Frequency Stability
±0.01%
Receiver Sensitivity -43 dBm under worst-case conditions
AGC Dynamic Range 43 dB
Interface TIA/EIA RS-232C/ITU-T V.24/V.28
Connectors DB25F RS-232C connector; two RJ-11 phone jacks (BA
model) or three RJ-11 phone jacks (BL model); power
connector
Cables Three modular telephone cords (USA); country-specific
cordage for International models; one 9-pin to 25-pin serial
cable for International models; external power transformer
Note: Any cables connected to the computer should be
shielded to reduce interference.
Diagnostics Power-on self test, local analog loop, local digital loop,
remote digital loop
Indicators 32-character backlit LCD for status and configuration
information; LEDs for Transmit Data, Receive Data,
Carrier Detect, Off Hook, Terminal Ready, and Test Mode
Speaker 1-inch speaker for call progress monitoring
Manual Controls Power switch, speaker volume control, four LCD control
buttons
Environmental Temperature range 0°–50°C (32°–120°F) ambient under
closed conditions; humidity range 20–90% (non-condensing)
Storage Temperature -10° to +85°C (14°–185°F)
Power Requirement 120 VAC, 60 Hz, 16 W; 230V/50 Hz optional (international)
Power Consumption 12 W @ 0.1 A typical
Dimensions 15.8 cm wide × 22.9 cm long × 3.6 cm high (6.2 " × 9.0 " × 1.4 " )
Weight 0.9 kg (2 lb.)
Limited Warranty 10 years
