DCA70SSIU2 60 HZ GENERATOR • OPERATION AND PARTS MANUAL — REV. #0 (05/29/09) — PAGE 73
ENCLOSURE ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 M2413002102 BASE 1
1A M2493000004 ACOUSTIC SHEET 1
2 M1413400004 UNDER COVER 1
3 0016908020 HEX HEAD BOLT 2
4 M2413600004 DUCT 1
4A M2493000104 ACOUSTIC SHEET 1
5 0016908020 HEX HEAD BOLT 4
6 M2423001902 FRONT FRAME 1
6A M2493108703 ACOUSTIC SHEET 1
6B 0228800100 SEAL RUBBER 4
7 0016908020 HEX HEAD BOLT 6
8 M2423202504 COVER, FRONT FRAME 1
8A M2493101104 ACOUSTIC SHEET 1
9 0019208020 HEX HEAD BOLT 14
10 M2423202703 INNER COVER, FRONT FRAME 1
11 0016908020 HEX HEAD BOLT 7
12 M2310200603 SUPPORTER, INTER COOLER 1
13 0017110020 HEX HEAD BOLT 4
14 M2310200504 BRACKET, INNER COOLER 2
15 0016908020 HEX HEAD BOLT 8
16 M2310302803 FAN SHROUD 1
17 M2310302903 FAN SHROUD 1
18 0016908020 HEX HEAD BOLT 6
19 0016908020 HEX HEAD BOLT 4
20 M2310303004 FAN GUARD 1
21 M2310303103 FAN GUARD 1
22 0016908020 HEX HEAD BOLT 9
23 M2435000203 HANGER 1
24 M2433001103 HANGER 1
25 0010114030 HEX HEAD BOLT 8
25A 0040014000 WASHER, LOCK 8
25B 0041214000 WASHER, FLAT 8
26 0017112030 HEX HEAD BOLT 10
27 M2443001302 REAR FRAME 1
27A M2493305404 ACOUSTIC SHEET 2
28 0016908020 HEX HEAD BOLT 4
29 M2443301203 REAR COVER 1
30 M2443301703 DUCT, REAR COVER 1
30A M2493305303 ACOUSTIC SHEET 1
31 0207006000 HEX NUT 12
32 0019208020 HEX BOLT 9
33 M2443200123 REAR DOOR 1
34 M1443600204 WINDOW PLATE 1
35 0037906000 HEX NUT 8
35A 0041206000 WASHER, FLAT 8
