DCA70SSIU2 60 HZ GENERATOR • OPERATION AND PARTS MANUAL — REV. #0 (05/29/09) — PAGE 55
NO. PART NO. PART NAME QTY. REMARKS
1 M2213001602 CONTROL BOX 1
1-1 0330000180 EDGING 2
1-2 0330000615 EDGING 1
1-3 0330000300 EDGING 2
2 0601870432 CIRCUIT BREAKER, 175A 1
2-1 0601870490 COVER, CIRCUIT BREAKER 2
3 0021004040 MACHINE SCREW 4
4 0601823863 RELAY UNIT 2
5 0027104016 MACHINE SCREW 4
6 0601820602 AUTOMATIC VOLTAGE REGULATOR 1
7 0027105016 MACHINE SCREW 4
8 0601801123 CURRENT TRANSFORMER 3
9 0027106020 MACHINE SCREW 6
10 0601820847 OVER CURRENT RELAY 1
11 0601820848 OVER CURRENT RELAY 1
12 0027104016 MACHINE SCREW 2
12A 0207004000 HEX NUT 2
13 M2260500204 SET PANEL, ELECTRIC PARTS 1
14 0016906016 HEX HEAD BOLT 4
15 0601802218 HOLDER, FUSE 1
15A 0601806671 FUSE, 15A 3
16 0027103020 MACHINE SCREW 1
17 LY20DC12V RELAY .........................................................2 ................REPLACES P/N 0601827656
17A PTF08A BASE ...........................................................2 ................REPLACES P/N 0601823109
17B PYCAT CLIP ............................................................4 ................REPLACES P/N 0601824400
18 0027104020 MACHINE SCREW 4
19 0601815153 TERMINAL 1
20 0027104016 MACHINE SCREW 2
21 8121468300 SENSOR, INLET AIR TEMP. .......................1 ................REPLACES P/N 0603210240
22 8980980660 CONTROLLER ............................................1 ................REPLACES P/N 0602202689
23 M3260500604 BRACKET 1
24 0016906016 HEX HEAD BOLT 4
25 0601831205 PUSH BUTTON SWITCH 1
26 0601831330 DIAGNOSTIC SWITCH 1
27 0016916016 HEX HEAD BOLT 4
28 0601823240 RECTIFIER 1
29 0027105020 MACHINE SCREW 1
30 8972177780 SENSOR, BAROMETRIC PRESSURE ......1 ................REPLACES P/N 0602130220
31 M2260600104 BRACKET, SENSOR 1
32 0027105016 MACHINE SCREW 2
33 0027105016 MACHINE SCREW 2
34 8942481610 RELAY, STARTER .......................................1 ................REPLACES P/N 0602202502
CONTROL BOX ASSY.
