PARTS MANUAL

Revision #5 (10/12/09)

DRY PRIME PUMP

THIS MANUAL MUST ACCOMPANY THE EQUIPMENT AT ALL TIMES.

To find the latest revision of this

publication, visit our website at:

www.multiquip.com

P/N 17568

MP150SDLTE (6-inch, High Flow, Deutz F3L914, Electric Brakes)

MP150SDLTS (6-inch, High Flow, Deutz F3L914, Surge Brakes)

MP150SDLSM (6-inch, High Flow, Deutz F3L914, Skid Mount)

MP200DLTE (8-inch, High Flow, Deutz F3L914, Electric Brakes)

MP200DLTS (8-inch, High Flow, Deutz F3L914, Surge Brakes)

MP200DLSM (8-inch, High Flow, Deutz F3L914, Skid Mount)

MP200SDLTE (8-inch, High Flow, Deutz F4L914, Electric Brakes)

MP200DLST (8-inch, High Flow, Deutz F4L914, Surge Brakes)

MP200SDLSM (8-inch, High Flow, Deutz F4L914, Skid Mount)

Summary of content (56 pages)

PAGE 1
PARTS MANUAL DRY PRIME PUMP MP150SDLTE (6-inch, High Flow, Deutz F3L914, Electric Brakes) MP150SDLTS (6-inch, High Flow, Deutz F3L914, Surge Brakes) MP150SDLSM (6-inch, High Flow, Deutz F3L914, Skid Mount) MP200DLTE (8-inch, High Flow, Deutz F3L914, Electric Brakes) MP200DLTS (8-inch, High Flow, Deutz F3L914, Surge Brakes) MP200DLSM (8-inch, High Flow, Deutz F3L914, Skid Mount) MP200SDLTE (8-inch, High Flow, Deutz F4L914, Electric Brakes) MP200DLST (8-inch, High Flow, Deutz F4L914, Surge Brakes) MP200SDLSM
PAGE 2
Engine exhaust and some of its constituents, and some dust created by power sanding, sawing, grinding, drillingandotherconstructionactivities contains chemicals known to the State of California to cause cancer, birth defects and other reproductive harm. Some examples of these chemicals are: Leadfromlead-basedpaints. Crystallinesilicafrombricks. Cementandothermasonryproducts. Arsenicandchromiumfromchemically treatedlumber.
PAGE 3
WARNING WARNING SILICOSIS WARNING RESPIRATORY HAZARDS Grinding/cutting/drilling of masonry, concrete, metal and other materials with silica in their composition may give off dust or mists containing crystalline silica. Silica is a basic component of sand, quartz, brick clay, granite and numerous other minerals and rocks. Repeated and/or substantial inhalation of airborne crystalline silica can cause serious or fatal respiratory diseases, including silicosis.
PAGE 4
TABLE OF CONTENTS MQ - DRY PRIME PUMP Table of Contents ...................................................... 4 Parts Ordering Procedures ....................................... 5 Explanation Of Code In Remarks Column ................ 6 Suggested Spare Parts ............................................. 7 Nameplate and Decals......................................... 8-11 Engine Skid Rails Assy. ...................................... 12-13 Deutz F3L914 Engine Assy. ...............................
PAGE 5
www.multiquip.com PARTS ORDERING PROCEDURES Ordering parts has never been easier! Choose from three easy options: Effective: January 1st, 2006 Best Deal! Order via Internet (Dealers Only): If you have an MQ Account, to obtain a Username and Password, E-mail us at: parts@multiquip.com. Order parts on-line using Multiquip’s SmartEquip website! ■ View Parts Diagrams ■ Order Parts ■ Print Specification Information To obtain an MQ Account, contact your District Sales Manager for more information.
PAGE 6
EXPLANATION OF CODE IN REMARKS COLUMN The following section explains the different symbols and remarks used in the Parts section of this manual. Use the help numbers found on the back page of the manual if there are any questions. The contents and part numbers listed in the parts section are subject to change without notice. Multiquip does not guarantee the availibility of the parts listed. * * Numbers Used - Item quantity can be indicated by a number, a blank entry, or A/R.
PAGE 7
SUGGESTED SPARE PARTS MQ DRY PRIME PUMP 1 TO 3 UNITS WITH DEUTZ DIESEL ENGINE RECOMENDED SERVICE TOOLING Qty. P/N Description 2 ....... 17020 .................. O-RING, SIZE 2-248 VITON 1 ....... 17031 .................. O-RING, SIZE 2-237 VITON 1 ....... 17037 .................. GASKET, VOLUTE TO PRIMING TANK 1 ....... 17038 .................. GASKET, PRIMING TANK ACCESS PANEL 1 ....... 17039 .................. GASKET, PRIMING TANK FLOAT VALVE 3 ....... 17040 .................. GASKET, 8" FLANGE 2 ......
PAGE 8
NAMEPLATES AND DECALS (1) NAMEPLATES AND DECALS (1) PAGE 8 — MQ DRY PRIME PUMP • PARTS MANUAL — REV.
PAGE 9
NAMEPLATES AND DECALS (1) NAMEPLATES AND DECALS (1) NO. PART NO. PART NAME QTY. REMARKS 1 17175 DECAL, WARNING CHECK VALVE DRAIN ............. 1 .................. SAFETY ITEM 2 17176 DECAL, WARNING PRIMING TANK LIFT BAIL ....... 3 .................. SAFETY ITEM 3 36099 DECAL, PROTECTIVE CLOTHING ISO BLUE ........ 1 .................. SAFETY ITEM 4 17174 DECAL, OPERATING INSTRUCTIONS/WARNINGS 1 .................. SAFETY ITEM 5 36092 DECAL, WARNING DIESEL FUEL 3.5 X 1.75 ......... 1 ..................
PAGE 10
NAMEPLATES AND DECALS (2) NAMEPLATES AND DECALS (2) PAGE 10 — MQ DRY PRIME PUMP • PARTS MANUAL — REV.
PAGE 11
NAMEPLATES AND DECALS (2) NAMEPLATES AND DECALS (2) NO. PART NO. PART NAME QTY. REMARKS 1 17348 DECAL, MQ MULTIQUIP 14" WHITE 2 2 17176 DECAL, WARNING PRIMING TANK LIFT BAIL ....... 3 .................. SAFETY ITEM 3 17177 DECAL, BACKFLUSH VALVE 1 4 36092 DECAL, WARNING DIESEL FUEL 3.5 X 1.75 ......... 1 .................. SAFETY ITEM 5 29157 DECAL, DIESEL ONLY ............................................ 1 .................. SAFETY ITEM 6 17347 DECAL, MQ LOGO 8 X 10 WHITE ..........................
PAGE 12
ENGINE SKID RAILS ASSY. ENGINE SKID RAILS ASSY. 5 5 4 3 3 2 3 6 3 6 3 6 1 PAGE 12 — MQ DRY PRIME PUMP • PARTS MANUAL — REV.
PAGE 13
ENGINE SKID RAILS ASSY. ENGINE SKID RAILS ASSY. NO. PART NO. PART NAME 1 17224 RAIL, MP PUMP LH SIDE 2 17225 RAIL, MP PUMP RH SIDE 3 4684 WASHER, FLAT SAE 5/8 PLTD 4 17412 SCREW, HHC M16 - 2.00 X 120 ZN CL8.8 5 17170 SCREW, HHC M16 - 2.00 X 60 ZN CL8.8 6 17097 NUT, NYLOC M16-2.00 DIN985 QTY. 1 1 20 2 8 10 REMARKS MQ DRY PRIME PUMP • PARTS MANUAL — REV.
PAGE 14
DEUTZ F3L914 ENGINE ASSY. (1) DEUTZ F3L914 ENGINE ASSY. (1) 6 16 12 1 11 3 13 1 15 4 1 10 14 7 9 2 8 5 1 1 USE THREADLOCK: HIGH TEMP. LOCTITE BLUE 246 OR EQUIVALENT. TORQUE TO 50 FT-LBF (67.9 N-m) 2 USE THREADLOCK: HIGH TEMP. LOCTITE RED 272 OR EQUIVALENT TORQUE TO 250 FT-LB (338.9 N-m) 2 PAGE 14 — MQ DRY PRIME PUMP • PARTS MANUAL — REV.
PAGE 15
DEUTZ F3L914 ENGINE ASSY. (1) DEUTZ F3L914 ENGINE ASSY. (1) NO. PART NO. PART NAME 1 2866 SCREW, HHC M8-1.25 X 20 MM GR 8.8 2 8151 WASHER FLAT SAE 3/4 10136 WASHER, FLAT SAE 3/8 3 4 13339 WASHER, EXT. SHKP, 5/16 5 16523 SCREW, HHC 3/4-10 X 1-1/2 GD 8 6 17000 ENGINE, DEUTZ F3L914 7 17116 KEY, WOODRUFF #1422-1-7/16X2-3/4 8 17117 WASHER, FLAT SAE 1-1/4" 9 17119 NUT, HEX JAM 1-1/4-12 10 17233 COUPLER, MP PUMP ENG TO BRG HSG 11 17205 PLATE, PUMP FLYWHEEL HSG MOUNT 12 17388 SCREW, SHC M10-1.5X25 GRD 10.
PAGE 16
DEUTZ F3L914 ENGINE ASSY. (2) DEUTZ F3L914 ENGINE ASSY. (2) 4 3 7 8 5 10 2 6 9 1 PAGE 16 — MQ DRY PRIME PUMP • PARTS MANUAL — REV.
PAGE 17
DEUTZ F3L914 ENGINE ASSY. (2) DEUTZ F3L914 ENGINE ASSY. (2) NO. PART NO. PART NAME 1 2866 SCREW, HHC M8-1.25X20 MM GR8.8 2 17206 FITTING, STR 5 BARB X 1/4 MP 3 17331 SPACER, MP PUMP CONTROL PANEL 4 17388 SCREW, SHC M10-1.50X25 GRD 10.9 5 19473 CLAMP, HOSE WORM #2 1/4" TO 5/8" 6 35022 CLAMP, LOOM CUSHIONED #8 7 1181917 FILTER, FUEL 8 1182001 FILTER, OIL 9 2235175 BELT, FAN 10 2235178 BELT, ALTERNATOR QTY. 1 2 2 2 2 2 1 1 1 1 REMARKS MQ DRY PRIME PUMP • PARTS MANUAL — REV.
PAGE 18
DEUTZ F4L914 ENGINE ASSY. (1) DEUTZ F4L914 ENGINE ASSY. (1) 6 16 12 1 4 11 15 1 14 10 9 2 13 1 3 7 8 2 5 1 1 USE THREADLOCK: HIGH TEMP. LOCTITE BLUE 246 OR EQUIVALENT. TORQUE TO 50 FT-LB (67.9 N-m) 2 US THREADLOCK: HIGH TEMP LOCTITE RED 272 OR EQUIVALENT TORQUE TO 250 FT-LB (338.9 N-m) PAGE 18 — MQ DRY PRIME PUMP • PARTS MANUAL — REV.
PAGE 19
DEUTZ F4L914 ENGINE ASSY. (1) DEUTZ F4L914 ENGINE ASSY.(1) NO. PART NO. PART NAME 1 2866 SCREW, HHC M8-1.25 X 20 MM GR 8.8 2 8151 WASHER FLAT SAE 3/4 10136 WASHER, FLAT SAE 3/8 3 4 13339 WASHER, EXT. SHKP, 5/16 5 16523 SCREW, HHC 3/4-10 X 1-1/2 GD 8 6 17002 ENGINE, DEUTZ F4L914 7 17116 KEY, WOODRUFF #1422-1-7/16X2-3/4 8 17117 WASHER, FLAT SAE 1-1/4" 9 17119 NUT, HEX JAM 1-1/4-12 10 17233 COUPLER, MP PUMP ENG TO BRG HSG 11 17205 PLATE, PUMP FLYWHEEL HSG MOUNT 12 17388 SCREW, SHC M10-1.5X25 GRD 10.
PAGE 20
DEUTZ F4L914 ENGINE ASSY. (2) DEUTZ F4L914 ENGINE ASSY. (2) 5 6 8 3 2 7 1 4 PAGE 20 — MQ DRY PRIME PUMP • PARTS MANUAL — REV.
PAGE 21
DEUTZ F4L914 ENGINE ASSY. (2) DEUTZ F4L914 ENGINE ASSY. (2) NO. PART NO. PART NAME 1 2866 SCREW, HHC M8-1.25X20 MM GR8.8 2 17206 FITTING, STR 5 BARB X 1/4 MP 3 19473 CLAMP, HOSE WORM #2 1/4" TO 5/8" 4 35022 CLAMP, LOOM CUSHIONED #8 5 1181917 FILTER, FUEL 6 1182001 FILTER, OIL 7 2235175 BELT, FAN 8 2235178 BELT, ALTERNATOR QTY. 1 2 2 2 1 1 1 1 REMARKS MQ DRY PRIME PUMP • PARTS MANUAL — REV.
PAGE 22
MQ DRY PRIME PUMP - PRIMING SYSTEM HOSES PRIMING SYSTEM HOSES 3 1 4 3 1 5 2 1 5 3 2 1 P\N 17265: 36 IN (91.44 cm) CLEAR HOSE WIRE REINFORCED 2 P\N 60008: 25 IN (60.96 cm) HOSE, PVC BRAIDED 3 P\N 60008: 2 IN (5.08 cm) HOSE, PVC BRAIDED PAGE 22 — MQ DRY PRIME PUMP • PARTS MANUAL — REV.
PAGE 23
MQ DRY PRIME PUMP —PRIMING SYSTEM HOSES PRIMING SYSTEM HOSES NO. PART NO. PART NAME QTY. REMARKS 1 15538 CLAMP, HOSE WORM #6 4 2 17180 FILTER, FLOJET 1740-002 1 3 17265 HOSE, 1.25ID CLEAR WIRE REINFORCED ........... 72.0 IN. ........ SOLD IN FOOT LENGTHS 4 26405 CLAMP, HOSE WORM 13/16 - 1-3/4 SIZE 20 4 5 60088 HOSE, PVC BRAIDED, .5 ID X .75 OD ................... 26.0 IN ......... SOLD IN FOOT LENGTHS MQ DRY PRIME PUMP • PARTS MANUAL — REV.
PAGE 24
PUMP END ASSY. PUMP END ASSY. 4 2 8 6 12 5 3 13 1 1 10 3 7 1 USE THREADLOCK: HIGH TEMP. LOCTITE BLUE 246 OR EQUIVALENT. TORQUE TO 28 FT-LBF (37.9 N-m) 2 USE THREADLOCK: HIGH TEMP. LOCTITE BLUE 246 OR EQUIVALENT TORQUE TO 48 FT-LB (65.0 N-m) 3 USE THREADLOCK: HIGH TEMP. 9 2 2 11 2 LOCTITE RED 272 OR EQUIVALENT PAGE 24 — MQ DRY PRIME PUMP • PARTS MANUAL — REV.
PAGE 25
PUMP END ASSY. PUMP END ASSY. NO. PART NO. 1 2 0447 3 10136 4 16057 5 17017 6 17034 7 17037 8 17078 9 17114 10 17172 11 17413 12 17416 13 21584 PART NAME QTY. REMARKS VOLUTE ASSEMBLY ............................................... 1 .................. SEE PAGES 32-33 WASHER, FLAT SAE 1/2 12 WASHER, FLAT SAE 3/8 8 SCREW, HHC M12-1.75 x 40mm 4 PRIMING TANK ASSY., MP PUMP ......................... 1 .................. SEE PAGES 38-41 HOUSING ASSY. MP PUMP DRIVE SHAFT .......... 1 ..................
PAGE 26
BEARING HOUSING ASSY. BEARING HOUSING ASSY. 30 19 24 30 8 25 28 27 31 1 1 22 25 2 10 31 29 3 9 5 18 26 15 10 24 29 3 21 12 23 9 7 32 3 11 6 1 USE THREADLOCK: HIGH TEMP. LOCTITE BLUE 246 OR EQUIVALENT. 2 US THREADLOCK: HIGH TEMP LOCTITE RED 272 OR EQUIVALENT TORQUE TO 100 FT-LB (135.5 N-m) 13 1 14 17 3 FILL BEARING HOUSING CAVATIES TO THE CENTER OF SIGHTGLASS. FILL WITH P\N 60078 OIL, GEAR ISO 220 OR EQUIVALENT. 16 20 2 22 1 4 PAGE 26 — MQ DRY PRIME PUMP • PARTS MANUAL — REV.
PAGE 27
BEARING HOUSING ASSY. BEARING HOUSING ASSY. NO. PART NO. PART NAME QTY. REMARKS 1 11821 SCREW, SHC M8 - 1.25 X 25MM GR 12.9 NP 8 2 17012 HOUSING, MP PUMP DRIVE SHAFT 1 3 17013 DRIVE SHAFT, MULTIPURPOSE PUMP 1 4 17014 END CAP, MP PUMP BEARING HOUSING 1 5 17015 END CAP, MP PUMP BEARING HSG,VOLUTE 1 6 17016 SPACER, PUMP GEAR/BEARING 1 7 17018 PLATE,VACUUM PUMP MOUNT COVER 1 8 17019 EYE BOLT, M12 X 1.
PAGE 28
VACUUM PUMP ASSY. VACUUM PUMP ASSY. 20 11 10 23 16 17 24 3 5 12 9 4 13 3 5 15 2 1 2 2 22 2 1 2 18 7 4 21 18 5 21 6 9 19 8 1 14 1 2 1 USE THREADLOCK: HIGH TEMP LOCTITE BLUE 246 OR EQUIVALENT. 2 TORQUE TO 14 FT. LBS (18.9 N-m). 3 FILL ALL OIL RESERVOIRS WITH FILL WITH P\N 60078 OIL, GEAR ISO 220 OR EQUIVAL ENT. 4 ROTATE ECCENTRIC HOUSING TO OBTAIN. 006” CLEARANCE BETWEEN IMPELLER AND HOUSING. ROTATE IMPELLER AFTER SETTING CLEARANCE TO ENSURE IMPELLER DOES NOT RUB.
PAGE 29
VACUUM PUMP ASSY. VACUUM PUMP ASSY. NO. PART NO. 1 2478 2 2866 3 11821 4 12464 5 15538 6 17080 7 17081 8 17082 9 17083 10 17085 11 17086 12 17087 13 17096 14 17104 15 17113 16 17120 17 17136 18 17143 19 17204 20 17212 21 17299 22 17420 23 21218 24 37213 PART NAME QTY. FITTING, PETCOCK RAD DRAIN 1/4MP 1 SCREW, HHC M8 - 1.25 X 20MM 4 SCREW, SHC M8 - 1.25 X 25MM GR 12.9 NP 1 SCREW, HHC M6 - 1.
PAGE 30
VAC. PUMP BEARING HOUSING ASSY. VAC. PUMP BEARING HOUSING ASSY. 13 4 18 19 17 2 1 14 3 5 3 9 1 15 7 11 6 3 10 2 16 4 12 14 8 1 USE THREADLOCK: HIGH TEMP LOCTITE BLUE 246 OR EQUIVALENT. TORQUE TO 14 FT-LBS. (18.9 N-m). 2 TORQUE TO 8 FT-LBS (10.8 N-m). 3 APPLY LOCTITE 518, FLANGE SEALANT TO MATING SURFACES OF BEARING HOUSING AND PORT PLATE.
PAGE 31
VAC. PUMP BEARING HOUSING ASSY. VAC. PUMP BEARING HOUSING ASSY. NO. PART NO. PART NAME QTY. REMARKS 1 DECAL, MQT SERIAL PLATE, NON CE ................. 1 .................. CONTACT SERVICE DEPT. 2 4014 SCREW, #2 3/16 P-K TYPE U DRIVE 2 3 17020 O-RING, SIZE 2-248 VITON 1 4 17058 SPACER, MECHANICAL SEAL LOCATING 1 5 17079 PORT PLATE, MP VACUUM PUMP 1 6 17088 BEARING HOUSING, MP VACUUM PUMP 1 7 17089 END CAP, VACUUM PUMP BEARING HOUSING 1 8 17090 DRIVE SHAFT MP VACUUM PUMP 1 9 17098 SCREW, FHSC M8-1.
PAGE 32
VOLUTE AND CHECK VALVE ASSY. VOLUTE AND CHECK VALVE ASSY. 4 2 6 5 1 8 9 11 12 14 2 17 3 3 13 7 10 1 15 16 1 USE THREADLOCK: HIGH TEMP LOCTITE BLUE 246 OR EQUIVALENT. TORQUE TO 14 FT-LBS. (18.9 N-m). 2 USE THREADLOCK: HIGH TEMP LOCTITE BLUE 272 OR EQUIVALENT. 3 SHIM AS NECCESARY TO OBTAIN .020” +- .010” CLEARANCE BETWEEN IMPELLER AND WEAR PLATE PAGE 32 — MQ DRY PRIME PUMP • PARTS MANUAL — REV.
PAGE 33
VOLUTE AND CHECK VALVE ASSY. VOLUTE AND CHECK VALVE ASSY. NO. PART NO. PART NAME QTY. REMARKS 1 0447 WASHER, FLAT 1/2 SAE 6 2 16057 SCREW, HHC M12 - 1.75 X 40MM 6 3 17004 VOLUTE, MULTIPURPOSE PUMP 1 4 17019 EYE BOLT, M12 X 1.75 ZP 1 5 17040 GASKET, 8" FLANGE 1 6 17062 CHECK VALVE ASSY., PUMP DISCHARGE 1 7 17093 REAR WEAR RING, MP PUMP 1/4" ....................... 1 .................. CONTACT PARTS DEPT. 17396 REAR WEAR RING, MP PUMP 3/16" ..................... 1 .................. W\ SERIAL NUMBER TO ......
PAGE 34
CHECK VALVE ASSY. CHECK VALVE ASSY. 1 13 2 12 14 2 7 3 5 10 6 9 4 8 11 PAGE 34 — MQ DRY PRIME PUMP • PARTS MANUAL — REV.
PAGE 35
CHECK VALVE ASSY. CHECK VALVE ASSY. NO. PART NO. 1 17063 2 17076 3* 1605 4* 1928 10790 5* 17070 6* 17073 7* 17074 8* 17075 9* 17336 10* 19470 11* 20440 12 17077 13 17138 14 368699 PART NAME QTY. REMARKS PIN, DISCHARGE CHECK VALVE PIVOT 1 VALVE PLATE ASM, PUMP DISCHARGE .............. 1 .................. INCLUDES ITEMS W/* SCREW, HHC M8-1.25 X 25MM 1 SCREW, HHC M8-1.25 X 40MM .............................. 3 .................. S\N 170043 AND UP SCREW, HHC M6-1.00 X 30MM .............................. 3 ...
PAGE 36
IMPELLER AND WEAR PLATE ASSY. IMPELLER AND WEAR PLATE ASSY. 5 2 8 2 4 5 1 7 2 6 3 3 1 1 USE THREADLOCK: HIGH TEMP. LOCTITE BLUE 246 OR EQUIVALENT. TORQUE TO 60 FT-LBF (81.3 N-m) 2 USE ANTI-SEIZE OR EQUIVALENT TORQUE TO 60 FT-LBF (81.3 N-m) 3 USE THREADLOCK: HIGH TEMP. LOCTITE RED 272 OR EQUIVALENT. TORQUE TO 250 FT-LBF (338.9 N-m) PAGE 36 — MQ DRY PRIME PUMP • PARTS MANUAL — REV.
PAGE 37
IMPELLER AND WEAR PLATE ASSY. IMPELLER AND WEAR PLATE ASSY. NO. PART NO. PART NAME QTY. REMARKS 1 17006 IMPELLER, 285 X 80 PUMP .................................... 1 .................. FITS MP150S & MP200 17008 IMPELLER, 300 X 85 PUMP .................................... 1 .................. FITS MP200S 2 17011 SEPERATOR FLANGE, MP PUMP 1 3 17049 CAP, MP PUMP IMPELLER 1 4 17092 FRONT WEAR PLATE, MP PUMP .......................... 1 .................. FITS MP200S 17386 FRONT WEAR PLATE, MP PUMP ............
PAGE 38
PRIMING TANK ASSY. (1) PRIMING TANK ASSY. (1) 1 4 2 6 5 1 14 9 17 15 2 9 3 16 7 10 11 11 5 1 13 1 USE THREADLOCK: HIGH TEMP. LOCTITE BLUE 246 OR EQUIVALENT. TORQUE TO 50 FT-LBF (67.9 N-m) 2 P\N 17265: 10.5” (26.67 cm) CLEAR HOSE WIRE REINFORCED PAGE 38 — MQ DRY PRIME PUMP • PARTS MANUAL — REV.
PAGE 39
PRIMING TANK ASSY. (1) PRIMING TANK ASSY. (1) NO. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 PART NO. 11644 17036 17038 17039 17099 17122 17137 17211 17212 17214 17215 17217 17218 17219 17265 17438 26405 PART NAME QTY. REMARKS SCREW, HHC 10-32 X 5/8, W/WSHR PLATED 6 FILLER CAP ASSY., LENZ PN FCS-1303-24 1 GASKET, PRIMING TANK ACCESS PANEL 1 GASKET, PRIMING TANK FLOAT VALVE 1 SCREW, HHC M12-1.75X20 ZN, DIN933 CL8.8 10 FLOAT VALVE ASSY, MP PUMP ............................ 1 ..................
PAGE 40
PRIMING TANK ASSY. (2) PRIMING TANK ASSY. (2) 12 7 2 5 14 15 1 1 17 2 2 15 7 1 1 9 5 5 16 2 11 2 7 1 USE THREADLOCK: HIGH TEMP. 6 LOCTITE BLUE 246 OR EQUIVALENT. TORQUE TO 14 FT-LBF (18.9 N-m) 2 P\N 17265: 36 IN (91.44 cm) HOSE 1.25” ID CLEAR, WIRE REINFORCED 13 10 PAGE 40 — MQ DRY PRIME PUMP • PARTS MANUAL — REV.
PAGE 41
PRIMING TANK ASSY. (2) PRIMING TANK ASSY. (2) NO. PART NO. PART NAME QTY. REMARKS 1 1605 SCREW, HHC M8-1.25 X 25MM 8 2 17208 FITTING, 90 1.25MP X 1.25FP GALV 4 3 17209 FITTING, STR 1.25MP X .75FP, GALV 1 4 17211 FITTING, TEE 1.25FPX1.25FPX1.25FP, GALV 1 5 17212 FITTING, STR 1.25MPX1.25BARB, GALV 3 6 17214 FITTING, NIPPLE 3/4 MP CLOSE, GALV 2 7 17215 FITTING, NIPPLE 1-1/4 MP CLOSE, GALV 3 8 17216 FITTING, PLUG 1.
PAGE 42
MQ DRY PRIME PUMP —FLOAT VALVE ASSY. FLOAT VALVE ASSY. 1 1 7 4 6 5 8 2 2 9 3 1 USE THREADLOCK: HIGH TEMP. LOCTITE BLUE 246 OR EQUIVALENT. TORQUE TO 14 FT-LBF (18.9 N-m) 2 USE THREADLOCK: HIGH TEMP. LOCTITE BLUE 246 OR EQUIVALENT. TORQUE TO 10 FT-LBF (13.5 N-m) PAGE 42 — MQ DRY PRIME PUMP • PARTS MANUAL — REV.
PAGE 43
FLOAT VALVE ASSY. FLOAT VALVE ASSY. NO. PART NO. 1 17098 2 17115 3 17123 4 17125 5 17126 6 17127 7 17128 8 17406 9 368699 PART NAME SCREW, FHSC M8-1.25X30 SS, DIN7991 SCREW, FHSC M6-1.00X20 SS, DIN7991 BASE W/A, MP PUMP, FLOAT VALVE HINGE, MP PUMP, FLOAT VALVE SHIM, FLOAT VALVE HINGE BACKING PLATE, FLOAT VALVE HINGE SHIM, FLOAT VALVE HINGE MP PUMP FLOAT ARM W\A FITTING, PLUG 6MO HEX SKT HD QTY. 2 4 1 1 2 1 1 1 1 REMARKS MQ DRY PRIME PUMP • PARTS MANUAL — REV.
PAGE 44
BATTERY ASSY. BATTERY ASSY. 2 4 1 3 PAGE 44 — MQ DRY PRIME PUMP • PARTS MANUAL — REV.
PAGE 45
BATTERY ASSY. BATTERY ASSY. NO. 1 2 3 4 PART NO. 17292 17269 17294 17293 PART NAME BATTERY, 12V GROUP 31 1125CCA BATTERY BOX, GRP 27 CABLE, BATTERY POS 0 GA X 31" POST CABLE, BATTERY NEG 0 GA X 24" POST QTY. 1 1 1 1 REMARKS MQ DRY PRIME PUMP • PARTS MANUAL — REV.
PAGE 46
FUEL TANK ASSY. FUEL TANK ASSY. 10 4 1 16 2 5 11 6 14 1 3 15 11 3 8 9 12 7 13 1 4 PAGE 46 — MQ DRY PRIME PUMP • PARTS MANUAL — REV.
PAGE 47
FUEL TANK ASSY. FUEL TANK ASSY. NO. PART NO. 1* 4684 2 8151 3 16185 4* 17101 5 17102 6 17169 7 17184 8 17210 9 17216 10 17245 11 17268 12 17272 13* 17270 14 17274 15 17278 16 17279 17* 17285 18 60028 PART NAME QTY. REMARKS WASHER, FLAT SAE 5/8 PLTD 20 WASHER, FLAT SAE 3/4 4 FITTING, PLUG 1/4 MP SQ HD 3 SCREW, HHC M16 - 2.00 X 40 ZN 12 SCREW, HHC M20-2.5 X 40MM ZN, DIN 933 CL8.8 4 SCREW, HHC M16-2.00 X 25 DIN 933 CL 10.9 8 FUEL TANK, MP PUMP 1 FITTING, STR 1.25MP X .25FP GALV 2 FITTING, PLUG 1.
PAGE 48
TRAILER ASSY. (TRAILER LIGHTS) TRAILER ASSY. (TRAILER LIGHTS) 6 7 9 8 5 1 2 10 6 3 11 4 PAGE 48 — MQ DRY PRIME PUMP • PARTS MANUAL — REV.
PAGE 49
TRAILER ASSY. (TRAILER LIGHTS) TRAILER ASSY. (TRAILER LIGHTS) NO. PART NO. PART NAME QTY. 1 1319 TERMINAL RING, 16-14 1/4" LOOP 2 2 2203 WASHER FLAT #10 2 3 17113 NUT, HEX FINISH M6-1.
PAGE 50
TRAILER ASSY. (SURGE BRAKE) TRAILER ASSY. (SURGE BRAKE) 19 18 20 2 14 4 16 22 24 8 3 5 13 27 6 9 32 7 5 1 36 3 21 12 6 25 4 11 2 27 11 10 1 15 26 28 33 31 29 35 30 28 17 27 34 35 23 2 11 PAGE 50 — MQ DRY PRIME PUMP • PARTS MANUAL — REV.
PAGE 51
TRAILER ASSY. (SURGE BRAKE) TRAILER ASSY. (SURGE BRAKE) NO. PART NO. PART NAME QTY. REMARKS 1 0447 WASHER, FLAT 1/2 SAE 24 2* 4684 WASHER, FLAT SAE 5/8 PLTD 25 3 8126 CLAMP, HOSE SUPPORT 1/2" SMALL 2 4 9502 SCREW, HHC 5/8-11 X 4-1/2 GR8 3 5 9503 NUT, NYLOC 5/8-11 3 6 9509 SCREW, TEK 12 X 3/4 SELF TAP 2 7 10176 NUT, NYLOC 1/2-13 3 8 10306 SCREW, HHC 1/2-13 X 4-1/2 3 9 10463 CLAMP, HOSE WORM 6 1/8 - 7.0 SIZE 104 4 10 16057 SCREW, HHC M12-1.75 X 40MM 12 11* 17101 SCREW, HHC M16-2.00X40 ZN, DIN933 CL8.
PAGE 52
TRAILER ASSY. (ELECTRIC BRAKE) TRAILER ASSY. (ELECTRIC BRAKE) 20 21 19 2 8 17 3 15 9 24 3 4 22 6 30 11 2 5 30 27 8 25 26 23 14 16 7 1 12 10 4 18 5 13 2 8 28 PAGE 52 — MQ DRY PRIME PUMP • PARTS MANUAL — REV.
PAGE 53
TRAILER ASSY. (ELECTRIC BRAKE) TRAILER ASSY. (ELECTRIC BRAKE) NO. PART NO. PART NAME QTY. REMARKS 1 0447 WASHER, FLAT 1/2 SAE 24 2 4684 WASHER, FLAT SAE 5/8 PLTD 25 3 9502 SCREW, HHC 5/8-11 X 4-1/2 GR8 3 4 9503 NUT, NYLOC 5/8-11 3 5 9509 SCREW, TEK 12 X 3/4 SELF TAP 3 6 16055 NUT, HEX M8-1.25 2 7 16057 SCREW, HHC M12-1.75 X 40MM 12 8 17101 SCREW, HHC M16-2.00X40 ZN, DIN933 CL8.8 16 9 17114 NUT, HEX FINISH M12-1.750 ZN, DIN934 CL8 12 10 17181 HARNESS, MP PUMP ELEC.
PAGE 54
NOTE PAGE PAGE 54 — MQ DRY PRIME PUMP • PARTS MANUAL — REV.
PAGE 55
TERMS AND CONDITIONS OF SALE — PARTS PAYMENT TERMS 5. Parts must be in new and resalable condition, in the original Multiquip package (if any), and with Multiquip part numbers clearly marked. 6. The following items are not returnable: Terms of payment for parts are net 30 days. FREIGHT POLICY All parts orders will be shipped collect or prepaid with the charges added to the invoice. All shipments are F.O.B. point of origin.
PAGE 56
PARTS MANUAL HERE’S HOW TO GET HELP PLEASE HAVE THE MODEL AND SERIAL NUMBER ON-HAND WHEN CALLING UNITED STATES Multiquip Corporate Office 18910 Wilmington Ave. Tel. (800) 421-1244 Carson, CA 90746 Fax (800) 537-3927 Contact: mq@multiquip.com Mayco Parts 800-306-2926 Fax: 800-672-7877 310-537-3700 Fax: 310-637-3284 Service Department 800-421-1244 Fax: 310-537-4259 310-537-3700 MQ Parts Department 800-427-1244 Fax: 800-672-7877 310-537-3700 Fax: 310-637-3284 MEXICO UNITED KINGDOM MQ Cipsa Carr. Fed.
