MQ DRY PRIME PUMP • PARTS MANUAL — REV. #5 (10/12/09) — PAGE 53

NO. PART NO. PART NAME QTY. REMARKS

1 0447 WASHER, FLAT 1/2 SAE 24

2 4684 WASHER, FLAT SAE 5/8 PLTD 25

3 9502 SCREW, HHC 5/8-11 X 4-1/2 GR8 3

4 9503 NUT, NYLOC 5/8-11 3

5 9509 SCREW, TEK 12 X 3/4 SELF TAP 3

6 16055 NUT, HEX M8-1.25 2

7 16057 SCREW, HHC M12-1.75 X 40MM 12

8 17101 SCREW, HHC M16-2.00X40 ZN, DIN933 CL8.8 16

9 17114 NUT, HEX FINISH M12-1.750 ZN, DIN934 CL8 12

10 17181 HARNESS, MP PUMP ELEC. BRAKES 1

11 17183 HARNESS, MP PUMP TONGUE, ELEC. BRK. 1

12 17267 CONNECTOR, BUTT SPLICE, 16-14 HT SHRNK 6

13 17273 AXLE, MP PUMP 5200# ELEC. BRAKE 1

14 17275 FENDER, MP PUMP 2

15 17276 FENDER MOUNT, MP PUMP, RH 2

16 17277 FENDER MOUNT, MP PUMP, LH 2

17 17280 MOUNT, MP PUMP AXLE & FENDERS 2

18 17281 AXLE MOUNT, MP PUMP 2

19 17282 JACK ASSY., MP PUMP ........................................2 .................... INCLUDES ITEMS W/*

20* 17284 JACK W/A, MP PUMP 2

21* 17285 MOUNTING PLATE, TRAILER ACCESSORIES 2

22 17286 RECEIVER W/A , MP PUMP ELEC BRAKES 1

23 17295 COUPLER, 2 5/16" BALL 6000# GVWR 1

24 19280 PIN, 5/8" X 6" 1

25 19468 GROMMET, MINOR Z-4004 2

26 29366 KIT, BREAK-AWAY, TRAILER 70 1

27 29572 CHAIN ASM, SAFETY 7600 LB 2

28 29638 WHEEL / TIRE, ST225/75D15 LR D 2

29 29755 KIT, HARDWARE, WHL MNT, 1/2-20 PLTD NUTS 1

30 17104 SCREW, HHC M8-1.25 X 100 ZN DIN931 CL8.8 2

TRAILER ASSY. (ELECTRIC BRAKE)
