BHN RIDE-ON POWER TROWEL — PARTS & OPERATION MANUAL — REV. #1 (10/17/02) — PAGE 17
ONAN ENGINE ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 24 HP ONAN ENGINE 1
2 2192 THROTTLE SPRING 1
3 2194 THROTTLE NUT 1
4 2124 THROTTLE CABLE 1
5 2153 SPHERICAL BEARING 1
6 0937 HEX NUT 10- 32 1
7 2190 SPACER 1
8 2628 THROTTLE CABLE MOUNTING BRACKET 1
9 4024 SQUARE KEY 1/4 X 1/4 X 2.3/4” 1
10 2517 4” CLUTCH ASM. 1.1/8” BORE 1
11 1883 CLUTCH SPINDLE1.1/8” BORE 1
12 1886 CLUTCH PULLEY 1
13 2504 CLUTCH BOWL 1
14 2451 CLUTCH WEIGHT 4
15 2450 WEIGHT SPRING 2
16 2506 CLUTCH PLATE (WITH ROLLERS) 1
17 1893 SHSS 3/8- 24 X 5/8” 2
18 2951 CLUTCH RETAINER 1
19 0166A LOCK WASHER 3/8” 3
20 8135 HHCS 3/8- 24 X 3” 1
21 10517 BELT (A- 41) 2
22 2333 BELT GUARD 1
23 1273 HHSTS 8- 32 X 3/8” 4
24 1284 HHCS 3/8- 16 X 1.1/2” 6
25 2631 BELT GUIDE 1
26 0300B FLAT WASHER 5/16” 8
27 5065B RHMS 10- 32 X 1/2” 2
28 2643 CONTROL PANEL 1
29 2655 HOUR METER 1
30 10490 LOCK NUT 3/8- NPT 1
BHN RIDE-ON POWER TROWEL— ONAN ENGINE ASSY.
