Environmental chambers that have U-plugs can be installed after the grips are installed. The following figure
shows the components used for most installations.
All-Temperature Grip Installation Components
DescriptionItemDescriptionItem
Hydraulic Release10Shim Washer1
Hydraulic Pressure11Connector Stud2
Upper Grip Assembly12Environmental Chamber3
Lower Grip Assembly13Water Supply4
Hydraulic Release14Shim Washer5
Hydraulic Pressure15Actuator Rod6
Connector Stud16Load Unit Base Plate7
Spiral Washer Set17Force Transducer8
