SWIFT 20 Sensors
156
SWIFT 20A Mechanical Parts
Assembly Drawings
SWIFT 20A Mechanical Parts
SWIFT 20A Mechanical Part Numbers
Part Number Part Description
700-000-620
Modified Rim Reference Drawing
700-000-621
Modified Rim Assembly Reference Drawing
700-000-684
Hub Adapter Reference Drawing
700-000-794
Reference Dimension Drawing
700-000-835
Bolt Torque Sequence Drawing
