DCA70SSIU2 60 HZ GENERATOR • OPERATION AND PARTS MANUAL — REV. #0 (05/29/09) — PAGE 61
ENGINE AND RADIATOR ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 M2923200144 ENGINE, ISUZU BJ-4JJ1X 1
1A 8973629260 FAN BELT ....................................................1 ................REPLACES P/N 0602015256
1-1 8980188580 CARTRIDGE, OIL FILTER ..........................1 ................REPLACES P/N 0602041222
2 0605000451 RUBBER SUSPENSION 2
3 M2413800104 COLLER 2
4 0030010000 HEX NUT 1
5 0040010000 WASHER, LOCK 2
6 0042810000 WASHER, FLAT 2
7 M2923200074 RADIATOR 1
7-1 0602011029 CAP, RADIATOR 1
8 0016908020 HEX HEAD BOLT 6
9 M9200100904 PLUG 1
10 0150000016 O-RING 1
11 M2310502003 RADIATOR HOSE, UPPER 1
12 M2310502103 RADIATOR HOSE, LOWER 1
13 0605515147 HOSE BAND 4
14 M2923200124 INTER COOLER 1
15 0132004000 PLUG, 3/8" 1
16 0010510020 HEX HEAD BOLT 8
16A 0040010000 WASHER, LOCK 8
16B 0041210000 WASHER, FLAT 8
17 M2310501903 INTER COOLER HOSE 1
18 M2310501803 INTER COOLER HOSE 1
19 0605515208 HOSE BAND 3
20 0605515207 HOSE BAND 1
21 0193601000 DRAIN HOSE 1
22 0602046582 AIR CLEANER 1
22A 0602046365 ELEMENT, AIR CLEANER 1
23 0602040651 INDICATOR, AIR CLEANER 1
24 0602040554 AIR CLEANER BAND 1
25 0016908030 HEX HEAD BOLT 2
26 M2373101603 HOSE, AIR CLEANER 1
27 M2326100304 BLOWBY PIPE 1
28 M2373101503 HOSE, AIR CLEANER 1
29 M2373101403 HOSE, AIR CLEANER 1
30 0605515230 HOSE BAND 1
31 0605515197 HOSE BAND 4
32 0191500770 BLOWBY HOSE 1
33 0605515149 HOSE BAND 2
34 M3326200204 BLOWBY HOSE BRACKET 1
35 0016908020 HEX HEAD BOLT 1
36 M2320300103 DRAIN JOINT 1
37 M9200200004 PLUG 1
38 0150000018 O-RING 1
39 0016906020 HEX HEAD BOLT 2
