Contents MTS Series 793 Controller Overview
Technical Support How to Get Technical Support Start with your manuals The manuals supplied by MTS provide most of the information you need to use and maintain your equipment. If your equipment includes software, look for online help and README files that contain additional product information. If you cannot find answers to your technical questions from these sources, you can use the internet, e-mail, telephone, or fax to contact MTS for assistance.
Before You Contact MTS MTS can help you more efficiently if you have the following information available when you contact us for support. Know your site number and system number The site number contains your company number and identifies your equipment type (such as material testing or simulation). The number is typically written on a label on your equipment before the system leaves MTS. If you do not know your MTS site number, contact your sales engineer.
Know relevant computer information Know relevant software information For a computer problem, have the following information available: • Manufacturer’s name and model number • Operating software type and service patch information • Amount of system memory • Amount of free space on the hard drive where the application resides • Current status of hard-drive fragmentation • Connection status to a corporate network For software application problems, have the following information available: • Th
Identify system type Be prepared to troubleshoot Write down relevant information After you call To enable the Call Center agent to connect you with the most qualified technical support specialist available, identify your system as one of the following types: • Electromechanical material test system • Hydromechanical material test system • Vehicle test system • Vehicle component test system • Aero test system Prepare to perform troubleshooting while on the phone: • Call from a telephone close
Access the Problem Submittal Form: • In the back of many MTS manuals (postage paid form to be mailed to MTS) • www.mts.
Technical Support MTS Series 793 Controller Overview
Preface Before You Begin Safety first! Other MTS manuals Before you use your MTS product or system, read and understand the Safety manual and any other safety information provided with your system. Improper installation, operation, or maintenance can result in hazardous conditions that can cause severe personal injury or death, or damage to your equipment and specimen. Again, read and understand the safety information provided with your system before you continue.
Conventions Conventions Documentation Conventions The following paragraphs describe some of the conventions that are used in your MTS manuals. Hazard conventions Hazard notices may be embedded in this manual. These notices contain safety information that is specific to the activity to be performed. Hazard notices immediately precede the step or procedure that may lead to an associated hazard. Read all hazard notices carefully and follow all directions and recommendations.
Conventions Illustrations Electronic manual conventions Hypertext links Illustrations appear in this manual to clarify text. They are examples only and do not necessarily represent your actual system configuration, test application, or software. This manual is available as an electronic document in the Portable Document File (PDF) format. It can be viewed on any computer that has Adobe Acrobat Reader installed. The electronic document has many hypertext links displayed in a blue font.
Conventions 16 Preface MTS Series 793 Controller Overview
Learn About Your Controller Here Chapter 1 Introduction Learn About Your Controller Here MTS Series 793 Controllers are supplied with several manuals—each pertaining to a primary attribute of the Controller, such as hardware, control software, application software, utility software, and more. This manual integrates descriptions of all of these attributes to help you learn about your Controller as efficiently as possible. It is a not a “how-to” manual, it is a learning manual.
New Features in Version 5.
Controller Overview Chapter 2 Controller Hardware Controller Overview MTS controllers equipped with Series 793 Software are referred to as MTS Series 793 Controllers. Types of MTS Series 793 Controllers MTS offers several types of Series 793 Controllers.
About MTS FlexTest Models 40/60/100/200 Types of MTS Series 793 Controllers MTS offers several types of Series 793 Controllers.
About MTS FlexTest Models 40/60/100/200 FlexTest 40 FlexTest 60 Back (3 VME slots) FlexTest 100 Front (6 VME slots) Front (10 VME slots) Back (8 transition slots, 7 powered) Back (12 transition slots, 10 powered) FlexTest 200 Front (20 VME slots) Back (20 transition slots, 19 powered) FlexTest Models 40/60/100/200 Controllers MTS Series 793 Controller Overview Controller Hardware 21
FlexTest GT Controller Description FlexTest GT Controller Description FlexTest GT Controllers are PC-based multi-station digital controllers consisting of: • A PC running Series793 Software • A FlexTest GT Controller chassis equipped with Series 493 electronics • An optional Handset These components work together to control up to eight channels on up to four independent stations.
FlexTest GT Controller Description Typical FlexTest GT configuration About DUCs The controller chassis is typically equipped with the following Series 493 Plug-In Modules (32 maximum): • One valve driver module per control channel (two-stage or three-stage) • Two digital universal conditioners (DUCs) per control channel • Hydraulic service manifold (HSM) and hydraulic power unit (HPU) interlock modules The Model 494.25 Digital Universal Conditioners (DUCs) condition AC and DC transducers.
FlexTest GT Controller Description Hardware options • Additional Model 494.25 DUCs • Model 494.26 Dual DUC • Model 494.
FlexTest SE Controller Description FlexTest SE Controller Description The FlexTest SE Controller is a fully-digital PIDF controller that is available in three configurations: FlexTest SE Basic • FlexTest SE Basic • FlexTest SE Plus • FlexTest SE 2-Channel The FlexTest SE Basic is a stand-alone controller equipped with a multicolor display panel and direct-access menu keys. It does not require a PC to operate; a special form of MTS Series 793 Software is stored directly on its internal flash memory.
FlexTest SE Controller Description Automated FlexTest SE Controllers The FlexTest SE is available in two automated configurations, the FlexTest SE Plus and the FlexTest SE 2-Channel. The FlexTest SE Plus and FlexTest SE 2-Channel Controllers include: • A PC with Series 793 Software • FlexTest SE Controller equipped with Series 493 Electronics FlexTest SE Plus The FlexTest SE Plus provides one control channel, as shown in this axial load unit example.
FlexTest SE Controller Description Using Plus and 2Channel Controllers in the Basic mode Supplemental interface for specimen handling If desired, the FlexTest SE Plus and FlexTest SE 2-Channel Controllers can also be used without PCs (in the FlexTest Basic configuration). The Controller is fully capable of system control without the PC.
FlexTest SE Controller Description Booting the controller in the automated mode disables several of the menus on the front panel of the controller. These menus are used for testing in nonautomated FlexTest SE Basic models. To compensate for the disabled front-panel menus, you use the Station Manager application interface on the PC to set up and run tests. The PC manages testing. You use a PC loaded with Series 793 Software to design and run tests.
FlexTest SE Controller Description Typical FlexTest SE Plus configuration Options FlexTest SE Plus Controllers typically support one channel on one station, and include the following: • VME processor capable of an update rate of 6kHz, along with a two-stage or three-stage valve driver, and two digital universal conditioners • One analog input and three analog outputs • Digital inputs and outputs (for interlocks or user-defined purposes) • Serial interface for temperature control • Up to three ad
FlexTest IIm Controller Description FlexTest IIm Controller Description FlexTest IIm Controllers are PC-based multistation digital controllers consisting of two major hardware components: • A PC running Series 793 Software • A FlexTest IIm Controller chassis, equipped with Series 497 Electronics FlexTest IIm Controllers support up to sixteen control channels on up to four independent stations.
FlexTest IIm Controller Description FlexTest IIm Console Each FlexTest IIm console houses the following rack-mount components: • 497.01 Analog Chassis equipped with a complement of Series 497 valve drivers and conditioners, supporting up to 16 channels of control • 497.05 Hydraulic Control Panel, which controls at least one Hydraulic Power Unit (HPU) or actuator manifold • 498.
Controller Hardware Options Controller Hardware Options Remote Setpoint Adjust (RSA) Model 494.05 Handset The Remote Setpoint Adjust control allows you to use one or more encoders on a station to control the setpoints of control channels (available for FlexTest IIm and FlexTest GT Controllers only).
Controller Hardware Options Programmable Display. Shows sensor output and the current control mode. You can use it to zero sensors and change control modes. *MC SN1 Ch1 >Displ 130.5 -Force 200 kN Exclusive Control Interlock Indicators Thumbwheel. Manually positions the actuator when Manual Command is enabled Hydraulics Indicator Manual Command Interlock Reset/Override Program Run/Stop/ Hold Controls Hydraulics Off Model 494.
About TEDS Sensors About TEDS Sensors Note Only controllers that use Series 494 Hardware support the use of MTS TEDS (transducer electronic data sheet) sensors. TEDS sensors have built-in memory chips that store basic TEDS information (manufacturer, model, number, and serial number). When you connect an initialized TEDS device to a conditioner, the Station Manager application reads the basic TEDS information from the device, and a sensor assignment window appears.
Model 793.00 System Software Bundle Chapter 3 Controller Software This section contains descriptions of the software included with MTS 793 Controllers. Regardless of the differences in hardware between one controller and another, all MTS 793 Controllers are equipped with MTS 793 Software. Multitasking Windows environment MTS 793 Software runs on the Windows operating system, which is multitasking. This means you can run more than one 793 application at a time.
Model 793.00 System Software Bundle Station Builder Station Manager A station design application that allows you to allocate controller resources, such as valve drivers, conditioners, digital inputs, and so forth, to station configuration files. You define parameters for the resources in the station configuration with the Station Manager application. This application is password protected.
Software Options Available with Key Codes For more information For more information about using Station Manager to assign parameters to station configurations, see “About Assigning Parameters to Station Configurations” on page 54. For more information about using Basic TestWare to create test designs, see “Designing Tests with the Basic TestWare Application” on page 65. For more information about using Station Manager to execute tests, see “About Running Tests” on page 76.
Software Options Available with Key Codes Model 793.04 PC-PerStation Kit The PC-Per-Station Kit allows you to use up to four PCs with your FlexTest IIm, or FlexTest GT Controller. Multiple PCs linked to a single controller allows different operators to run their assigned stations without having to share PCs. It also decreases downtime since multiple operators can run different tests simultaneously (at their assigned stations) through a single controller.
Software Options Available with Key Codes Each type of compensator uses a different technique to achieve the commanded levels. Certain compensators work more effectively than others for specific applications. The following compensators are available as Series 793 Software options: Model 793.10 MultiPurpose TestWare (MPT) • Model 793.05 Amplitude Phase Control (APC) Compensator • Model 793.06 Adaptive Inverse Control (AIC) Compensator • Model 793.
Software Options Available with Key Codes Model 793.14 Fatigue Monitoring A specialized analysis application that allows you to monitor fatigue data that has been recorded in real time. This application works with the MultiPurpose TestWare application, using the Fatigue process. Model 793.15 Degree of Freedom Control (DOF) DOF control (available with Series 793 Software version 4.
Software Options Available with Key Codes Model 793.25 CAN Bus Support Model 793.26 Signal Based Command Model 793.71 Time History Playout (THP) The Model 793.25 CAN Bus feature supports CAN bus devices. CAN bus is a computer network protocol and bus standard that allows devices to communicate with each other without a host computer. You can use CAN Bus resources in control loops and event-action sequences. The Model 793.
Software Options Available on Separate Media Software Options Available on Separate Media MTS has additional application software designed for use with Series 793 Controllers, and is continually developing more. These applications are not available as keyed options on the standard Series 793 System Software installation CD; they are distributed on separate media. The following descriptions are just a few examples of optional Series 793 applications (contact MTS for a complete list). Model 793.
Operational Overview Chapter 4 Operation Concepts This section provides conceptual information about using 793 Software components to perform specific test activities. Operational Overview The following pages provide a high-level overview of the steps required to set up, design, and run a test.
Operational Overview Assigning Parameters to the Station Configuration PARM PARM PARM Parameter Parameter Parameter Station Station set 2 set 1 set 3 Config Manager file application Next, you load a station by selecting a Station Configuration file with the Station Manager application. You assign parameters of the resources in Station Configuration file to optimize performance according to your test requirements.
Operational Overview For more information For more information on creating a station configuration, see “About Station Configurations” on page 51. For more information on assigning parameters to the station configuration, see “About Assigning Parameters to Station Configurations” on page 54. For more information on creating a test design, see “About Test Designs” on page 64. For more information on running a test, see “About Running Tests” on page 76.
About Projects About Projects Understanding Projects A Series 793 Project folder (or Project for simplicity) contains the various types of information you typically acquire while testing. Project 1 Project folders contain various files centered around test design and test execution. Projects also contain settings that include references to common support file stored elsewhere (as shown to the right). Project folders are displayed with a double-red line notation.
Understanding Projects Projects include information: Benefits of Projects Your initial Project • Required to perform tests, such as configuration files and test design files; and • Generated by testing, such as test data, scope images, and specimen files. • Captured as a result of unexpected shutdowns (Shutdown Recorder directory) The Project Manager (and the ability to create Projects) became available in version 4.0 of Series 793 System Software.
Using Project Manager to Modify Projects Using Project Manager to Modify Projects Every Project contains a Project Settings file. Most Project settings are folder path specifications. To configure Projects, you use the Project Manager application to edit the Project Settings file. A Project Settings file acts like a switchboard that directs the flow of information within a Project.
About Hardware Interface Files About Hardware Interface Files Understanding Hardware Interface Files The resources in your Station Builder application resource lists are defined by the hardware interface file (or .hwi file) installed with your system software. Resource examples include conditioners, valve drivers, digital inputs, and so forth. The .
Understanding Hardware Interface Files Editing .hwi files with the Hwi File Editor MTS has a software utility for editing .hwi files, called the Hwi File Editor. This utility minimizes the chance of introducing syntax errors when making changes to existing .hwi files or creating new .hwi files. The built-in logic of the Hwi File Editor streamlines the process of adding new resources. For instance, when you add or remove analog resources from an .hwi file, the .
About Station Configurations About Station Configurations About the Station Builder Application The Station Builder application defines the parts of a station configuration from a pool of system resources listed in the hardware interface file. With the Station Builder application, you can allocate all or a portion of your system resources to create station configuration files.
Using the Station Builder Application to Create Using the Station Builder Application to Create Station Configurations When you create station configurations with the Station Builder application, you are not required to apply power to your station or handle station hardware--you are simply creating files.
Station Builder Application Window Station Builder Application Window The Station Builder application has one main window that enables you to create station configurations.
About Assigning Parameters to Station About Assigning Parameters to Station Configurations About Parameter Sets In the pretest phase, you use the Station Manager application to optimize how the parts of your system work together. A product of the pretest phase is a parameter set that you save with the station configuration. A parameter set adapts the way the resources in your station configuration operate to suit your test requirements. Parameters include everything from tuning values to detector settings.
Using the Station Manager Application to Create Using the Station Manager Application to Create Parameter Sets When you optimize your station configuration with the Station Manager application, you perform many of the activities required to perform a test: You apply power to the station, manually position the actuator, apply tuning programs, monitor waveforms, and so forth. While doing these activities you adjust parameter values accordingly, which you save with your station configuration.
Using the Station Manager Application to Create To complete this task, make sure the force tuning values established in your parameter set are suitable for the test you are about to run.
Using the Station Manager Application to Create Where parameter sets are stored A station parameter set is not a discrete file that you can see on your desktop. It is a discrete attribute set that is saved within a station configuration by the Station Manager application. By default, configuration files are located at C:\MTS 793\Controllers\Controller Name (for example, FlexTest GT)\Config. Configuration files are referenced from the Project you selected when you started the Station Builder application.
Station Manager Application Windows Station Manager Application Windows With the Station Manager application, you can perform the following to optimize your station configuration prior to running tests.
About Compensators Station Setup window About Compensators Compensators are control techniques that improve the tracking and accuracy of your controller. They play an important role in optimizing system performance. Various compensators are available to suit specific test requirements. Null Pacing Null pacing ensures that desired levels are achieved on the initial command pass without over programming the input.
About Compensators Amplitude and Phase Control (APC) The Amplitude and Phase Control (APC) compensator monitors feedback from sine and sine tapered commands for amplitude roll-off and phase lag. APC works well when you need to control the amplitude of the fundamental frequency component.
About Compensators AIC is typically used in tests on linear specimens in which road profiles developed on a separate system must be accurately reproduced without having to iterate. AIC is also used on fast sine sweeps, particularly when the sweep rate is too fast (>1Hz/s) for APC, and on any component being tested with random or time history signals on a linear system.
About Compensators ALC is typically used in matrix depletion fatigue tests where only one or two cycles of a particular amplitude are executed before new amplitudes are introduced. Example of feedback dropping off in a test waveform without ALC compensation. The same waveform with ALC compensation Adaptive Harmonic Cencellation (AHC) Adaptive Harmonic Cancellation (AHC) works with Amplitude Phase Control (APC) to minimize spurious harmonic distortion.
About Compensators Adaptive Harmonic Cancellation is typically used when programming with pure sinewave commands or sine sweeps in acceleration control. Also, ALC is typically used in high-frequency MAST systems for ground vehicle testing. How AHC Works Because cancellation occurs at the system output by means of a signal at the system input, the phase response of the system must be known.
About Test Designs About Test Designs Understanding Test Design Files MTS Series 793 Software offers several applications you can use to create test design files. When you save test design files, they are automatically stored in the current Project. Note The Basic TestWare application is the only test design application that comes standard with Series 793 Software.
Designing Tests with the Basic TestWare Application Designing Tests with the Basic TestWare Application The Basic TestWare application is included in the Series 793 System Software bundle, and is the easiest software tool for creating simple monotonic and cyclic test designs that do not require complex signal management or mode switches. An on-screen panel lets you create tests by defining the rate, frequency, amplitude, and mean for sine, triangle, square, and ramp command signals.
Designing Tests with MultiPurpose TestWare Designing Tests with MultiPurpose TestWare MultiPurpose TestWare (MPT) is a powerful and flexible application that enables you to quickly and easily define complex test designs. MPT allows you to create complex test designs with discrete processes. Each process represents an individual test activity. This diagram shows how a test waveform may correlate to individual process icons.
Designing Tests with MultiPurpose TestWare Types of information in MPT test procedures Working with Processes An MPT test procedure contains two types of information: • Process information, which defines your processes (command, data acquisition, signal monitoring, and so forth) and the sequence in which each process executes • MPT application information, which includes test unit and dimension assignments, the behavior of hold and resume functions, the data file format, and so on You begin designing
Designing Tests with MultiPurpose TestWare For example, suppose you create a test procedure that includes several command processes that all use the same frequency. Rather than entering a frequency value for each process separately, you could associate all the frequency parameters with a “Frequency” variable.
MPT Process Types MPT Process Types Command Processes ICON PROCESS NAME DESCRIPTION Segment Command Produces a monotonic command signal. Cyclic Command Produces a cyclic command signal. Dwell Command Produces a dwell (or hold) command signal. Profile Produces a command signal based on the contents of a “profile” created with a text editor or the Profile Editor application. External Command Enables a command signal from an external program source.
MPT Process Types Data Acquisition Processes ICON 70 PROCESS NAME DESCRIPTION Peak/Valley Acquisition Records the peak/valley data for each cycle execution. Timed Acquisition Records data at user-specified time intervals. Max/Min Acquisition Records data at the highest peak and lowest valley during the life of the process. Level Crossing Acquisition Records data each time the selected signal changes by a specified amount. High Speed Timed Acquisition Records bursts of data at a high rate.
MPT Process Types Event Processes ICON PROCESS NAME DESCRIPTION Data Limit Detector Monitors one or more signals for sensor limits you specify. Digital Input Detector Detects digital transition states from external devices. Operator Event Enables operator interaction during the test. (For example, Operator events can display buttons the operator must click to continue the test.). Peak/Valley Change Detector Detects changes in the peak and valley amplitudes of cyclic waveforms.
MPT Process Types Other Processes ICON 72 PROCESS NAME DESCRIPTION Program Control Performs user-defined program actions such as Program Hold, Program Resume, Interlock, and user defined actions. Group Defines a process sub-group that can contain one or more other processes. MPT Calculation Adds mathematical functions to variable parameters. Operator Information Enables operator data entry (to be written to a data file) during the test.
MultiPurpose TestWare Windows MultiPurpose TestWare Windows MPT control panel The MPT control panel appears in the application area of the Station Manager application, as shown. MPT main window is nested within the Station Manager application main window. When you select the MPT application from the Station Manager application, the run, stop, and hold controls on the Station Controls panel pertain to running MPT test procedures.
MultiPurpose TestWare Windows Procedure Editor The MPT Procedure Editor contains a table on which you build MPT test procedures by selecting, assigning parameters to, and sequencing individual test processes. Test processes represent individual test activities. Navigation pane Status and progress indicators A blue arrow pointing toward a process (not shown) indicates it is executing. This lets you watch the progress of a test.
MultiPurpose TestWare Windows Process Palette The Process Palette displays the types of processes you can drag to the Procedure Editor. Process Palette Individual processes are arranged on the palette by type. You can double-click a process on the Process Palette to copy an instance of it to the table on the Procedure Editor, or you can use the drag-and-drop method.
About Running Tests About Running Tests Understanding Files Used for Testing During the testing phase, the Station Manager application controls how the parts of the system work together to maintain precision servo control. Command is typically provided by an application such as Basic TestWare or MultiPurpose TestWare.
Test Desktop Test Desktop With the Station Manager application window controls, you can perform the following to run tests: • Load and reload stations • Configure limit and error detectors • Control hydraulic pressure to the test station • Manage the execution of the Basic TestWare and MultiPurpose TestWare applications • Monitor signals on the built-in scopes and meters Windows typically open while running a test.
Monitoring Test Information The Scope displays the waveforms of selected signals. Monitoring Test Information MTS Series 793 Software includes several features for monitoring test signals and test progress. MPT Counters 78 Run time counter The Run Time counter displays the elapsed time of the current test since the last time it was reset. Channel counters Channel Counters display a cumulative count of segments or cycles that have been applied to a specific channel since the start of the test.
Monitoring Test Information Sequence counters Sequence Counters display the progress of individual processes within the test. They can be especially useful for procedures that contain nested groups, because you can configure them to show test progress within the nested structure of the procedure. This sample procedure includes a group process labeled “Cooling Cycles,” which contains four nested processes (with indented label names, “Trigger at 75C,” and so forth.
Monitoring Test Information Meters display The Meters window can display up to 16 meters per station simultaneously. The following data can be displayed for any defined input signal: • Timed data • Peak/valley data • Mean/amplitude data • Maximum/minimum values Meters can be aligned on the desktop vertically, horizontally, or in a grid. Meter displays can be sized to your preference. Scope display The Scope window in the Station Manager application is an oscilloscope.
Monitoring Test Information When you place the cursor on the trace, it becomes a crosshairs. With the crosshairs, you can select individual data points on the trace and see their precise coordinates on the axes in the associated display box.
Monitoring Test Information 82 Operation Concepts MTS Series 793 Controller Overview
File Types and Locations Chapter 5 Installed 793 Files File Types and Locations When you install Series 793 Software on your PC (version 4.
About Controller Information Individual Projects in the Projects folder can access common information at this level. For instance, all Projects can access: • Calibration data that applies to test system conditioners and sensors in the Calibration Files folder. • Station configurations and supporting files in the Controllers folder. • The MultiPurpose TestWare test procedure template (default.000) in the MPT folder. • The Project template in the Project Templates folder.
About Project Information About Project Information Folders and files within specific Project folders, including the BTW, ImportExport, MPT, Profiles, and Scope Images folder, and the project settings file (project.793settings), can be thought of as “project” information. Project information is stored directly in individual Project folders. References to other types of information Individual Project folders also include references to other types of Series 793 information.
About Program Information About Program Information Folders and files within the Program Files folder include executables, the unit definition (.udf) files, user documentation (PDFs), and readme files. This information is replaced when you install a Series 793 Software upgrade.
About Setting Up a Practice Test Chapter 6 Perform a Practice Test About Setting Up a Practice Test This section includes step-by-step instructions for performing a practice test. The purpose of this procedure is simply to help you learn how to use your system. While performing this test you will: • Select a Project at the beginning of the test, and review test data stored in the Project at the end of the test. • Set limits and manually position the actuator to install the specimen.
About Setting Up a Practice Test If you are going to set up your controller If you are installing Series 793 Software on your system and setting up your controller yourself, you'll need to do the following before performing the practice test: • Install Series 793 Software • Set up a Project (typically performed during software installation) • Create a station configuration file • Calibrate the sensors • Perform servovalve adjustments • Tune the system To perform the Series 793 Software install
Steps to Run a Test Steps to Run a Test WARNING Improper controller setup can result in unexpected actuator movement. Unexpected actuator movement can injure personnel and damage test equipment. Ensure that your controller is set up properly before attempting to perform a test. 1. Power up the controller chassis and PC. 2. Start the Station Manager application and select a Project. A.
Steps to Run a Test C. D. Select the following settings in the Function Generator. CONTROL SETTING Channel Channel 1 Control Mode Force Command Type Cyclic Target Setpoint 0 kN Amplitude 10% of full scale Frequency 1 Hz Wave Shape Ramp Compensator None From the Station Manager application toolbar, select the Scope. WARNING A crush zone exists between the actuator and any equipment in the path of its movement.
Steps to Run a Test E. Install a dummy specimen that has a compliance similar to the test specimen. • From the Station Controls panel toolbar, click the Manual Command icon . • Click to select the Enable Manual Command check box. • Select the Displacement control mode. • Adjust the Manual Command slider to position the actuator while installing the specimen. • Switch to the Force control mode. F. Adjust the P Gain and D Gain tuning controls.
Steps to Run a Test The middle waveform is the optimum waveform. In some cases the waveform will have no overshoot or ringing. High Rate (D) Low Gain (P) High 5. Install the test specimen. A. Select the Displacement control mode for test specimen installation. B. Install the test specimen. • Turn on the Manual Command control on the Station Controls panel. • Adjust Manual Command to position the actuator as required. C. Switch to the force control mode. 6. Set test limits and actions.
Steps to Run a Test 7. Set up the test monitor. Set up the Meters and Scope as desired to monitor test signals. 8. Set up a test program. A. From the Application control bar, select Basic TestWare. B. In the Command tab, set the following: Note MTS Series 793 Controller Overview Ensure that the Target Setpoint and Amplitude values are appropriate for your particular specimen.
Steps to Run a Test C. D. E. 94 Perform a Practice Test In the Data Acquisition tab, set the following: CONTROL SETTING Type Timed Signals Included Channel 1 Output Time Between Points default Buffer Size 2048 Buffer Type Linear In the Data File tab, set the following: CONTROL SETTING Destination File Test Default Data Header Enter “First Test” Data File Mode Append Data File Format Plain Close the Test Setup window.
Steps to Run a Test 9. Start the test. A. Ensure that the following are true: • Interlocks are cleared • High hydraulic pressure is applied to the station • Load tuning parameters are optimized • The test specimen is installed • Limits are set and actions are assigned • The test program is set up • The scope and meters are set up to monitor the test as desired B. On the Station Controls panel, press the Program Run button to start the test.
Steps to Run a Test 96 Perform a Practice Test MTS Series 793 Controller Overview
Series 793 Controller Manuals Chapter 7 Documentation The following describes the manuals that may accompany a 793 Controller (applies to 793 Software version 5.1 and later). Series 793 Controller Manuals MTS Series 793 Control Software manual Contains user information and software reference for the applications in the Model 793.00 System Software bundle.
Series 793 Controller Manuals MTS Series 793 Utility Software manual Contains information about the MTS .hwi file Editor and MTS Controller Management Tool software utilities. The .hwi file Editor manual contains instructions for creating and editing hardware interface files, which define the hardware resources available for your test system. The Controller Management Tool manual contains instructions for servicing MTS FlexTest SE Controllers.
Other 793 Documents Other 793 Documents Readme Files All applications included in the Series 793 System Software bundle (and all optional applications) are supplied with a separate Readme file. Readme files contain late breaking application features, and known problems and workarounds.
Other MTS Documents Included with Your System Other MTS Documents Included with Your System System reference manual (optional) If you have purchased a test system, it may include a set of system reference manuals that pertain to the hardware components in your test system, such as fixturing, hydraulic power supplies, actuators, and so forth. System reference manuals are bound in grey three ring binders, and are organized with tabbed dividers.
