Lubricant table
* Follow the notes in the engine manual as well.
14
Checking the oil level of the front
axle and wheel transmission
(both sides)
•
15
Lubricating the steering servo
cylinder (both sides)
••
16
Changing the oil – front axle and
transmission (both sides)
1
)
•
17
Lubricating the 3 point hub drive
shaft
••
18 Changing the engine coolant
1
)•
19
Inspecting all pipes and pipe
connections
••
20 Inspecting the state of the fan belts •
21 Replacing fan belts
1
)•
22
Emptying condensation from the
fuel filter
••
23 Exchanging the fuel filter
1
)•
1
) Carry out this servicing at a garage.
2
) Shorter intervals if used in dusty conditions.
 Only necessary after having been put into service for the first time. Thereafter, observe service intervals
according to the table.
Have your appliance with attachments checked and serviced once every season at a specialised workshop.
Observe the servicing guidelines in the engine manual.
Ref.-No.
Work to be carried out
Service-intervals
before each use Every 10 hours Every 25 hours Every 50 hours Every 100 hours Every 200 hours Every 250 hours Every 300 hours Every 500 hours Every 1000 hours Before placing into storage
Application Lubricant
General information
Capacity API class
Ambient
temperature
Viscosity
Engine Engine oil * approx. 4.7 l
with oil filter
CF-4, CG-4
or
CH-4
–30....+30 °C 5W-30
–20....+40 °C
–20....+50 °C
10W-30
10W-40
–6....+50 °C 20W-50
Hydrostatic gear and
hydraulic system
Drive System
Fluid Plus
(hydraulic/gear
oil)
approx. 24.6 l
Front wheel drive axle Drive System
Fluid Plus
(hydraulic/gear
oil)
approx. 2.4 l
Grease nipple Grease If necessary 251H EP grease or universal lithium grease no. 2
Cooler and
adjustment container
Anti-freeze
agent *
approx. 5 l Use high-grade long-term anti-freeze agent!
(Ethylene glycol with substances protecting against corrosion
and rust)
Coolant mix ratio:
Water and/or distilled water 50% Anti-freeze agent 50%
