DCA45SSIU3 50 HZ GENERATOR • OPERATION AND PARTS MANUAL — REV. #2 (12/19/08) — PAGE 53
NO. PART NO. PART NAME QTY. REMARKS
1 M1213000802 CONTROL BOX 1
2 0601870431 CIRCUIT BREAKER ....................................1 ................FG3110WS02 3P 110A
2-1 0601870490 COVER, CIRCUIT BREAKER 2
3 0021004040 MACHINE SCREW 4
4 0601823863 RELAY UNIT................................................2 ................MSA9013A
5 0027104016 MACHINE SCREW 4
6 0601820671 AUTOMATIC VOLTAGE REGULATOR ........1 ................NTA-5A-2DB
7 0027105016 MACHINE SCREW 4
8 0601806116 CURRENT TRANSFORMER ......................3 ................812-943 75/5A
9 0027106016 MACHINE SCREW 6
10 0601820847 OVER CURRENT RELAY ...........................1 ................TA25DU 4.0
11 0027120848 OVER CURRENT RELAY ...........................1 ................DB25/25A
12 0027104016 MACHINE SCREW 2
12A 0207004000 HEX NUT 2
13 0330000200 EDGING 1
14 M1213500303 CONTROL BOX COVER 1
15 0016906016 HEX HEAD BOLT 4
16 M1923100004 SELECTOR SWITCH ..................................1 ................VY-40
16A 47130106 KNOB. SELECTOR SWITCH 1
17 M1213600114 SWITCH BRACKET 1
18 0330000160 EDGING 2
19 0027103010 MACHINE SCREW 4
20 0016906016 HEX HEAD BOLT 4
21 M1213600014 SWITCH COVER 1
22 0016906016 HEX HEAD BOLT 4
23 0016906016 HEX HEAD BOLT 8
23A 0040506000 TOOTHED WASHER 1
24 M1223000503 CONTROL PANEL 1
25 0601807641 FREQUENCY METER ................................1 ................FCF-6 45~65Hz 240V
26 0601808986 AC AMMETER ............................................1 ................ACF-6 0~75A/150A:5A
27 0601801040 CHANGE-OVER SWITCH, AMMETER .......1 ................SL-2 AS
28 0601806859 AC VOLTMETER .........................................1 ................SCF-6 0~600V
29 0601801041 CHANGE-OVER SWITCH, VOLTMETER ...1 ................SL-2 VS
30 0601840073 RHEOSTAT (VOLTAGE REGULATOR) .......1 ................RA20A2SE102BJ 2W 1K W
31 0601840121 KNOB 1
32 M1223100004 STOPPER 1
33 0027105010 MACHINE SCREW 2
34 0027105010 MACHINE SCREW 4
35 M9220100004 SET SCREW 1
36 0080200007 SNAP RING 1
37 8971119621 EMERGENCY RELAY .................................1 ................REPLACES P/N 0602200432
38 8972465100 PREHEAT CONTROLLER ..........................1 ................REPLACES P/N 0602202506
39 0016906020 HEX HEAD BOLT 3
40 1825530401 SAFETY RELAY ..........................................1 ................REPLACES P/N 0602200304
41 5825500290 RELAY .........................................................1 ................REPLACES P/N 0602201400
42 0016906016 HEX HEAD BOLT 3
43 M1246702604 WIRE HARNESS, GENERATOR 1
CONTROL BOX ASSY.
