Specification Sheet
GRAPHICS CARD
GEFORCE® GTX 1060
6GT OC
© 2018 Micro-Star Int'l Co.Ltd. MSI is a registered trademark of Micro-Star Int'l Co.Ltd. All rights reserved. © 2016 NVIDIA, the NVIDIA logo, GeForce, SHIELD, and NVIDIA G-SYNC are trademarks and/or
registered trademarks of NVIDIA Corporation in the U.S. and other countries.
GRAPHICS CARD
GEFORCE® GTX 1060
6GT OC
© 2018 Micro-Star Int'l Co.Ltd. MSI is a registered trademark of Micro-Star Int'l Co.Ltd. All rights reserved. © 2016 NVIDIA, the NVIDIA logo, GeForce, SHIELD, and NVIDIA G-SYNC are trademarks and/or
registered trademarks of NVIDIA Corporation in the U.S. and other countries.
FEATURES
DUAL FAN THERMAL DESIGN
Dual fans covers more area of heatsink to take heat away more
efficiently.
Military Class 4 Components
Using only the highest quality components means you get
reliable and stable in-game performance.
OC PERFORMANCE
MSI OC graphics cards are equipped with higher clock speeds
out of the box for increased performance.
VR Ready
Certified to provide the performance required for a smooth
experience in your VR adventures.
MSI Afterburner
The ultimate overclocking software with advanced control
options and real-time hardware monitor.
NVIDIA G-SYNC™
Gives you more of what you want in a gaming experience.
Incredibly smooth, tear-free gameplay at refresh rates up to 240
Hz.
PASCAL PERFORMANCE
Pascal-powered graphics cards give you superior performance
and power efficiency to deliver the best gaming experiences.
SPECIFICATIONS
Model Name
GeForce
®
GTX 1060 6GT OC
Graphics Processing Unit
NVIDIA
®
GeForce
®
GTX 1060
Interface PCI Express x16 3.0
Core Name GP106-400
Cores 1280 Units
Core Clocks 1759 MHz / 1544 MHz
Memory Clock Speed 8008 MHz
Memory 6GB GDDR5 (192-bit)
Output DisplayPort (Version 1.4) / HDMI (Version 2.0) / DL-DVI-D
HDCP Support 2.2
Power consumption 120 W
Power connectors 6-pin x 1
Recommended PSU 400 W
Card Dimension(mm) 247 x 115 x 39 mm
Weight (Card / Package) 591 g / 940 g
Afterburner OC Y
DirectX Version Support 12
OpenGL Version Support 4.5
Maximum Displays 2
VR Ready Y
G-SYNC™ technology Y
Adaptive Vertical Sync Y
CONNECTIONS
DisplayPort1.
HDMI2.
DVI-D3.
Generated 2018-03-12, check for the latest version www.msi.com/datasheet. The information provided in this document is intended for informational purposes only and is subject to change without notice.
