MTS Criterion® Series 40 Manual Title Lifting and Moving AdditionalInstructions Information be certain.
Copyright information © 2011, 2012, 2014 MTS Systems Corporation. All rights reserved. Trademark information MTS and MTS Criterion are registered trademarks of MTS Systems Corporation within the United States. These trademarks may be protected in other countries. Proprietary information Software use and license is governed by MTS’ End User License Agreement which defines all rights retained by MTS and granted to the End User.
Lifting and Moving Instructions This manual provides guidelines for lifting and moving your MTS Criterion material testing system. Unless otherwise specified, it is your responsibility to safely off-load, unpack, and move the equipment to the final location on your premises. Equipment insurance is also your responsibility. Before moving the equipment from the receiving area to its final location, check the dimensions of all doors and passages through which the machine will travel.
Responsibilities Responsibilities This section details the responsibilities of both the customer and MTS to ensure that the proposed testing area is suitable for the installation and operation of the testing system. Customer’s Responsibilities It is the customer’s responsibility to ensure that all required support services are available, and that all necessary checks are made prior to installing the testing system. These services and checks are described below.
Responsibilities MTS’ Responsibilities MTS’ standard contract requires MTS to provide the necessary services to ensure that your testing system operates accurately. These services are described below. Additional services and equipment may be negotiated with MTS, but these additional services must be mutually agreed upon and specifically described in your purchase order.
Packaging Dimensions and Weights Packaging Dimensions and Weights The following table provides the dimensions of various load frame models when packaged for shipping. If you transfer the load frame from the shipping dock to its final site location before unpacking the system, then use these dimensions to ensure that the frame fits through all doorways and hallways. Packaging Dimensions for Load Frames MODEL WIDTH DEPTH HEIGHT WEIGHT C41.103 820 mm (32.28 in) 1100 mm (43.31 in) 1760 mm (69.
Load Frame Dimensions and Weights Load Frame Dimensions and Weights The following table provides the dimensions of various load frame models. If you transfer the load frame to its final site location after unpacking the system, then use these dimensions to ensure that the frame fits through all doorways and hallways. Load Frame Dimensions MODEL WIDTH DEPTH HEIGHT WEIGHT C41.103 560 mm (22.05 in) 530 mm (20.87 in) 1520 mm (59.84 in) 60 kg (176 lb) C42.503 704 mm (27.72 in) 636 mm (25.
Moving C41 Single-Column Frames Moving C41 Single-Column Frames The single-column load frames are shipped with wooden packaging. They are strapped to the wooden skid. Accompanying components are packed in cardboard cartons and also strapped to the wooden skid. Ensure that the test system is placed on a stable or other suitable work platform that can support the test system weight.
Moving C41 Single-Column Frames Procedure To unpack and position the load frame: 1. Move the load frame, still in the shipping material, to its final location within your building. Use a forklift to transport the container from the shipping dock to the final location. Unpack the load frame after it has been moved to its final location. 2. Remove the shipping material, leaving the load frame fastened to the shipping skid. 3. Remove the shrink wrap vapor barrier encasing the load frame. 4.
Moving C42 Single-Column Frames Moving C42 Single-Column Frames The single-column load frames are shipped with wooden packaging. They are strapped to the wooden skid. Accompanying components are packed in cardboard cartons and also strapped to the wooden skid. Ensure that the test system is placed on a stable or other suitable work platform that can support the test system weight.
Moving C42 Single-Column Frames Procedure To unpack and position the load frame: 1. Move the load frame, still in the shipping material, to its final location within your building. Use a forklift to transport the container from the shipping dock to the final location. Unpack the load frame after it has been moved to its final location. 2. Remove the shipping material, leaving the load frame fastened to the shipping skid. 3. Remove the shrink wrap vapor barrier encasing the load frame. 4.
Moving C43 (10 kN) Double-Column Frames Moving C43 (10 kN) Double-Column Frames C43 (10 kN) double-column MTS Criterion load frames should only be moved using a forklift (or crane) with a load rating that is double the load frame’s gross weight. For frame weights, see “Load Frame Dimensions and Weights” on page 7. Ensure that the test system is placed on a table or other suitable work platform that can support the test system weight.
Moving C43 (10 kN) Double-Column Frames Equipment Procedure The following items are required by the customer: • A forklift with a load rating that is double the load frame’s gross weight (for frame weights, see “Load Frame Dimensions and Weights” on page 7) • Sharp knife • Screw removal tool • Protective padding for the crosshead • Two M16 hoist rings if using a crane To unpack and position the C43.104 load frame: 1.
Moving C43 (30 kN, 50 kN) and C44 Frames Moving C43 (30 kN, 50 kN) and C44 Frames C43 (30 kN, 50 kN) and C44 double-column MTS Criterion load frames should only be moved using a forklift (or crane) with a load rating that is double the load frame’s gross weight. For frame weights, see “Load Frame Dimensions and Weights” on page 7. WARNING The MTS Criterion frames are heavy.
Moving C43 (30 kN, 50 kN) and C44 Frames To right a package from a prone position: 1. Using a forklift, approach the frame from the light end of the package. 2. Insert the forks under the shipping skid. 3. Lift the whole assembly to about a 35° angle relative to the floor. 4. Wind the safety line or safety belt between the package and forklift carriage to prevent the package from overturning suddenly. 5.
Moving C43 (30 kN, 50 kN) and C44 Frames 7. Before placing the frame in its operating location, you must insert the leveling feet into each corner of the base. The shipping skid must be removed to insert the feet and before placing the frame in its operating location. Remove the shipping skid, insert the leveling feet, and position the frame. Follow the instructions described under “Crosshead method” on page 16. When the frame is in its operating location, you can proceed with the installation process.
Moving C43 (30 kN, 50 kN) and C44 Frames To transport the load frame using the crosshead method: 1. Ensure that there are no shipping bolts attached to the skid. 2. Using a forklift with padded forks or protective material around the crosshead, carefully insert the forks under the crosshead between the columns. WARNING The frame may overturn suddenly when lifting the frame. An overturned frame can cause injury or death to anyone in the immediate area.
Moving C43 (30 kN, 50 kN) and C44 Frames Crane method MTS recommends using professional riggers experienced in moving heavy equipment. To transport the load frame using the crane method: 1. Attach the two lifting slings to hoist rings of the top plate and secure them to the crane hook. WARNING The frame may overturn suddenly when lifting the frame. An overturned frame can cause injury or death to anyone in the immediate area.
Moving C43 (30 kN, 50 kN) and C44 Frames Do not exceed 30° Crane Hook Lifting Sling Hoist Ring Load Frame Lifting Load Frame with a Crane MTS Criterion® Series 40 Lifting and Moving Instructions 19
Moving C45 Frames Moving C45 Frames The C45 frame has been shipped in a horizontal position, so it must be moved into an upright, standing position before placing it in its operating location. The package cannot be uprighted directly. You need to unpack the package, and then move the frame into an upright, standing position . WARNING The MTS Criterion frames are heavy. Moving the frame using improper procedures can injure personnel (for example, strained muscles and back injuries) or damage the frame.
Moving C45 Frames Procedure To lift the load frame into a vertical position: 1. Remove all packaging material from the frame and ensure that the frame is not attached to the shipping skid. 2. Attach the two lifting slings to the hoist rings of the top plate and secure them to the crane hook. WARNING The frame may overturn suddenly when lifting the frame. An overturned frame can cause injury or death to anyone in the immediate area.
