Axial Grip Installation Components
DescriptionItem
Crosshead or Force Transducer1
Spiral Washer Set2
Stud3
Shim Washer4
Shim Washer5
Actuator Rod6
Load Unit Base Plate7
Spiral Washer Set8
Stud9
Required equipment
The following materials and equipment are required for installation:
• The appropriate attachment kit.
• Two sets of spiral washers.
• Two connector studs.
• Shim washers.
• Lubricant.
40 Series 647 Hydraulic Wedge Grips Reference Manual
