DCA250SSI/DCA250SSIU GENERATOR • OPERATION AND PARTS MANUAL — REV. #0 (01/12/11) — PAGE 73
OUTPUT TERMINAL ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 C2231700403 SET BOARD, OUTPUT TERMINAL ............1 ................DCA250SSI
1 M5230700003 SET BOARD, OUTPUT TERMINAL ............1 ................DCA250SSIU
2 C0277500004 OUTPUT TERMINAL ...................................8 ................DCA250SSI
2 M9220100914 OUTPUT TERMINAL ...................................8 ................DCA250SSIU
3 0801830904 HEX HEAD BOLT ........................................8 ................DCA250SSI
3 M9220101004 HEX HEAD BOLT ........................................8 ................DCA250SSIU
4 0039320000 HEX NUT 16
5 030220510 WASHER, LOCK 24
6 0041420000 WASHER, FLAT 32
7 3501860604 TERMINAL PLATE ......................................3 ................DCA250SSI
7 M5233200004 TERMINAL PLATE ......................................3 ................DCA250SSIU
8 0019210040 HEX HEAD BOLT 5
9 0601808803 CIRCUIT BREAKER, 1P 20A 2
10 0601808804 CIRCUIT BREAKER, 2P 50A 3
11 C3261600704 BRACKET, CIRCUIT BREAKER .................1 ................DCA250SSI
11 M4260600104 BRACKET, CIRCUIT BREAKER .................1 ................DCA250SSIU
11-1 0221200150 RUBBER CUSHION 1
12 011206020 HEX HEAD BOLT 2
13 0601814013 RECEPTACLE, GF20LA 2
14 0601811034 RECEPTACLE, CS-6369 3
15 0025304015 MACHINE SCREW 10
15A OEMAA8 HEX NUT 10
16 C2234500104 COVER ........................................................1 ................DCA250SSI
16 M4236400204 COVER ........................................................1 ................DCA250SSIU
17 011206020 HEX HEAD BOLT ........................................8 ................DCA250SSI
17 0019206015 HEX HEAD BOLT ........................................8 ................DCA250SSIU
18 0601815324 TERMINAL BOARD ....................................1 ................DCA250SSI
18 0601815194 TERMINAL BOARD ....................................1 ................DCA250SSIU
19 0025304015 MACHINE SCREW 2
20 0601850275 GROMMET 1
21 0601851780 GROMMET 2
21 0603306775 BLIND PLUG 2
22 C2237102303 COVER, OUTPUT TERMINAL ....................1
22 M5236100003 COVER, OUTPUT TERMINAL ....................1
23 012212045 HEX HEAD BOLT 2
24 031112230 WASHER, FLAT 2
25 0805009804 STAY RUBBER ............................................2 ................DCA25SSI
25 M9310200104 STAY RUBBER ............................................2 ................DCA25SSIU
