OUTPUT TERMINAL ASSY.
    
1 M1230700203 TERMINAL PANEL 1
2 M9220000204 OUTPUT TERMINAL BOLT 4
3 M9220000104 TIE BOLT 4
4 0039308000 HEX. NUT 8
5 0040008000 WASHER, LOCK 12
6 0041408000 WASHER, FLAT 16
7 011606025 HEX. HEAD BOLT .............................................4................REPLACES P/N 0016906025
8 M1237100103 3-PHASE OUTPUT TERMINAL 1
9 M1236100404 OUTPUT WINDOW 1
10 0605010040 HINGE 2
11 0027103010 MACHINE SCREW 4
11A 0207003000 HEX. NUT .........................................................4................REPLACES P/N 0030003000
11B 0041203000 WASHER, FLAT 4
12 0027103010 MACHINE SCREW 4
12A 0207003000 HEX. NUT .........................................................4................REPLACES P/N 0030003000
13 M9220100804 SET SCREW 2
13A 0040006000 WASHER, LOCK 2
13B 952404470 WASHER, FLAT ................................................2................REPLACES P/N 0041206000
13C 0080200005 E-SNAP RING 2
14 011106015 HEX. HEAD BOLT .............................................4................REPLACES P/N 0016906015
15 M1236400004 CABLE OUTLET COVER 1
16 M1236300004 SUPPORTER, CABLE OUTLET COVER 1
17 011206020 HEX. HEAD BOLT .............................................6................REPLACES P/N 0016906020
18 0601815194 TERMINAL BLOCK 1
19 7538070 MACHINE SCREW ...........................................2................REPLACES P/N 0027104015
20 0040508000 TOOTHED WASHER 1
21 0019208020 HEX. HEAD BOLT 1
22 0601870440 CIRCUIT BREAKER, 1P 20A 2
23 0601870441 CIRCUIT BREAKER, 2P 50A 2
24 M1260700404 BREAKER FITTING COVER 1
24-1 0222100080 CUSHION RUBBER 2
25 011206020 HEX. HEAD BOLT .............................................2................REPLACES P/N 0016906020
26 0601814013 RECEPTACLE, 125V 20A X 2 2
27 Y0601814014 RECEPTACLE, 250V 50A 2
28 7538070 MACHINE SCREW ...........................................8................REPLACES P/N 0027104015
28A OEMAA8 HEX. NUT .........................................................8................REPLACES P/N 0207004000
29 M1236400104 COVER 1
30 011106015 HEX. HEAD BOLT .............................................4................REPLACES P/N 0016906015
31 M1237100003 TERMINAL COVER 1
32 012212045 HEX. HEAD BOLT .............................................2................REPLACES P/N 0010112045
33 031112230 WASHER, FLAT ................................................6................REPLACES P/N 0041212000
34 0030012000 HEX. NUT 2
35 0605050060 CONICAL LOCK WASHER 2
