ENCLOSURE ASSY.
    
1 M1414000502 BASE 1
2 M1415100202 ENVIRONMENTAL TANK 1
3 0016910030 HEX. HEAD BOLT 6
4 0603306797 SQUARE HEAD PIPE PLUG 1-1/2” 1
5 Y0603306793 SQUARE HEAD PIPE PLUG 1/2” 1
6 M1424000602 FRONT FRAME 1
6A M1494101703 ACOUSTIC SHEET 1
6B M1494105304 ACOUSTIC SHEET 1
7 0016908020 HEX. HEAD BOLT .............................................4................REPLACES P/N 0016908020
8 M1424200903 COVER, FRONT FRAME .................................1................REPLACES P/N 0207006000
8A M1494101804 ACOUSTIC SHEET 1
9 0019208020 HEX. HEAD BOLT 11
10 0601850239 GROMMET 1
11 M1311200004 RADIATOR BRACKET 1
12 M1311200104 RADIATOR BRACKET 1
13 M1311200204 RADIATOR BRACKET 2
14 011008020 HEX. HEAD BOLT .............................................4................REPLACES P/N 0016908020
15 M1311600203 FAN SHROUD 1
16 M1311600303 FAN SHROUD 1
17 011008020 HEX. HEAD BOLT .............................................6................REPLACES P/N 0016908020
18 M1311300103 FAN GUARD 1
19 M1311300203 FAN GUARD 1
20 011008020 HEX. HEAD BOLT .............................................6................REPLACES P/N 0016908020
21 M1434000003 CENTER FRAME 1
22 M1434000103 CENTER FRAME 1
23 0012312030 HEX. HEAD BOLT .............................................4................REPLACES P/N 0013612030
23A 0040012000 WASHER, LOCK 4
23B 031112230 WASHER, FLAT ................................................4................REPLACES P/N 0041212000
24 M1484500104 FUEL LEAK SWITCH BRACKET 1
25 011206020 HEX. HEAD BOLT .............................................2................REPLACES P/N 0016906020
26 0605503066 FUEL LEAK DETECTED SWITCH 1
27 0012312030 HEX. HEAD BOLT .............................................4................REPLACES P/N 0013612030
27A 0040012000 WASHER, LOCK 4
27B 031112230 WASHER, FLAT ................................................4................REPLACES P/N 0041212000
28 M1444000202 REAR FRAME 1
29 011008020 HEX. HEAD BOLT .............................................4................REPLACES P/N 0016908020
30 M1444300103 REAR COVER 1
31 M1444800303 DUCT, REAR COVER 1
31A M1494301103 ACOUSTIC SHEET 1
32 0176060030 SELF-LOCKING NUT .......................................5................REPLACES P/N 0207006000
33 0019208020 HEX. HEAD BOLT 7
34 M1444200103 REAR DOOR 1
35 M1444600104 WINDOW PLATE 1
36 020106050 LOCK NUT ........................................................7................REPLACES P/N 0037906000
36A 952404470 WASHER, FLAT ................................................7................REPLACES P/N 0041206000
37 Y0605012309 DOOR HANDLE ASSY. 1
37A C9312500004 SEAL RUBBER 1
38 C9312500004 SELF-LOCKING NUT 4
39 M9110100204 HINGE 2
