BHN RIDE-ON POWER TROWEL — PARTS & OPERATION MANUAL — REV. #1 (10/17/02) — PAGE 21
HONDA ENGINE ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 20 HP HONDA ENGINE 1
2 2192 THROTTLE SPRING 1
3 2194 THROTTLE NUT 1
4 10568 THROTTLE CABLE 1
5 2153 SPHERICAL BEARING 1
6 0937 HEX NUT 10- 32 1
7 10990 SHOULDER BOLT 1
8 10964 THROTTLE CABLE MOUNTING BRACKET 1
9 0310 SQUARE KEY 1/4 X 1/4 X 1.1/2” 1
10 2516 4” CLUTCH ASM. 1” BORE 1
11 1882 CLUTCH SPINDLE 1
12 1886 CLUTCH PULLEY ASM. 1
13 2504 CLUTCH BOWL ASM. 1
14 2939 CLUTCH WEIGHT SET 1
15 2450 WEIGHT SPRING 2
16 2506 CLUTCH PLATE (WITH ROLLERS) 1
17 1893 SHSS 3/8- 24 X 5/8” 2
18 9123 CLUTCH RETAINER 1
19 0166A LOCK WASHER 3/8” 1
20 2667 HHCS 3/8- 24 X 2.1/2” 1
21 10517 DRIVE BELT A41 2
22 10956 BELT GUARD 1
23 1273 HHSTS 8- 32 X 3/8” 4
24 2334 HHCS 7/16- 14 X 3.1/4” 1
25 2257 BELT GUIDE 1
26 0205 HHCS 3/8- 16 X 1” 4
27 0300B FLAT WASHER 5/16” 2
28 8156 HHCS 3/8- 16 X 2.1/2” 4
29 0730 HHCS 1/4- 20 X 1” 2
30 5065B RHMS 10- 32 X 1/2” 6
31 10927 CONTROL PANEL 1
32 10019 LOCK NUT 10- 32 8
33 2655 HOUR METER 1
34 10954 THROTTLE LEVER 1
47 10958 IGNITION SWITCH W /KEY 1
48 1618 LOCK NUT 10- 24 1
49 10963 OIL DRAIN VALVE 1
50 2207 SOLENOID 1
BHN RIDE-ON POWER TROWEL— HONDA ENGINE ASSY.
