7 Appendix
7.1 Technical Specifications
7.1.1 MEA1060-Inv
Operating temperature 10 °C to 50 °C
Storage temperature 0 °C to 50 °C
Dimensions (W x D x H) 165 mm x 165 mm x 20 mm (29 mm with sockets)
Weight 800 g
Supply voltage (external power
supply)
± 6 VDC to ± 9 VDC
Supply current max. 220 mA, typically ± 150 mA
Number of stimulus input channels 60
Maximum recommended stimulus
input voltage
± 5 V
Number of analog input channels 60
Input voltage -4 mV to 4 mV (with respect to the standard gain of 1200)
Input impedance
10
11
parallel to 10 pF
Input noise < 800 nV
RMS
Noise density e
n
= 15 nV / Wurzel aus Hz
Number of analog output channels 60
Output voltage ± 5 V
Output current 10 mA
Output impedance
300
Bandwidth 1 Hz to 3000 Hz (standard), 1 Hz to 5000 Hz (custom)
Gain 1200 (standard), 500 to 5000 (custom)
Microscope compatibility Inverse microscopes
Distance focal plane to microscope table 3.5 mm
