Notebook User's Manual Preface 1
Content 1 Preface................................................................................................1-1 Regulations and Statements.........................................................................................1-4 FCC-B Radio Frequency Interference Statement...................................................1-4 FCC Conditions..........................................................................................................1-4 CE Conformity.......................................
How to Use the Keyboard..............................................................................................3-8 Windows Key..............................................................................................................3-8 Switch Display............................................................................................................3-8 Disable or Enable Touchpad ....................................................................................3-8 Enter Sleep Mode.........
Regulations and Statements FCC-B Radio Frequency Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
Battery Regulations 廢電池請回收 Taiwan: For better environmental protection, waste batteries should be collected separately for recycling or special disposal. California, USA: The button cell battery may contain perchlorate material and requires special handling when recycled or disposed of in California. For further information please visit: http://www.dtsc.ca.gov/hazardouswaste/ perchlorate/ Safety Guideline for Using Lithium Battery Danger of explosion if battery is incorrectly replaced.
Japan JIS C 0950 Material Declaration A Japanese regulatory requirement, defined by specification JIS C 0950, mandates that manufacturers provide material declarations for certain categories of electronic products offered for sale after July 1, 2006. http://www.msi.com/html/popup/csr/cemm_jp.html http://tw.msi.com/html/popup/csr_tw/cemm_jp.
Safety Instructions Read the safety instructions carefully and thoroughly. All cautions and warnings on the equipment or user’s manual should be noted. Lay this equipment on a stable surface before setting it up. The openings on the enclosure are used for air convection and to prevent the equipment from overheating. Do not cover the openings. • Do not leave the equipment in an unconditioned environment with a storage temperature above 60ºC (140ºF) or below 0ºC (32ºF), which may damage the equipment.
• To prevent explosion caused by improper battery replacement, use the same or equivalent type of battery recommended by the manufacturer only. • Always keep the battery in a safe place. When installing the coaxial cable to the TV Tuner, it is necessary to ensure that the metal shield is reliable connected to protective earthing system of the building. Never pour liquid into the opening that could damage the equipment or cause an electrical shock.
MSI Highlights Explore more about MSI highlights at http://www.msi.com and https://www.youtube.com/user/MSIGamingGlobal MSI collaborates with SteelSeries to develop an exclusive SteelSeries Engine in gaming notebooks. SteelSeries Engine is the Apps to combine all frequent functions for gamers in multiple devices management.
Optical Disc Drive Notice CAUTION: This appliance contains a laser system and is classified as a “CLASS 1 LASER PRODUCT.” To use this model properly, read the instruction manual carefully and keep this manual for your future reference. In case of any trouble with this model, please contact your nearest “AUTHORIZED service station.” To prevent direct exposure to the laser beam, do not try to disassemble the enclosure. Trademarks ▶▶ All trademarks are the properties of their respective owners.
Notebook User's Manual Introductions 2
Congratulations on becoming an user of this notebook, the finely designed notebook. You will have a delightful and professional experience in using this exquisite notebook. We are proud to tell users that this notebook is thoroughly tested and certified by our reputation for unsurpassed dependability and customer satisfaction. Manual Map This User’s Manual provides instructions and illustrations on how to operate this notebook. It is recommended to read this manual carefully before using this notebook.
Product Overview This section provides the description of basic aspects of the notebook. It will help you to know more about the appearance of this notebook before using it. Please be aware that the figures shown here are for reference only. The figure of top-open view and description shown below will lead you to browse the main operating area of your notebook.
1. Webcam/ Webcam LED/ Internal Microphone • This built-in webcam can be used for picture taking, video recording or conferencing, and any other interactive applications. • Webcam LED indicator, next to the webcam, glows when webcam function is activated; LED goes out when this function is turned off. • The built-in microphone and its function is the same with microphone. 2. Quick Launch Buttons Use the quick launch buttons to activate the specific applications or tools.
3. Touchpad This is the pointing device of the notebook. 4. Keyboard The built-in keyboard provides all the functions of a full-sized keyboard. Use the [Fn] keys on the keyboard to activate the specific applications or tools. With the help of these keys, users will be able to do work more efficiently. The following keys will only be functional in the operating system with the SCM application installed.
+ Shift + Airplane mode • Press and hold the Fn key, and then press the F7 key to switch among Sport / Comfort / Green modes and shift the performance. • This function will only be activated when AC Power is plugged-in, and the default setting is Sport mode. • Press and hold the Fn key, and then press the F10 key repeatedly to turn Airplane mode on or off recurrently. • For flight safety consideration, it is always recommended to turn Airplane mode on when you are in flight.
Front Side View Introductions 1. Stereo Speakers Give high quality sound blaster with stereo system and Hi-Fi function supported. 2. Status LED Wireless LAN (WiFi) WLAN(WiFi) • LED glows when Wireless LAN (WiFi) function is enabled. • LED goes out when this function is disabled. Battery Status • LED glows when the battery is being charged. • Continuously blinking if the battery fails and it is recommended to replace a new battery.
Right Side View 1. Optical Disc Drive This notebook is equipped with an optical disc drive. The actual device preinstalled in the notebook depends on the model you purchased. 2. Card Reader The built-in card reader may support SD3.0 (Secure Digital) card. Contact the local dealer for further and correct information and be noted that the supported memory cards may vary without notice. 3. USB 2.0 Port The USB 2.
Left Side View Introductions 1. Kensington Lock This notebook provides a Kensington lock hole, which allows users to secure the notebook in place with a key or some mechanical PIN device and attached through a rubberized metal cable. The end of the cable has a small loop which allows the whole cable to be looped around a permanent object, such as a heavy table or other similar equipment, thus securing the notebook in place. 2. USB 3.0 Port/ Super Charger USB Port USB 3.
5. RJ-45 Connector The 10/100/1000 Ethernet connector is used to connect a LAN cable for network connection. 6. HDMI Connector HDMI (High Definition Multimedia Interface) is a new interface standard for PCs, displays and consumer electronics devices that supports standard, enhanced and high-definition video, plus multi-channel digital audio on a single cable. 7. USB 3.0 Ports USB 3.
Rear Side View Introductions 1. Ventilator The ventilator is designed to cool the system. DO NOT block the ventilator for air circulation.
Bottom Side View 1. Ventilator The ventilator is designed to cool the system. DO NOT block the ventilator for air circulation. 2. Woofer Speaker The woofer speaker is to reproduce low-pitched audio frequencies known as bass.
Specifications The specification may change without notice. The actual products sold are different from areas. Please check the detailed specification with your local dealers. Physical Characteristic 383 (W) x 260 (D) x 27-29 (H) mm (15.6") 419.9 (W) x 287.8 (D) x 29.8-32 (H) mm (17.3") Weight 2.4 kg with battery (15.6") 2.7 kg with battery (17.
Storage (items listed here may very without notice) HDD form factor 2.5" HDD SSD (optional) M.2 2280 SSD Optical Drive Device (optional) Super Multi / Blu-ray/ BD Writer I/O Port USB x 3 (version 3.0) x 1 (version 2.0) Mic-in x1 Headphone-out x 1 (S/PDIF-Out supported) RJ45 x1 HDMI x1 Mini-DisplayPort x1 Card Reader x 1 (SD3.0) The supported memory cards may vary without notice.
HDMI output Supported DisplayPort output Supported Multi-Display Function Supported HD CMOS Camera Supported Audio Internal Speaker 4 speakers + 1 woofer Sound Volume Adjusted by keyboard hot-key and switches.
Notebook User's Manual 2-16
Notebook User's Manual How To Get Started 3
Begin to Use the Notebook For a new user of this notebook, we would like to suggest you follow the illustrations below to begin to use the notebook.
How to Use the Notebook Safely If you are a beginner to the notebook, please read the following instructions to assure your own safety, and make yourself comfortable during the operations. ▶▶ Your work area should have enough illumination. ▶▶ Adjust the backrest to support your lower back comfortably when you are sitting upright. ▶▶ Place your feet flat on the floor with your knees bent to a 90 degrees. ▶▶ Adjust the angle/position of the LCD panel to have an optimal view.
How to Manage Power Supply This section provides users basic safety precautions to take when using an AC/DC adapter and battery power properly. AC/DC Adapter To safely and properly power on a notebook, it is strongly recommended to connect the supplied power adapter before turning it on for the first time. Below are some Do's and Don'ts of an AC/DC adapter. ▶▶ DOs • Use the adapter that shipped with your notebook only. • Always be aware of heat coming from the in use AC/DC adapter.
▶▶ Charging the Battery Pack The battery pack can be recharged while it is installed in the notebook. Please pay attention to the following tips before recharging the battery: 3-5 How To Get Started • If a charged battery pack is not available, save your work and close all running programs and shut down the system. • Plug in an external AC/DC adapter. • You can use the system, suspend system operation or shut down and turn off the system without interrupting the charging process.
How to Set Up Power Plan in Windows Below steps show you how to save battery power for your notebook by using a power-saving plan. Follow the instructions below to adjust the power management settings in Windows OS: Power Options in Windows OS allows you to control the power management features of your display, hard drive, and battery. 1. Drag the mouse cursor to the left corner of the screen and [Start] icon will show up. Right click the icon to show selection menu. Select [Control Panel] in the menu. 2.
How To Get Started 3-7
How to Use the Keyboard This notebook provides a full functioned keyboard. To ensure that the keyboard will be functional properly, it is recommended to have the SCM application installed in your operating system. Windows Key You can find the Windws Logo key on the keyboard which is used to perform Windows-specific functions, such as opening the Start menu and launching the shortcut menu. Switch Display + Switch the display output mode between the LCD, external monitor and both.
Enter Sleep Mode Adjust the Brightness Levels of the Display + + Increase the LCD brightness. Decrease the LCD brightness. Adjust the Sound Levels of the Speakers + + + Increase the built-in speaker’s volume. Decrease the built-in speaker’s volume. Mute the built-in speakers. 3-9 How To Get Started + Force the computer into sleep state (depending on the system configuration). Press the Power button to wake up the system from sleep state.
Adjust the Brightness Levels of the Keyboard Backlight LEDs + Increase the brightness level of the keyboard backlight LEDs. Decrease the brightness level of the keyboard backlight LEDs. + Quick Launch Keys Use the [Fn] combination keys on the keyboard to activate the specific applications or tools. With the help of these keys, users will be able to do work more efficiently.
+ Webcam + Airplane mode • Press and hold the Fn key, and then press the F7 key to switch among Sport / Comfort / Green modes and shift the performance. • This function will only be activated when AC Power is plugged-in, and the default setting is Sport mode. • Press and hold the Fn key, and then press the F10 key repeatedly to turn Airplane mode on or off recurrently. • For flight safety consideration, it is always recommended to turn Airplane mode on when you are in flight.
What is Touchpad The touchpad integrated in your notebook is a pointing device that is compatible with standard mouse, allowing you to control the notebook by pointing the location of the cursor on the screen. ▶▶ Configuring the Touchpad You can customize the pointing device to meet your personal needs. For example, if you are a left-handed user, you may want to swap the functions of the two buttons.
▶▶ Point and Click ▶▶ Drag and Drop You can move files or objects in your notebook by using drag-and-drop. To do so, place the cursor on the desired item and slightly tap twice on the touchpad, and then keep your fingertip in contact with the touchpad on the second tap. Now, you can drag the selected item to the desired location by moving your finger on the touchpad, and then lift your finger from the touchpad to drop the item into place.
How to Use PCIe / SATA SSD Combo Slot The M.2 SSD slot in the notebook are compatible with SATA and PCIe interfaces, providing diverse features to users . Please follow the instructions below to uninstall or install the PCIe/ SATA SSDs. Note: Any damage caused while replacing the device may void the warranty. 1. Loosen the screw that secures the optical disc drive. 2. Pull the optical disc drive out. 3. Loosen the screws that secure the back panel and remove it.
Types of Slot and SSD 1. SATA Gen 3 M.2 Slot 2. SATA Gen 3 M.2 & PCIe 2.0 x2/ x4 Combo Slot 3. SATA Gen 3 M.2 2280 SSD Uninstallation and Installation Uninstallation Installation 3-15 How To Get Started 4. SATA Gen 3 M.2 or PCIe 2.
How to Use Optical Disc Drive This notebook may be equipped with an optical disc drive. Follow the instructions below to insert a disc. Devices shown here are for reference only. 1. Confirm that the notebook is turned on. 2. Press the eject button on the panel and the disc tray will slide out partially. 3. Gently pull the tray out until fully extended. 4. Place the disc in the tray and confirm the disc is placed correctly and securely. Slightly press the center of the disc to secure it into place. 5.
How to Connect the Internet Wireless LAN ▶▶ Turning Airplane mode off For flight safety consideration, it is always recommended to turn Airplane mode on when you are in flight. When Airplane mode is enabled, Wireless LAN connection and Bluetooth will be turned off. Please make sure turning Airplane mode off before setting up Wireless LAN connection. Go to the desktop. (Please launch Desktop if you are in Win 8 Start screen.) 1. Find the [Settings] icon on the desktop and click on it. 2.
▶▶ Setup Wireless LAN 1. Unfold the setting menu by pointing the mouse to the lower-right corner of the desktop and clicking it. 2. Click the [Wireless LAN] icon. 3. Select a Wireless LAN connection from the network list. 4. A security key will be required for connecting the selected network. Then click [Next].
Wired LAN Using cables and network adapters to connect to the internet. ▶▶ Setup Dynamic IP/PPPoE connection Go to the desktop (Please launch Desktop if you are in Win 8 Start screen) 2. Choose [Change adapter settings]. 3. Right click on [Ethernet] to select [Properties] from the drop-down menu. 4. In the Ethernet Properties window, select [Networking] tab and check [Internet Protocol Version 4 (TCP/IPv4)]. Then click [Properties] to continue. 5.
6. Repeat step 1 to launch [Network and Sharing Center] again. Select [Set up a new connection or network] under [Change your networking settings]. 7. Choose [Connect to the Internet], and then click [Next]. 8. Click [Broadband (PPPoE)]. 9. Fills User name, Password, and Connection name fields. Then click [Connect].
How To Get Started 3-21
▶▶ Setup a static IP internet connection 1. Follow the previous steps 1 to 4 in [Setup Dynamic IP/PPPoE Connection]. 2. Select [General] tab and click [Use the following IP address] and [Use the following DNS server addresses]. You will be asked to enter the IP address, Subnet mask, and Default gateway into the empty place , then click [OK].
How to Set Up Bluetooth Connection Bluetooth pairing is a process in which two Bluetooth enabled devices communicate with each other through an established connection. ▶▶ Turning Airplane mode off Refer to the previous Wireless LAN section to turn Airplane mode off before activating Bluetooth connection. ▶▶ Pairing Bluetooth devices Go to the desktop. (Please launch Desktop if you are in Win 8 Start screen.) 1.
3. Click "PC and devices" from the PC settings list. 4. Choose a desired Bluetooth device from the connection list, and then click [Pair] to continue. 5. Match the passcode between the notebook and the selected Bluetooth device, click [yes] to finish.
How to Connect External Devices This notebook may equipped with various connecting I/O (input/output) ports, such as USB, HDMI, DisplayPort, and mini DisplayPort. Users will be able to connect diverse peripheral devices to the notebook. 3-25 How To Get Started To connect these devices, refer to the instruction manuals of each device first, and then connect the device to the notebook.
How to Use Multiple Monitors If users connect an additional monitor to the notebook, the system will automatically detect the external monitor connected. Users will be allowed to customize the display settings. 1. Connect the monitor to the notebook. 2. Press and hold the Windows key, and then press [P] key to bring up [Display Settings]. 3. Select a desired mode ▶▶ PC screen only: shows the desktop on the monitor of the notebook only.
How to Use RAID Function To set up RAID, follow the instructions below: 1. Create a recovery disk with the Recovery Image Backup Tool that comes with the package of the notebook. Users may find the shortcut of BurnRecovery on the Start Screen or Windows desktop. 2. Assemble SSDs or HDDs with exactly the same capacity and brand. Make sure you have proper skills to do the assembly of SSDs or HDDs or you can contact an authorized service center for further assistance. 3.
How to Select Boot Mode in BIOS while installing OS 1. Power on the system. As soon as the first logo screen appears, press the DEL key immediately and enter the BIOS menu. 2. Move the cursor to [Boot] tab, and select [Boot mode select] in Boot Configuration. 3. For operating systems support UEFI-based BIOS (Windows 8 and Windows 8.1), it is suggested to select [UEFI]. 4. For Windows 7 or previous versions of Windows, select [Legacy] mode.
Where Are Key Components In this section you will find information about main parts inside a notebook, some may be upgradable or replaceable depending on the model purchased. 1. HDD 2. Memory 3. M.2 SSD 4. Bluetooth/ WiFi combo card 5. ODD 3-29 How To Get Started Don't try to upgrade your device yourself as unauthorized replacements may void your warranty. To obtain service, please contact a local authorized service center.
Notebook User's Manual 3-30
