17
Specifications
Continued from previous page
LED Features
∙ 1x EZ LED Control switch
∙ 4x EZ Debug LED
Back Panel
Connectors
∙ 1 x PS/2 keyboard/ mouse combo port
∙ 2 x USB 2.0 Type-A ports
∙ 1x Display port
∙ 1x HDMI port
∙ 1 x USB 3.2 Gen 2x2 20Gbps Type-C port
∙ 4 x USB 3.2 Gen 2 10Gbps Type-A ports
∙ 1 x LAN (RJ45) port
∙ 2 x Wi-Fi Antenna connectors
∙ 5 x Audio jacks
∙ 1 x Optical S/PDIF Out connector
I/O Controller NUVOTON NCT6687 Controller Chip
Hardware Monitor
∙ CPU/System temperature detection
∙ CPU/System fan speed detection
∙ CPU/System fan speed control
Form Factor
∙ ATX Form Factor
∙ 12 in. x 9.6 in. (30.5 cm x 24.4 cm)
BIOS Features
∙ 1x 256 Mb flash
∙ UEFI AMI BIOS
∙ ACPI 6.2, SMBIOS 3.2
∙ Multi-language
Software
∙ Drivers
∙ DRAGON CENTER
∙ MSI APP Player (BlueStacks)
∙ Open Broadcaster Software (OBS)
∙ CPU-Z MSI GAMING
∙ Intel® Extreme Tuning Utility
∙ Google Chrome™, Google Toolbar, Google Drive
∙ Norton™ Internet Security Solution
Continued on next page
