Chapter 7 - Troubleshooting
45
Multi-Tech Systems, Inc. MT5600BA/BL Series User Guide
· The default DTR Control command (&D2) inhibits autoanswer. To enable autoanswer, change DTR
Control to &D0, and make sure &Q0, &Q1, &Q5, or &Q6 is also set. For more information, see the
&D command in the AT Command Reference Guide on the CD shipped with your modem. For
information on changing the modem’s default configuration, see “Step 3: Install and Configure Your
Software” in Chapter 2.
· Autoanswer might be disabled. Turn on autoanswer in your datacomm program or send the
command ATS0=1 (ATS0=2 if you have Caller ID service) to your modem in terminal mode.
· You might have an older UART. For best throughput, install a 16550AFN UART or a Multi-Tech ISI
serial port card.
· If you are running under Windows 3.1 and have a 16550AFN UART, you must replace the
Windows serial driver, COMM.DRV, to take full advantage of the UART’s speed.
· If you are using a slow transfer protocol, such as Xmodem, try Zmodem or Ymodem/G instead.
· Is your line noisy? If there is static on your line, the modem has to resend many blocks of data to
insure accuracy. You must have a clean line for maximum speed.
· Are you downloading a compressed file with MNP 5 hardware compression enabled? Since
hardware data compression cannot compress a file already compressed by an archiving program, the
transfer can be marginally slower with data compression enabled than with it disabled.
· Does your Internet service provider (ISP) use the same 56K protocol as your modem? The default
setting of your modem is to connect using either the 56K or the V.90 protocol, depending on which
one the ISP modem is using. If your ISP uses the X2 protocol, the maximum speed you will be able
to connect at is 33,600 bps. Check with your ISP to see which protocols it supports, and check the
Multi-Tech Web site for the latest developments in V.92.
· Try entering the &V1 command to display information about the last connection, making a screen
print of the connection statistics, and checking for parameters that might be unacceptable.
· If you are using data compression and a high speed serial port, set the serial port baud rate to four
times the data rate.
· Your UART might not be reliable at serial port speeds over 9600 bps or 19,200 bps. Turn off data
compression, reset your serial port speed to a lower rate, or replace your serial port with a faster
one.
· Make sure the flow control method you selected in software matches the method selected in the
modem. If you are using the modem with a Macintosh, you might have the wrong cable for
hardware flow control.
