BHN RIDE-ON POWER TROWEL — PARTS & OPERATION MANUAL — REV. #1 (10/17/02) — PAGE 13
25 HP KOHLER ENGINE ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 25 HP KOHLER ENGINE 1
2 2192 THROTTLE SPRING 1
3 2194 THROTTLE NUT 1
4 2124 THROTTLE CABLE 1
5 2153 SPHERICAL BEARING 1
6 0937 HEX NUT 10- 32 1
7 2190 SPACER 1
8 2884 THROTTLE CABLE MOUNTING BRACKET 1
9 4024 SQUARE KEY 1
10 2517 4” CLUTCH ASM. 1.1/8” BORE 1
11 1883 CLUTCH SPINDLE1.1/8” BORE 1
12 1886 CLUTCH PULLEY 1
13 2504 CLUTCH BOWL 1
14 2451 CLUTCH WEIGHT 4
15 2450 WEIGHT SPRING 2
16 2506 CLUTCH PLATE (WITH ROLLERS) 1
17 1893 SHSS 3/8- 24 X 5/8” 2
18 2951 CLUTCH RETAINER 1
19 2955 LOCK WASHER 7/16” 1
20 2956 HHCS 7/16- 20 X 1.1/2” 1
21 11048 BELT (B- 39) 2
22 2134 BELT GUARD 1
23 1273 HHSTS 8- 32 X 3/8” 4
24 11020 CONTROL PANEL 1
25 2580 CHOKE CABLE 1
26 4514 HHCS 1/4- 20 X 5/8” 2
27 0300B FLAT WASHER 5/16” 4
28 0161C LOCK WASHER 5/16” 4
29 8381 BOOT 1
30 5065B RHMS 10- 32 X 1/2” 8
BHN RIDE-ON POWER TROWEL— 25 HP KOHLER ENGINE ASSY.
