Spare Parts
Product Product
Number
Description
Heating element with 8 mm bore
hole
HE-Inv-8
Heating element with 12 mm bore
hole
HE-Inv-12
Heating element with 23 mm bore
hole
HE-Inv-23
For MEA1060-Inv/MEA1060-Inv-BC amplifier.
Available with bore holes in different sizes,
for using smaller or larger microscope
objectives. The smallest size has the best
temperature controlling properties.
Heating element HE-Up For MEA1060-Up/MEA1060-Up-BC amplifier
Cable assembly CA For HE-Inv or HE-Up
0.5 m 68-Pin MCS Standard cable C68x0.5M
1 m 68-pin MCS Standard cable C68x1M
3 m 68-Pin MCS Standard cable C68x3M
For MEA- or ME-Systems
Ag/AgCl pellet P1060-Inv For MEA1060-Inv/MEA1060-Inv-BC amplifier
Ag/AgCl pellet P1060-Up For MEA1060-Up/MEA1060-Up-BC amplifier
Ag wire W1060-Inv For MEA1060-Inv/MEA1060-Inv-BC amplifier
Ag wire W1060-Up For MEA1060-Up/MEA1060-Up-BC amplifier
Solder lug SL1060-Inv For MEA1060-Inv/MEA1060-Inv-BC amplifier
Gold spring contacts GSC1060-Inv For MEA1060-Inv/MEA1060-Inv-BC amplifier
Gold spring contacts GSC1060-Up For MEA1060-Up/MEA1060-Up-BC amplifier
Gold spring contact comb GSCC1060-Up For MEA1060-Up/MEA1060-Up-BC amplifier
3-Pole cable (from STG to
MEA1060)
C3P With ground, not necessary for MEA1060BC
amplifiers
Red single pole cable (from STG
to MEA1060)
CR
Black single pole cable (from STG
to MEA1060)
CB
MEA-Systems
Product Product
Number
Description
MEA recording system for
inverted microscopes,
60 electrode channels
MEA60-Inv-
System
Complete with 5 MEAs, data acquisition
computer with MC_Card, MEA1060-Inv
amplifier, TC01, power supply, and accessories
MEA recording system for
inverted microscopes,
60 electrode channels, 2
MEA amplifiers
MEA60-Inv-2-
System
Complete with 5 MEAs, data acquisition
computer with MC_Card, 2 x MEA1060-Inv
amplifier, MEAS2/1, TC02, power supply,
and accessories
MEA recording system for
upright microscopes,
60 electrode channels
MEA60-Up-
System
Complete with 5 MEAs, data acquisition
computer with MC_Card, MEA1060-Up
amplifier, TC01, power supply, and accessories
MEA recording system for
upright microscopes,
60 electrode channels
MEA60-Up-2-
System
Complete with 5 MEAs, data acquisition
computer with MC_Card, 2 x MEA1060-Up
amplifier, MEAS2/1, TC02, power supply,
and accessories
MEA recording system for
inverted microscopes with
advanced
p
erfusion,
MEA60-Inv-
System-E
Complete with 5 MEAs, data acquisition
computer with MC_Card, MEA1060-Inv
am
p
lifier, TC02, PH01,
p
ower su
pp
l
y
,
