PAGE 44 — MVC88GH/GHW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV.
CRANKSHAFT ASSY. NO. 4 13 14 15 PART NO. 13310ZE1601 90003ZE1000 90473842000 90745ZE1600 PART NAME QTY. REMARKS CRANKSHAFT (Q-TYPE) 1 BOLT, HEX 5/16” ............................................ 1 .... USE FROM S/N 6745959 WASHER, 8 MM ............................................. 1 .... USE FROM S/N 6745959 KEY, 78 X 38 MM 1 MVC88GH/GHW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV.
PISTON/RINGS ASSY. l PAGE 46 — MVC88GH/GHW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV.
PISTON/RINGS ASSY. NO. 1 1 1 1 2 2 2 2 3 4 5 * 6 PART NO. 13010ZH8941 13011ZH8941 13012ZH8941 13013ZH8941 13101ZH8000 13102ZH8000 13103ZH8000 13104ZH8000 13111ZE1000 13200ZE1010 90001ZE1000 90551ZE1000 PART NAME QTY. REMARKS RING SET, PISTON (STD) 1 RING SET, PISTON (OS 0.25) 1 RING SET, PISTON (OS 0.50) ............. 1 ......... USE FROM ENGINE S/N 4733211 RING SET, PISTON (0.75) OPTION 1 PISTON (STD) 1 PISTON (OS 0.25) 1 PISTON (OS 0.50) 1 PISTON (0.75) 1 PIN, PISTON 1 ROD ASSY., CONNECTING ............
CAMSHAFT ASSY. l PAGE 48 — MVC88GH/GHW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV.
CAMSHAFT ASSY. NO. 1 2 3 4 5 6 * 7 8 9 10 11 12 13 14 15 PART NO. 14100ZE1812 14410ZE1010 14431ZE1000 14441ZE1010 14451ZE1013 14568ZE1000 14711ZF1000 14721ZF1000 14751ZF1000 14771ZE1000 14773ZE1000 14781ZE1000 14791ZE1010 90012ZE0010 90206ZE1000 PART NAME QTY. REMARKS CAMSHAFT ASSY. ...................................... 1 ...... INCLUDES ITEMS W/ * ROD, PUSH 2 ARM, VLAVE ROCKER 2 LIFTER, VALVE 2 PIVOT, ROCKER ARM 2 SPRING, WEIGHT RETURN 1 VALVE, IN. 1 VALVE, EX. (STELITE) 1 SPRING VALVE 2 RETAINER, IN.
RECOIL STARTER ASSY. l PAGE 50 — MVC88GH/GHW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV.
RECOIL STARTER ASSY. NO. 1 2 * 3 * 4 * 5 * 6 * 7 * 8 * 9 * 10 * 11 * 12 PART NO. 28400ZH8013ZB 28410ZH8003ZB 28420ZH8013 28422ZH8013 28433ZH8003 28441ZH8003 28442ZH8003 28443ZH8003 28461ZH8003 28462ZH8003 90003ZH8003 90008ZE2003 PART NAME QTY. REMARKS STARTER ASSY., RECOIL “NH1”(BLACK) ............ 1 .....
FAN COVER ASSY. l PAGE 52 — MVC88GH/GHW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV.
FAN COVER ASSY. NO. 2 4 7 8 11 11 13 14 17 19 PART NO. 19610ZE1000ZC 19612ZH8811 90601ZH7013 19630ZH8000 36100ZE1015 36100ZH7003 90013883000 90022888010 34150ZH7003 957010600800 PART NAME QTY. REMARKS COVER, FAN *NH1* (BLACK) 1 PLATE, SIDE (OIL ALERT) 1 CLIP, HARNESS 1 SHROUD 1 SWITCH ASSY., ENGINE STOP ........... 1.......... USE UP TO S/N 4368640 SWITCH ASSY., ENGINE STOP ........... 1..........
CARBURETOR ASSY. l PAGE 54 — MVC88GH/GHW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV.
CARBURETOR ASSY. NO. 1 2 * 3 * 4 * 5 * 6 * 7 * 8 * 9 * 10 * 11 * 12 * 13 14 15 16 17 18 * 19 * 20 * 21 * 22 * 23 * 24# 25 25 25 * 26 * PART NO. 16010ZE1812 16011ZE0005 16013ZE0005 16015ZE0831 16016ZH7W01 16024ZE1811 16028ZE0005 16044ZE0005 16100ZH8W51 16124ZE0005 16166ZH8W50 16173001004 16211ZE1000 16212ZH8800 16220ZE1020 16221ZH8801 16610ZE1000 16953ZE1812 16954ZE1811 16956ZE1811 16957ZE1812 16967ZE0811 93500030060H 9430520122 99101ZH80650 99101ZH80680 99101ZH80700 99204ZE00350 PART NAME QTY.
AIR CLEANER ASSY. l PAGE 56 — MVC88GH/GHW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV.
AIR CLEANER ASSY. NO. 1 2 3 * 4 5 * 6# 7# 8 9 10 11 13 PART NO. 16271ZE1000 17210ZE1505 17218ZE1505 17230ZE1820 17232891000 17238ZE7010 17239ZE1000 17410ZE1020 90201415000 17235ze1831 90325044000 957010602000 PART NAME QTY. REMARKS GASKET, ELBOW ........................................ 1 ...... INCLUDES ITEMS W/ * ELEMENT, AIR CLEANER (DUAL) 1 FILTER (OUTER) 1 COVER, AIR CLEANER (DUAL) 1 GROMMET, AIR CLEANER 1 COLLAR, AIR CLEANER 2 COLLAR B, AIR CLEANER 1 ELBOW, AIR CLEANER ...............................
MUFFLER ASSY. l PAGE 58 — MVC88GH/GHW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV.
MUFFLER ASSY. NO. 1 1 3 5 7 8 11 12 13 15 30 PART NO. 18310ZH8810 18310ZK8V50 18320ZF1H01 18331883810 18355ZE1000 18381ZH8800 90050ZE1000 90055ZE1000 18522ZE1000 94001080000S 90002ZG0003 PART NAME QTY. REMARKS MUFFLER..................................................... 1 ...... USE UP TO S/N 6745959 MUFFLER..................................................... 1 ......
FUEL TANK ASSY. l PAGE 60 — MVC88GH/GHW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV.
FUEL TANK ASSY. NO. 10 17 20 21 23 * 24 29 33 36 PART NO. 16854ZH8000 16955ZE1000 17510ZE1020ZF 17620ZH7023 17631ZH7003 17672ZE2W01 91353671003 9405006000 950014500360M 40 43 44 45 9500202080 957010602500 90404680000 91319ME5003 PART NAME QTY. REMARKS RUBBER, SUPPORTER (107MM) 1 JOINT, FUEL TANK 1 TANK, FUEL *NH1* (BLACK) 1 CAP, FUEL FILLER ...................................... 1 ...... INCLUDES ITEMS W/ * GASKET, FUEL FILLER CAP 1 FILTER, FUEL 1 O-RING (13.5 X 1.
COOLING FAN AND FLYWHEEL ASSY. l PAGE 62 — MVC88GH/GHW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV.
COOLING FAN AND FLYWHEEL ASSY. NO. 1 2 4 5 5 8 PART NO. 13331357000 19511ZE1000 28451ZH8003 31100ZE1010 31100ZE1810 90201878003 PART NAME KEY, SPECIAL WOODRUFF (25 X 18) FAN, COOLING PULLEY, STARTER FLYWHEEL FLYWHEEL (LAMP) NUT, SPECIAL (14MM) QTY. 1 1 1 1 1 1 REMARKS MVC88GH/GHW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV.
IGNITION COIL ASSY. l PAGE 64 — MVC88GH/GHW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV.
IGNITION COIL ASSY. NO. 1 2 7 11 PART NO. 30500ZE1033 30700ZE1013 36101ZE1010 90121952000 PART NAME COIL ASSY., IGNITION CAP ASSY., NOISE SUPPRESSOR WIRE, STOP SWITCH (370MM) BOLT, FLANGE (6 X 25) QTY. 1 1 1 2 REMARKS MVC88GH/GHW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV.
CONTROL ASSY. l PAGE 66 — MVC88GH/GHW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV.
CONTROL ASSY. NO. 2 4 5 6 7 9 * 10 * 11 * 12 * 13 * 14 * 15 * 16 * 17 * 21 22 24 * 25 * 26 * 27 * 28 * 29 PART NO. 16500ZH8813 16551ZE0010 16555ZE1000 16561ZE1020 16562ZE1020 16571ZH8020 16574ZE1000 16575ZH8000 16576891000 16578ZE1000 16580ZH8813 16584883300 16592ZE1810 16594883010 90013883000 90015ZE5010 90114SA0000 93500050250H 90605230000 93500040060H 93500050160A 9405006000 PART NAME QTY. REMARKS CONTROL ASSY. ......................................... 1 ......
GASKET KIT ASSY. NO ARTWORK AVAILABLE l PAGE 68 — MVC88GH/GHW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV.
GASKET KIT ASSY. NO. 1 2 * 3 * 4 * 5 * 6 * 7 * PART NO. 06111ZH8405 11381ZH8801 12251ZF1800 12391ZE1000 16212ZH8800 16221ZH8801 18381ZH8800 PART NAME QTY. REMARKS GASKET KIT ............................................. 1 .......... INCLUDES ITEMS W/ * GASKET, CASE COVER 1 GASKET, CYLINDER HEAD 1 GASKET, CYLINDER HEAD COVER 1 GASKET, INSULATOR 1 GASKET, CARBURETOR 1 GASKET, MUFFLER 1 MVC88GH/GHW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV.
LABELS ASSY. l PAGE 70 — MVC88GH/GHW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV.
LABELS ASSY. NO. 1 3 6 8 PART NO. 87521ZH8020 87522zh9010 87528ZE1810 87532ZH8810 PART NAME EMBLEM (5.5) LABEL, CAUTION MARK, CHOKE MARK, OIL ALERT (E) QTY. 1 1 1 1 REMARKS MVC88GH/GHW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV.
TERMS AND CONDITIONS OF SALE — PARTS PAYMENT TERMS 5. Parts must be in new and resalable condition, in the original Multiquip package (if any), and with Multiquip part numbers clearly marked. 6. The following items are not returnable: Multiquip reserves the right to quote and sell direct to Government agencies, and to Original Equipment Manufacturer accounts who use our products as integral parts of their own products. a. SPECIAL EXPEDITING SERVICE Terms of payment for parts are net 30 days.
NOTENOTES PAGE MVC88GH/GHW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV.
OPERATION AND PARTS MANUAL HERE’S HOW TO GET HELP PLEASE HAVE THE MODEL AND SERIAL NUMBER ON-HAND WHEN CALLING UNITED STATES Multiquip Corporate Office 18910 Wilmington Ave. Carson, CA 90746 Contact: mq@multiquip.com MQ Parts Department Tel.
