© COPYRIGHT 2003, MULTIQUIP INC. PARTS AND OPERATION MANUAL OPERATION AND PARTS MANUAL Tamping Rammer Model MT-62HS Revision #2 (12/15/03) MULTIQUIP INC.. PARTS DEPARTMENT: 18910 WILMINGTON AVE. 800-427-1244 CARSON, CALIFORNIA 90746 FAX: 800-672-7877 SERVICE DEPARTMENT/TECHNICAL ASSISTANCE: 310-537-3700 800-421-1244 800-478-1244 FAX: 310-537-3927 FAX: 310-631-5032 E-mail:mq@multiquip.com • www:multiquip.
PAGE 2 — MT-62HS — PARTS & OPERATION MANUAL — REV.
HERE'S HOW TO GET HELP PLEASE HAVE THE MODEL AND SERIAL NUMBER ON-HAND WHEN CALLING MULTIQUIP’S MAIN PHONE NUMBERS 800-421-1244 FAX: 310-537-3927 310-537-3700 PARTS DEPARTMENT 800-427-1244 FAX: 800-672-7877 310-537-3700 FAX: 310-637-3284 MAYCO PARTS 800-306-2926 FAX: 800-672-7877 310-537-3700 FAX: 310-637-3284 SERVICE DEPARTMENT 800-478-1244 FAX: 310-537-4259 310-537-3700 MQ POWER SERVICE DEPARTMENT 800-835-2551 FAX: 310-638-8046 310-537-3700 TECHNICAL ASSISTANCE 800-478-1244 FAX: 310-631-5032 WARRANTY DEPA
TABLE OF CONTENTS MT-62HS Tamping Rammer ROBIN EC-08HS ENGINE Here's How To Get Help ............................................3 Table Of Contents .....................................................4 Parts Ordering Procedures .......................................5 Safety Message Alert Symbols ............................. 6-7 Rules For safe Operation ..................................... 8-9 Operation and Safety Decals ..................................10 General Information ........................
PARTS ORDERING PROCEDURES When ordering parts, please supply the following information: ❒ ❒ ❒ ❒ ❒ ❒ ❒ Dealer account number Dealer name and address Shipping address (if different than billing address) Return fax number Applicable model number Quantity, part number and description of each part Specify preferred method of shipment: Note: Unless otherwise indicated by customer, all ✓ FedEx or UPS Ground orders are treated as “Standard Orders”, and will ✓ FedEx or UPS Second Day or Third Day ship within 24 hou
MT-62HS — SAFETY MESSAGE ALERT SYMBOLS FOR YOUR SAFETY AND THE SAFETY OF OTHERS! Safety precautions should be followed at all times when operating this equipment. Failure to read and understand the Safety Messages and Operating Instructions could result in injury to yourself and others. NOTE This Owner's Manual has been developed to provide complete instructions for the safe and efficient operation of the Multiquip MT-62HS Tamping Rammer.
MT-62HS — SAFETY MESSAGE ALERT SYMBOLS Accidental Starting ALWAYS place the engine ON/OFF switch in the OFF position, and remove the ignition key when the machine is not in use. Over Speed Conditions NEVER tamper with the factory settings of the engine governor or settings. Personal injury and damage to the engine or equipment can result if operating in speed ranges above maximum allowable.
MT-62HS — RULES FOR SAFE OPERATION DANGER: Failure to follow instructions in this manual may lead to serious injury or even death! This equipment is to be operated by trained and qualified personnel only! This equipment is for industrial use only. The following safety guidelines should always be used when operating the MT-62HS Tamping Rammer: SAFETY ■ DO NOT operate or service this equipment before reading this entire manual. ■ This equipment should not be operated by persons under 18 years of age.
MT-62HS — RULES FOR SAFE OPERATION ■ NEVER use accessories or attachments, which are not recommended by Multiquip for this equipment. Damage to the equipment and/or injury to user may result. Maintenance Safety ■ NEVER lubricate components or attempt service on a running rammer. ■ Whenever necessary, replace nameplate, operation and safety decals when they become difficult read. ■ ALWAYS allow the rammer a proper amount of time to cool before servicing. ■ NEVER Run engine without air filter.
MT-62HS — OPERATION AND SAFETY DECALS P/N 920100240 NPA-910 J CAUTION ATTENZIONE ATENÇAÕ PRECAUCION * Read operator’s manual carefully before use. * Libre le manual attentivement avant utillsation. * Bitte lesen Sie vor inbetriebnahme der Maschine de Bedienungsanleitung sogfältig durch. * Prima dell’ uso leggere attentamente il manuale. * Lee com atenÇão o manual de instruÇões antes de usar. * Leer detenidamente el mamual de instrucciones antes de usar la maquina.
MT-62HS — GENERAL INFORMATION Definition of Tamping Rammer The Mikasa MT-62HS Tamping Rammer is a powerful compacting tool capable of applying a tremendous force in consecutive impacts to a soil surface. Its applications include soil compacting for backfilling for gas pipelines, water pipelines and cable installation work. The impact force of the MT-62HS levels and uniformly compacts voids between soil particles to increase dry density. Circular motion is converted to create impact force.
MT-62HS — SPECIFICATIONS Table 1. MT-62HS Rammer Specifications MODEL MT-62HS U.S. (metric) Overall Height 40.6 in. (1,030 mm) Overall Width 13.8 in. (350 mm) Over Length 27.6 in. (700 mm) Shoe Size 10.8 x 13.4 in. (274 x 340 mm) Blows/minute 600 ~ 690 Travel Speed 36 ft./min. (11 meters/min.) Stroke (Jump Height) 2.75 in. (70 mm) Impact Force 1,650 ~ 2,250 lbs./blow (750 ~ 1,000 Kg/blow) Compacted Area 1,944 ft2/hr (181 m2/hr) Clutch Automatic Centrifugal Operating Weight 123 lbs.
MT-62HS — CONTROLS AND COMPONENTS 13 8 10 1 5 2 12 MT-62HS 11 9 3 7 6 4 Figure 1. MT-62HS Rammer Figure 1 shows the location of the controls and components for the MT-62HS Tamping Rammer. The functions of each control is described below: 1. Throttle Lever – Controls engine speed and the tamping action of the rammer. 2. Fuel Shut-Off Valve – Supplies fuel from the fuel tank to the engine. To begin fuel flow move the fuel shut-off valve downward. 3.
MT-62HS — BASIC ENGINE 3 4 2 1 5 6 Figure 2. Engine Controls and Components INITIAL SERVICING The engine (Figure 2) must be checked for proper lubrication and filled with fuel prior to operation. Refer to the manufacturers Engine manual for instructions & details of operation and servicing. 5. Recoil Starter (pull rope) – Manual-starting method. Pull the starter grip until resistance is felt, then pull briskly and smoothly. 1.
MT-62HS — PRE-INSPECTION This section is intended to assist the operator with the pre-inspection of the MT-62HS Tamping Rammer. It is extremely important that this section be read carefully before attempting to operate the rammer. Fuel 1. If fuel is low, remove the fuel filler cap (Figure 4) and fill with only unleaded gasoline. Motor fuels are highly flammable and can be dangerous if mishandled. DO NOT smoke while refueling. DO NOT attempt to refuel the pump if the engine is hot! or running.
MT-62HS — INITIAL START-UP This section is intended to assist the operator with the initial start-up of the MT-62HS rammer. It is extremely important that this section be read carefully before attempting to use the rammer in the field. 2. Turn the engine ON/OFF switch (Figure 7) to the "ON" position. DO NOT use your rammer until this section is thoroughly understood. CAUTION: Figure 7.
MT-62HS —INITIAL START-UP 5 Grip the recoil starter (Figure 10) handle and pull it until you feel a slight resistance. Then pull sharply and quickly. Return the recoil starter handle to the starter position before releasing. 8. If the engine does not start after repeated attempts, check the spark plug for excess fuel. Clean and replace the spark plug as needed. 9.
MT-62HS — OPERATION Operation 1. To start the rammer tamping action, move the throttle lever (Figure 12) quickly from IDLE (close) to the FULL OPEN position. DO NOT move the throttle lever slowly as this may cause damage to the clutch or spring. Figure 13. Throttle Lever (Idle) 2. After the engine cools, turn the engine ON/OFF switch to the “OFF” position (Figure 14). Figure 12. Throttle Lever (Full Open) CAUTION: Make sure that the throttle lever is moved to the FULL OPEN position.
MT-62HS — MAINTENANCE MAINTENANCE Perform the scheduled maintenance procedures as definded by Table 3 and below: DAILY ■ Thoroughly remove dirt and oil from the engine compartment and rammer. Clean or replace the air cleaner elements as necessary. Check and retighten all fasteners as necessary. Check the bellows for oil leaks. Repair or replace as needed.
MT-62HS — MAINTENANCE (RAMMER) CLEANING THE OIL TANK ■ Clean the inside of the oil tank regularly, preferably 2 or 3 times a year. ■ In winter, be sure to clean the inside of oil tank to avoid the freezing of water that may have accumulated inside the tank. CAUTION: 2. Remove the bolts that secure the oil tank to the fuel tank, and drain all oil from the tank. 3. Remove cock holder, then clean strainer and cock holder in a kerosene solution. 4.
MT-62HS — MAINTENANCE (ENGINE) Perform the scheduled engine maintenance procedures as definded by Table 3 below: Table 3. Engine Maintenance Schedule DESCRIPTION (3) OPERATION BEFORE CHECK X FIRST EVERY MONTH 3 MONTHS OR OR 10 HRS. 25 HRS. EVERY 6 MONTHS OR 50 HRS. EVERY Y E AR OR 1 0 0 HRS . EVERY 2 YEARS OR 200 HRS.
MT-62HS — TROUBLESHOOTING GUIDE TABLE 4. ENGINE TROUBLESHOOTING SYMPTOM POSSIBLE PROBLEM SOLUTION Difficult to start Fuel is available but spark plug will not ignite. (Power available at high tension cable). Fuel is available but spark plug will not ignite. (Power NOT available at high tension cable). Fuel is available and spark plug ignites (compression normal). Fuel is available and spark plug ignites (compression low ). Ignition plug being bridge? Check ignition system.
MT-62HS — TROUBLESHOOTING GUIDE ENGINE TABLE 4. ENGINE TROUBLESHOOTING (continued) SYMPTOM POSSIBLE PROBLEM SOLUTION Operation not satisfactory Governor adjustment improper? Adjust governor to correct lever. Governor spring defective? Clean or replace ignition. Fuel flow erratic? Check fuel line. Air taken in through suction line? Check suction line. Dust in rotating par t? Clean recoil star ter assembly. Spring spring failure? Replace sprial spring. Rotational speed fluctuates.
MT-62HS — EXPLANATION OF CODE IN REMARKS COLUMN How to read the marks and remarks used in this parts book. Items Found In the “Remarks” Column Serial Numbers-Where indicated, this indicates a serial number range (inclusive) where a particular part is used. Model Number-Where indicated, this shows that the corresponding part is utilized only with this specific model number or model number variant.
MT-62HS — SUGGESTED SPARE PARTS MT-62HS 1 TO 3 UNITS WITH ROBIN EC08HS ENGINE 1 to 3 Units Qty. P/N Description 1 ......... 362910060 .......... THROTTLE LEVER ASSY. 1 ......... 956100044 .......... THROTTLE WIRE 1 ......... 0830000010 ........ SPRING, COIL 3 ......... 362030030 .......... ELEMENT, AIR CLEANER (YELLOW) 3 ......... 1573620101 ........ ELEMENT SET (ENGINE) 3 ......... 0650140031 ........ SPARK PLUG 1 ......... 361910021 .......... CAP, FUEL TANK W/STRAP (ORANGE) 1 ......... 353030071 .......
MT-62HS — NAMEPLATE AND DECALS NAMEPLATE AND DECALS 2 1 3 14 13 12 11 10 9 4 6 MT-62HS 5 7 8 PAGE 26 — MT-62HS — PARTS & OPERATION MANUAL — REV.
MT-62HS — NAMEPLATE AND DECALS NAME PLATE AND DECALS NO. PART NO. PART NAME 1 2 3 4 5 6 7 8 9 10 11 12 13 14 920100240 920205990 920205810 920203290 NPA963 920108310 DECAL: (M- MARK) 1 DECAL: CAUTION (WATER) ................. 1............ NPA599 DECAL: CAUTION/OIL INJECT ............ 1............ NPA581 DECAL: CAUTION ................................ 1............ NPA329 DECAL: CLEANING ELEMENT 1 DECAL: CLEANER ELEMENT ............. 1............ NPA831 PLATE: SERIAL NO. .............................
MT-62HS — CRANKCASE AND ENGINE ASSY. CRANKCASE AND ENGINE ASSY. PAGE 28 — MT-62HS — PARTS & OPERATION MANUAL — REV.
MT-62HS — CRANKCASE AND ENGINE ASSY. CRANKCASE & ENGINE ASSY. NO. 1 2 3 4 5 6 7 9 10 11 13 14 15 16 17 18 20 21 23 24 25 26 27 28 29 30 31 32 32-1 * 32-2 * 32-3 * 32-4 * 32-5 * 33 34 * 57 58 59 60 PART NO.
MT-62HS — CRANKCASE AND ENGINE ASSY. CRANKCASE AND ENGINE ASSY. PAGE 30 — MT-62HS — PARTS & OPERATION MANUAL — REV.
MT-62HS — CRANKCASE AND ENGINE ASSY. CRANKCASE & ENGINE ASSY. NO. 62 62-1# 62-2# 62-3# 62-4# 62-5# 63 64 65 66 68# 70 75 88 PART NO. 362116870 362030010 362030020 362030030 362030040 050300070 362455670 031108160 353342400 507010110 PART NAME QTY. REMARKS AIR CLEANER ASSY. ............................................... 1 ..........
MT-62HS — GUIDE CYLINDER ASSY. GUIDE CYLINDER ASSY. PAGE 32 — MT-62HS — PARTS & OPERATION MANUAL — REV.
MT-62HS — GUIDE CYLINDER ASSY. GUIDE CYLINDER & FOOT ASSY. NO. 61 62 63 64 65 66 67 68 69 70 71 73 74 75 76 77 78 82 83 84 85 86 87 88 89 90 112 113 PART NO. 351420390 080100120 351324120 362455680 020116130 351434200 351434211 351324140 362341640 351209600 351109020 050100750 050930850 001521020 001521035 953405270 953405260 351209590 353332850 050100950 351316870 351433250 001220840 020308060 050100800 002211040 959010150 953404670 PART NAME PISTON PIN STOP RING R- 12 PISTON ROD PISTON END NUT M16, P1.
MT-62HS — TANK AND HANDLE ASSY. TANK AND HANDLE ASSY. PAGE 34 — MT-62HS — PARTS & OPERATION MANUAL — REV.
MT-62HS — TANK AND HANDLE ASSY. TANK & HANDLE ASSY. NO. 3 4 8 9 10 11 12 13 14 15 16 16-1# 16-2# 16-3# 18 19 20 23 24 25 26 27 28 * 29 30 31 32 33 * 34 * 35 36 37 38 39 * 40 * 41 * 42 * 43 * 44 * 45 * 46 * 47 * 48 49 50 PART NO.
MT-62HS — TANK AND HANDLE ASSY. TANK AND HANDLE ASSY. PAGE 36 — MT-62HS — PARTS & OPERATION MANUAL — REV.
MT-62HS — TANK AND HANDLE ASSY. TANK & HANDLE ASSY. NO. 51 52 53 54 55 56% 57% 58% 59% 60 61 62 63 64 65 66 67 70 71 72 89 PART NO. 353213710 355448251 353030071 091004010 353910020 1617260101 0062610091 353449031 953405640 956100044 353450220 355448071 0830000010 959401750 353030080 091005015 952405970 009110011 030208200 952401450 361910040 90$ 91 92$ 091005025 022610505 031105080 PART NAME QTY. REMARKS OIL TANK 1 STRAINER, OIL TANK 1 OIL TANK CAP CP (YELLOW) 1 SCREW 4X10 1 OIL SENSOR ASSEMBLY .......
MT-62HS — FOOT ASSY. FOOT ASSY. PAGE 38 — MT-62HS — PARTS & OPERATION MANUAL — REV.
MT-62HS — FOOT ASSY. FOOT ASSY. NO. 100 101 * 102 * 103 * 104 * 105 * 106 * 107 * 108 * 109 * 110 * PART NO. 351910130 351109030 351109040 001611253 001611051 022711214 030212300 022711012 030210250 352322581 301010540 PART NAME QTY. REMARKS FOOT ASSY. 265W- 215P ......................................... 1 .......... INCLUDES ITEMS W/ * FOOT, 265W- 215P 1 METAL SHEET 265W- 215P- 4.
MT-62HS — TRENCH SHOE ASSY. (OPTION) TRENCH SHOE ASSY. (OPTION) PAGE 40 — MT-62HS — PARTS & OPERATION MANUAL — REV.
MT-62HS — TRENCH SHOE ASSY. (OPTION) TRENCH SHOE ASSY. (OPTION) NO. A A A B * B * B * 1 # * 1 # * 1 # * 2 # * 2 # * 2 # * 3 # * 4 # * 5 # * 6 # * 7 # * 8 # * 9 # * 10 * 11 * 12 * 13 * PART NO. 351910200 351910210 351910110 351910220 301910130 351910230 351327020 351205710 351327040 351327050 351206700 351327070 001611052 022711012 030210250 301010540 001611254 022711214 030212300 351105241 001211240 022711214 030212300 MT-62HS — TRENCH SHOE ASSY. (OPTION) PART NAME QTY. REMARKS FOOT ASSY.
MT-62HS — NARROW FOOT ASSY. (OPTION) NARROW FOOT ASSY. (OPTION) PAGE 42 — MT-62HS — PARTS & OPERATION MANUAL — REV.
MT-62HS — NARROW FOOT ASSY. (OPTION) NARROW FOOT ASSY. (OPTION) NO. 210 211 * 212 * 220 220 220 221# 221# 221# 222# 222# 222# 223# 224# 225# 226# 227# 228# 229# 230# PART NO. 351910270 351323750 001611256 351910140 351910150 351910160 351324240 351324250 351324260 351324270 351324280 351324290 001611051 301010540 030210250 022711012 001611253 022711214 030212300 959010413 PART NAME QTY. REMARKS FOOT ASSY., PLASTIC ............................................ 1 ..........
ROBIN EC-08HS ENGINE — CRANKCASE AND CYLINDER ASSY. CRANKCASE AND CYLINDER ASSY. PAGE 44 — MT-62HS — PARTS & OPERATION MANUAL — REV.
ROBIN EC-08HS ENGINE — CRANKCASE AND CYLINDER ASSY. CRANKCASE AND CYLINDER ASSY. NO 10 30 35 36 40 41 50 95 105 115 140 145 146 170 180 190 200 510 850 * * * * * * * * PART NO 5801056000 0440200020 0440200020 0440060010 0600200010 0600200020 0052606140 0011406450 0105060050 0105064940 0643000101 5809501600 0011308180 5801501800 0021706000 030206150 0031006000 5801501400 1507520103 PART NAME QTY. REMARKS CRANK CASE CP ................................ 1 ............
ROBIN EC-08HS ENGINE — CRANKSHAFT AND PISTON ASSY. CRANKSHAFT AND PISTON ASSY. PAGE 46 — MT-62HS — PARTS & OPERATION MANUAL — REV.
ROBIN EC-08HS ENGINE — CRANKSHAFT AND PISTON ASSY. CRANKSHAFT AND PISTON ASSY. NO 10 30 40 50 60 65 70 130 131 132 140 160 170 350 360 370 380 390 PART NO 5802028000 0323049950 1292500103 0039310000 030210250 030206150 0053204201 5804010000 0131050020 0032005000 5514500100 0230230020 0173120010 5802500700 5802500600 5802023000 0565119990 0610120010 PART NAME QTY. REMARKS CRANK SHAFT 1 WOODRUFF KEY 1 SPACER 2 NUT ...................................................... 1 ............REPLACES SPRING WASHER ..
ROBIN EC-08HS ENGINE — GOVERNOR ASSY. GOVERNOR ASSY. PAGE 48 — MT-62HS — PARTS & OPERATION MANUAL — REV.
ROBIN EC-08HS ENGINE — GOVERNOR ASSY. GOVERNOR ASSY. NO 10 15 16 20 30 40 80 90 100 120 130 305 310 340 341 342 350 360 370 380 400 480 610 620 PART NO 5804005000 5804500900 2266255008 1294220103 1054270111 1064280113 1294250111 1294210113 0140039980 57028 030206150 0217060020 5804500800 5804500600 0230060090 0105050616 0200070010 0016506400 57028 0170069960 1294500103 402010110 0149060040 020106050 PART NAME QTY. REMARKS GOVERNOR LEVER 1 BUSH 2 BUSH, NYLON ..................................... 1 ........
ROBIN EC-08HS ENGINE — MUFFLER ASSY. MUFFLER ASSY. PAGE 50 — MT-62HS — PARTS & OPERATION MANUAL — REV.
ROBIN EC-08HS ENGINE — MUFFLER ASSY. MUFFLER ASSY. NO 300 308 309 310 330 331 340 350 355 356 361 362 PART NO 0016706200 0031206000 0566099950 5803032000 5803033000 5803034000 1293500403 0170069960 030206150 0031006000 0016706160 0031006000 PART NAME QTY. REMARKS MUFFLER 2 WASHER, FLAT 2 CLAMP 1 MUFFLER 1 MUFFLER BRACKET A 1 MUFFLER BRACKET B 1 GASKET (MUFFLER) 1 U-NUT 2 SPRING WASHER ............................... 7 ............
ROBIN EC-08HS ENGINE — CARBURETOR AND OIL PUMP ASSY. CARBURETOR AND OIL PUMP ASSY. PAGE 52 — MT-62HS — PARTS & OPERATION MANUAL — REV.
ROBIN EC-08HS ENGINE — CARBURETOR AND OIL PUMP ASSY. CARBURETOR AND OIL PUMP ASSY. NO 210 250 700 705 706 710 716 720 730 731 732 733 740 745 750 760 765 PART NO 5806111000 1616235308 5806113000 5806502300 0323039980 0011306250 0031520000 1616350101 5806501900 0119089970 030208200 0031008000 5806502000 5806502100 5806502200 0566059980 0119059610 PART NAME QTY. REMARKS CARBURETOR ASSY ......................... 1 ............SEE CARBURETOR FIG.
ROBIN EC-08HS ENGINE — RECOIL STARTER AND BLOWER ASSY. RECOIL STARTER AND BLOWER ASSY. PAGE 54 — MT-62HS — PARTS & OPERATION MANUAL — REV.
ROBIN EC-08HS ENGINE — RECOIL STARTER AND BLOWER ASSY. RECOIL STARTER AND BLOWER ASSY. NO 10 15 20 25 26 40 50 51 52 53 210 PART NO 5805501200 5515500200 920100240 5809503800 5809500501 0011106200 5805022000 011206020 0031206000 030206150 5805001000 220 230 850 0011006100 0011006140 0566000250 PART NAME QTY. REMARKS FAN COVER 1 GUIDE RUBBER 1 DECAL, (M-MARK) 1 LABEL, ENGINE 1 LABEL, MODEL 1 BOLT ASSY 4 CYLINDER COVER CP 1 BOLT (CYLINDER) .............................. 2 ............
ROBIN EC-08HS ENGINE — AIR CLEANER ASSY. AIR CLEANER ASSY. PAGE 56 — MT-62HS — PARTS & OPERATION MANUAL — REV.
ROBIN EC-08HS ENGINE — AIR CLEANER ASSY. AIR CLEANER ASSY. NO 510 520 521 522 540 550 560 580 600 * * * PART NO 5803052000 1573620101 1613261008 2263272008 1293290103 1063500103 2373590303 0011306800 030206150 PART NAME QTY. REMARKS AIR CLEANER ASSY ........................... 1 ............INCLUDES ITEMS W/ ELEMENT SET .................................... 1 ............REPLACES 1573260007 ELEMENT 1 GASKET (AIR CLEANER) 1 INSULATOR 1 GASKET (INSULATOR) 2 GASKET 2 (INSULATOR) 1 BOLT 2 SPRING WASHER ......
ROBIN EC-08HS ENGINE — CARBURETOR COMPONENTS ASSY. CARBURETOR COMPONENTS ASSY. PAGE 58 — MT-62HS — PARTS & OPERATION MANUAL — REV.
ROBIN EC-08HS ENGINE — CARBURETOR COMPONENTS ASSY. CARBURETOR COMPONENTS ASSY.
ROBIN EC-08HS ENGINE — RECOIL STARTER COMPONENTS ASSY. RECOIL STARTER COMPONENTS ASSY. PAGE 60 — MT-62HS — PARTS & OPERATION MANUAL — REV.
ROBIN EC-08HS ENGINE — RECOIL STARTER COMPONENTS ASSY. RECOIL STARTER COMPONENTS ASSY. NO 1 2 3 4 5 6 7 8 9 10 11 12 * * * * * * * * * * * PART NO 5515005160 5805001030 5805011040 5805004020 5805004030 5805004050 5805004040 5805004110 5805004120 5805011020 5805004140 5805001000 PART NAME QTY. REMARKS ROPE STOPPER 1 STARTER HANDLE 1 STARTER ROPE 1 SPIRAL SPRING 1 REEL 1 RETURN SPRING 1 RATCHET 1 FRICTION SPRING 1 FRICTION PLATE ................................ 1 ............
ROBIN EC-08HS ENGINE — MAGNETO ASSY. MAGNETO ASSY. PAGE 62 — MT-62HS — PARTS & OPERATION MANUAL — REV.
ROBIN EC-08HS ENGINE — MAGNETO ASSY. MAGNETO ASSY. NO. 10 11 18 30 40 60 70 81 95 100 110 PART NO. 5807005010 5807007020 0851029960 0011105250 1507520103 0660000361 0043304100 0241069980 0659000010 0650140031 0655000140 PART NAME QTY. REMARKS FLYWHEEL 1 IGNITION COIL 1 VINYL PIPE 1 BOLT AND WASHER ASSY 2 CLAMP ................................................. 1 ............REPLACES 0566099950 STOP SWITCH ASSY (ON-OFF) 1 SCREW 4X10 2 GROMMET 1 SPARK PLUG CLIP .............................. 1 ............
ROBIN EC-08HS ENGINE — OIL PUMP ASSY. OIL PUMP ASSY. PAGE 64 — MT-62HS — PARTS & OPERATION MANUAL — REV.
ROBIN EC-08HS ENGINE — OIL PUMP ASSY. OIL PUMP ASSY. NO. 1 2 3 4 6 7 11 12 13 PART NO. 5806113000 5806113020 5806113030 5806113040 1616391608 1616391008 2266235408 1616391909 5806113140 PART NAME QTY. REMARKS OIL PUMP ASSY. 1 OIL HOSE 1 OIL HOSE 1 PROTECTOR 1 CLIP 3 CLIP ...................................................... 1 ............REPLACES 0566099950 SCREW 1 PACKING 1 PROTECTOR 1 MT-62HS — PARTS & OPERATION MANUAL — REV.
TERMS AND CONDITIONS OF SALE — PARTS Effective: October 1, 2002 PAYMENT TERMS 5. Parts must be in new and resalable condition, in the original Multiquip package (if any), and with Multiquip part numbers clearly marked. 6. The following items are not returnable: Terms of payment for parts are net 10 days. FREIGHT POLICY All parts orders will be shipped collect or prepaid with the charges added to the invoice. All shipments are F.O.B. point of origin.
NOTE PAGE MT-62HS — PARTS & OPERATION MANUAL — REV.
