DCA70SSIU2 60 HZ GENERATOR • OPERATION AND PARTS MANUAL — REV. #0 (05/29/09) — PAGE 71
FUEL TANK ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 M2363000102 FUEL TANK 1
1-1 0605505070 CAP, FUEL TANK 1
1-2 0605501074 FUEL SENDER UNIT 1
1-2A 0605516090 GASKET 1
1-3 0027104016 MACHINE SCREW 5
2 M2363200104 TANK BAND 2
3 M9310500104 SUPPORTER SHEET 4
4 0016908020 HEX HEAD BOLT 2
5 0207308000 HEX NUT 2
6 0222100178 RUBBER SHEET 4
7 M9200000003 DRAIN JOINT 1
8 M9200200004 DRAIN BOLT 1
9 0150000018 O-RING 1
10 0016906020 HEX HEAD BOLT 2
11 M1363400104 DRAIN HOSE 1
12 0605515198 HOSE BAND 2
13 M2366700203 FUEL FILTER BRACKET 1
14 0016910025 HEX HEAD BOLT 2
15 0016908020 HEX HEAD BOLT 2
16 M2366700104 FUEL PUMP BRACKET 1
17 0016908020 HEX HEAD BOLT 2
18 8980139861 FUEL FILTER (MAIN) ..................................1 ................REPLACES P/N 0602042426
18A 8980088400 ELEMENT, FUEL FILTER, (MAIN) ..............1 ................REPLACES P/N 0602042515
19 8980758550 FUEL FILTER (PRE) ...................................1 ................REPLACES P/N 0602042405
19A 8980758540 ELEMENT, FUEL FILTER, (PRE) ................1 ................REPLACES P/N 0602042516
20 8973834270 JOINT PIPE .................................................1 ................REPLACES P/N 0602042661
21 1096750951 JOINT BOLT ................................................4 ................REPLACES P/N 0602042621
22 1096300860 PACKING .....................................................8 ................REPLACES P/N 0602042641
23 0015310045 HEX SOCKET HEAD CAP SCREW 4
23A 0040010000 WASHER, LOCK 4
23B 0041210000 WASHER, FLAT 4
24 0010110080 HEX HEAD BOLT 2
24A 0040010000 WASHER, LOCK 2
24B 0041210000 WASHER, FLAT 2
25 8980682750 FUEL FEED PUMP .....................................1 ................REPLACES P/N 0602023240
25A 8980714010 FUEL FILTER ..............................................1 ................REPLACES P/N 0602042517
26 0016906025 HEX HEAD BOLT 2
27 0191301750 SUCTION HOSE 1
28 0191300650 SUCTION HOSE 1
29 0191300450 SUCTION HOSE 1
30 0191301400 SUCTION HOSE 1
31 0191302150 RETURN HOSE 1
32 0605515109 HOSE BAND 10
33 0602220911 CLAMP 1
34 0016908020 HEX HEAD BOLT 1
