MQ DRY PRIME PUMP • PARTS MANUAL — REV. #5 (10/12/09) — PAGE 41

PRIMING TANK ASSY. (2)

NO. PART NO. PART NAME QTY. REMARKS

1 1605 SCREW, HHC M8-1.25 X 25MM 8

2 17208 FITTING, 90 1.25MP X 1.25FP GALV 4

3 17209 FITTING, STR 1.25MP X .75FP, GALV 1

4 17211 FITTING, TEE 1.25FPX1.25FPX1.25FP, GALV 1

5 17212 FITTING, STR 1.25MPX1.25BARB, GALV 3

6 17214 FITTING, NIPPLE 3/4 MP CLOSE, GALV 2

7 17215 FITTING, NIPPLE 1-1/4 MP CLOSE, GALV 3

8 17216 FITTING, PLUG 1.25MP SQ HD, GALV 1

9 17217 VALVE, BALL 1-1/4FPX1-1/4FP, BRASS 2

10 17218 VALVE, BALL 3/4FPX3/4FP, BRASS 2

11 17265 HOSE 1.25ID CLEAR, WIRE REINFORCED ................................. SOLD IN FOOT LENGTHS

12 17266 FITTING, 1.25FP X 1.25FP CHECK VALVE 1

13 17291 FITTING, 3/4 MP X 1/2 FP, BRASS 1

14 17387 BAFFLE, PRIMING TANK EXHAUST 1

15 19470 WASHER, FLAT 5/16 USS 8

16 26405 CLAMP, HOSE WORM 13/16 X 1-3/4 SIZE 20 1

17 29057 DOCUMENT BOX 1
