BRT RIDE-ON POWER TROWEL — OPERATION & PARTS MANUAL — REV. #1 (01/13/03) — PAGE 27
GEARBOX ASSY. (RIGHT-SIDE) WITH 1-1/8 DIA. SHAFT.
NO PART NO PART NAME QTY. REMARKS
1 0121 A FITTING, PLUG 3/8MP SQ HEAD 3
2 10031 WASHER, COPPER 1/4 8
3
*
0232 BEARING, CONE, TIMKEN #1985 2
4
*
0232 A BEARING, CUP, TIMKEN #1932 4
5 0424 SCREW, HHC 1/4-20 X 1-1/4 1
6 2295 SCREW, HHC 1/4-20 X 1 8
7 10930 WASHER, FLAT, 1/4 SAE 1
8 10237 EXT. SHKP WASHER 1
9 10138 SCREW, SHS 1/4-20 X 1/2, N.P. 1
10 10235 WASHER, C/S EXT. SHKP, 5/16 4
11 10139 GEARBOX LUBRICATING OIL (BOTTLE) .................. 3 ........ THREE 22 OZ. BOTTLES REQD.
12 10492 GEARBOX CASE ONLY ............................................. 1 ........ S/N LD39205 AND BELOW
12 10800 GEARBOX CASE ONLY ............................................. 1 ........ S/N LD39206 AND ABOVE
13 10890 FAN COVER, RIGHT SIDE 1
14 10921 FAN, AAI 3.5 X 1.5 CW ROT 1
15 10930 WASHER, FENDER, 1/4 X 1-1/4 1
16 10989 STUD, 10-32 X 3/4 1
17 1132 VENT, AIR 1
18 1138 RING, SNAP, TRUARC 5100-112 1
20 1146 SCREW, FHSC 5/16-18 X 1, NYLOC, NP 4
23 10493 RS WORM AND C/SHAFT W/BEARING .................... 1 ........ S/N LD39205 AND BELOW 7-1/4"
23 10876 RS WORM AND C/SHAFT W/BEARING .................... 1 ........ S/N LD39206 AND ABOVE 8-1/4"
24 1146 SCREW, FHSC 3/8-24 X 3/4 PLAIN 1
25 5065B HEX SLOTED WASHER HEAD 10-32 X ½ 2
27 2249 GEAR, WORM GEAR RH 1
28 2030 COUPLER- 7/8” ID 1
29 2115 RING, O, SIZE –022, BUNA-N 2
30 2203 WASHER, FLAT, #10 3
31 10498 COUNTERSHAFT FLANGE 2
32# 2308 RING, O 2 13/16” 2
33 2126 KEY, 1/4 X 1/4 X 13/16 1
35 1145 PLATE, COVER 1
36# 2633 SHIM, (.005, .010, AND .020) 1
37# 1143 RING, O, A-264 1
38# 10461 SEAL, OIL, 471763 1
39 10497 SPACER, 1-1/4 X 1 X 1.375L 2
40 10460 SEAL, OIL, NATIONAL #471413 2
41
*
10501 BEARING, CONE, TIMKEN #1986 2
42# 2633 SHIM, (.002, .003, .005, .010, AND .020) 1
43 2037 RETAINER, DRIVEN PULLEY 1
44 2231 MAINSHAFT 1
45 2229 KEY, 5/16 X 2-1/4 HRDND 1
46 10518 BEARING KIT ............................................................ 1 ........ INCLUDES ITEMS W/
*
47 2633 SEAL KIT ................................................................... 1 ........ INCLUDES ITEMS W/#
48 10966 GEARBOX ASSY. 1
BRT RIDE-ON POWER TROWEL— GEARBOX ASSY. (RIGHT-SIDE)
