Remote Control Manual

6
TIMER ON OFF
FAN
HIGH
MED
LOW
AUTO
COOL
DRY
HEAT
Information that is displayed when the remote is turned on.
Mode display
AUTO: COOL: DRY: HEAT: FAN:
Displayed when remote signal is sent.
Displayed when remote control is ON.
TIMER ON Displayed when TIMER ON time is set.
TIMER OFF Displayed when TIMER OFF time is set.
Show set temperature or room temperature,
or time under TIMER setting.
Indicated all the current settings are locked.
Fan speed indication
HIGH - High speed
MED - Medium speed
LOW - Low speed
No Display - Auto fan speed
Note:
All indicators shown in the figure are for the purpose
of clear presentation. But during the actual operation
only the relative functional signs are shown on the
display window.
LCD Indicators
