BHN RIDE-ON POWER TROWEL — PARTS & OPERATION MANUAL — REV. #1 (10/17/02) — PAGE 47
SINGLE PITCH CONTROL ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 1162A LUBRA- CAP 2
2 2621 GREASE FITTING 2
3 4403 CRANK KNOB 2
4 3231 SPACER 2
5 10512 SNAP RING 2
6 2575 CRANK LEVER 2
7 1616 SHOULDER BOLT 2
8 1111 BEARING 2
9 10646 TROWEL CONTROL SCREW 2
10 0786 BHCS 1/4- 20 X 3/8” 2
11 10382 SHOULDER BOLT 2
12 10723 ROLL PIN 2
13 2008 CABLE 2
14 2170 THRUST WASHER 6
15 2300 LOCK WASHER 5/16” 2
16 4014 U- DRIVE SCREW 2 X 3/16” 4
17 5283 LOCK NUT 5/16- 18 8
18 0300B FLAT WASHER 5/16” 8
19 0202 HHCS 5/16- 18 X 1” 8
20 10548 PITCH CONTROL TUBE 2
21 1116 BRASS JAM NUT 4
22 10721 SLIDE BLOCK 2
23 2367 SET COLLAR 2
24 1604 THRUST BEARING 2
25 0185 SHSS 3/8- 16 X 3/8” 2
26 1733 HARDENED WASHER 2
27 2169 THRUST BEARING 2
BHN RIDE-ON POWER TROWEL— SINGLE PITCH CONTROL ASSY.
